「lden」の検索結果

DescriptionThe XBee3 Thing Plus is an ultra capable and easy way for getting into wireless device development. The combination of XBee and Qwiic in a space conscious design represents a much needed update to our XBee offering. With 20 I/O pins and Lithium Polymer Ion battery management， the XBee3 Thing Plus has all the basics for quickly prototyping or developing a connected device such as a remote sensor. The Qwiic connector and JST connector for the battery make for a solder-less option when working with the board which shortens setup time.The new XBee3 Micro Module provides the classic all-but plug and play 802.15.4 2.4GHz wireless connection(Zigbee 3.0 Protocol)that makes it so desirable， but with a new addition of being programmable with MicroPython(32KB of memory available for it). RF data rates up to 250 Kbps and 200ft indoor ranges and up to 4000ft line-of-sight outdoor range. Communicating with/Configuring the module happens via an AT Command set or the Digi API， X-CTU， both locally or over-the-air. There's even a mobile version of X-CTU now； Digi XBee(R)Mobile.This variation features a U.FL antenna connector for longer range communications. Check out the related products for compatible antennas.Get Started With the SparkFun XBee3 Thing Plus GuideFeaturesXBee3 Micro ModuleSilicon Labs EFR32MG SoC250Kbps RF， 1Mbps Serial data ratesIndoor/Urban range up to 200 ft(60 m)Outdoor/RF Line of Sight range up to 4000 ft(1200 m)+8 dBm transmit power-103 dBm receiver sensitivityUART， I2C， SPI Interfaces(SPI currently not available at this time， but broken out on the board)ISM 2.4GHz Frequency Band(802.15.4)1MB of memory， 128KB RAM(32KB available for MicroPython)20 GPIO PinsConfigurable via X-CTU or AT Command set via both USB and Wirelessly(second XBee 3 device required for wireless configuration unless you're using the mobile app)Qwiic CompatibleOn-board charging circuit and connector for 3.3v Lithium Polymer Ion Batteries(see related products for compatible batteries)2.6VDC - 3.6VDC supply voltageU.FL Antenna Connector

DescriptionThe XBee3 Thing Plus is an ultra-capable and easy way for getting into wireless device development. The combination of XBee and Qwiic in a space-conscious design represents a much-needed update to our XBee offering. With 20 I/O pins and Lithium-Polymer Ion battery management， the XBee3 Thing Plus has all the basics for quickly prototyping or developing a connected device such as a remote sensor. The Qwiic connector and JST connector for the battery make for a solder-less option when working with the board which shortens setup time.The new XBee3 Micro Module provides the classic， near plug and play 802.15.4 2.4GHz wireless connection(Zigbee 3.0 Protocol)that makes it so desirable， but with a new addition of being programmable with MicroPython(32KB of memory available for it). RF data rates up to 250Kbps and 200 ft indoor ranges and up to 4000 ft line-of-sight outdoor range. Communicating with/Configuring the module happens via an AT Command set or the Digi API， X-CTU， both locally or over-the-air. There's even a mobile version of X-CTU now； Digi XBee(R)Mobile.Note：This variation uses a chip antenna and is not compatible with external antennas.Get Started With the SparkFun XBee3 Thing Plus GuideFeaturesXBee3 Micro ModuleSilicon Labs EFR32MG SoC250Kbps RF， 1Mbps Serial data ratesIndoor/Urban range up to 200 ft(60 m)Outdoor/RF Line of Sight range up to 4000 ft(1200 m)+8 dBm transmit power-103 dBm receiver sensitivityUART， I2C， SPI Interfaces(SPI currently not available at this time， but broken out on the board)ISM 2.4GHz Frequency Band(802.15.4)1MB of memory， 128KB RAM(32KB available for MicroPython)20 GPIO PinsConfigurable via X-CTU or AT Command set via both USB and Wirelessly(second XBee 3 device required for wireless configuration unless you're using the mobile app)Qwiic CompatibleOn-board charging circuit and connector for 3.3v Lithium Polymer Ion Batteries(see related products for compatible batteries)2.6VDC - 3.6VDC supply voltageOn-board Chip Antenna

DescriptionThe SparkFun Qwiic Adapter provides the perfect means to make any old I2C board into a Qwiic-enabled board. This adapter breaks out the I2C pins from the Qwiic connectors to pins that you can easily solder with your favorite I2C-enabled device.The Qwiic Adapter has two Qwiic connection ports， all on the same I2C bus. Four plated through holes are broken out for SCL， SDA， 3.3V and GND. These pins can be used to convert an old I2C-enabled device into a Qwiic-enabled board.The SparkFun Qwiic Connect System is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.Get Started with the SparkFun Qwiic Adapter GuideFeatures2x Qwiic Connection PortsBroken-out I2C Pins

DescriptionThe SparkFun ProtoShield Kit lets you customize your own Arduino shield using whatever circuit you can come up with and then test it to make sure everything is working the way it should! The SparkFun ProtoShield Kit is based off the Arduino R3's footprint that allows you to easily incorporate it with favorite Arduino-based device.One of our favorite features with this version of the ProtoShield Kit is the solderable-like breadboard prototyping area! Half of this area was designed with a breadboard in mind. On the underside of the shield you will be able to see open jumper pads between each through hole to make a connection like a breadboard. Once you add a component， simply add a solder jumper between holes to make a connection. For those that prefer the standard prototyping pads， we left the other side(near the BlueSMiRF and Serial UART ports)as is.We have also moved the prototype testing components(those used to make sure your circuit works effectively)off of the "mainland" of the shield and onto a ProtoSnap styled， removable PCB. On this test area you will find soldering areas for the two yellow 3mm LEDs(as well as pins to control and power them)， two 330 Ohm resistors， a 10K Ohm resistor， and a pushbutton.Note：Since this product is a kit， assembly and a basic knowledge of soldering will be required. The SparkFun ProtoShield Kit does not come pre-assembled.Get Started With the SparkFun ProtoShield Kit GuideFeaturesArduino R3 FootprintSoldering KitSolderable-Like BreadboardBlueSMiRF or Comparable 6-pin PinsDetachable Test Area

DescriptionRobots are fun， and the micro：bit is the perfect controller for learning how to build and program robots! Combining the micro：bit with the SparkFun moto：bit carrier board creates a flexible， low-cost， Qwiic-enabled robotics platform for robot enthusiasts young and old! With the SparkFun micro：bot kit you will be able to create simple robots quickly without spending hours learning how to build and program your bot.Inside each micro：bot kit you will find all the components required to build your micro：bit into a robotics powerhouse； the only part that's not included is the micro：bit itself. Simply add your own micro：bit to the provided moto：bit， assemble the kit， and you will be ready to start moving. The SparkFun micro：bot kit is a great way to get your feet wet in the world of robotics.The kit does not require any soldering and is recommended for anyone curious about robotics or the micro：bit platform.Note：The SparkFun micro：bot kit doesNOTinclude a micro：bit board. The micro：bit board will need to be purchased separately.The micro：bit is a pocket-sized computer that lets you get creative with digital technology. Between the micro：bit and our shield-like bit boards you can do almost anything while coding， customizing and controlling your micro：bit from almost anywhere! You can use your micro：bit for all sorts of unique creations， from robots to musical instruments and more. At half the size of a credit card， this versatile board has vast potential!Get started with the micro：bot kit Guide

DescriptionThe SparkFun BME280 Atmospheric Sensor Breakout is the easy way to measure barometric pressure， humidity， and temperature readings all without taking up too much space. Basically， anything you need to know about atmospheric conditions you can find out from this tiny breakout. The BME280 Breakout has been design to be used in indoor/outdoor navigation， weather forecasting， home automation， and even personal health and wellness monitoring.The on-board BME280 sensor measures atmospheric pressure from 30kPa to 110kPa as well as relative humidity and temperature. The breakout provides a 3.3V SPI interface， a 5V tolerant I2C interface(with pull-up resistors to 3.3V)， takes measurements at less than 1mA and idles less than 5μA. The BME280 Breakout board has 10 pins， but no more than six are used at a single time. The left side of the board provide power， ground， and I2C pins. The remaining pins which provide SPI functionality and have another power and ground， are broken out on the other side.Note：The breakout does NOT have headers installed and will need to purchased and soldered on yourself. Check theRecommended Productssection below for the type of headers we use in the Hookup Guide!FeaturesOperation Voltage：3.3VI2C SPI Communications InterfaceTemp Range：-40C to 85CHumidity Range：0 - 100% RH， =-3% from 20-80%Pressure Range：30，000Pa to 110，000Pa， relative accuracy of 12Pa， absolute accuracy of 100PaAltitude Range：0 to 30，000 ft(9.2 km)， relative accuracy of 3.3 ft(1 m)at sea level， 6.6(2 m)at 30，000 ft.Incredibly Small

DescriptionThis is an ET Series replacement soldering tip for the Weller WE1010 soldering station. It is a "screwdriver" type of soldering tip， measuring 1/16"(1.6mm)wide. Replacing the tip is a breeze --- simply unscrew the currently attached tip， slip the replacement tip in， and screw it into place.This Weller tip has been pre-tinned with a lead-free alloy. Although this soldering tip is called a "screwdriver，" this is in name only and functions in no way similar to the tool it is named after.

DescriptionThe Hologram eUICC SIM Card is a mix between legacy and new technology when cellular service is needed your project. This eUICC SIM Card enables profile switching capabilities so you can dynamically change the subscriber profile while your chosen devices are in the field， over-the-air. For those looking for IoT cellular service with no intentions on switching cellular carriers， this SIM card is for you.eUICC features are limited to certain modules at this point. This includes the u-blox SARA-R4 module used on our SparkFun LTE CAT M1/NB-IoT Shield - SARA-R4. For these situations， the functionality will be that of a normal SIM with cellular service through Hologram. You won't be able to change carriers.FeaturesTemperature Range：-25C to 85CNano SIM 8.8mm x 12.3mmMinimum 500，000 Read/write cyclesMinimum 25 yrs at 25℃ Data retention

DescriptionThis diode-transistor photocouplers consist of an LED， optically coupled to a high speed photodetector to transmit electrical signals between circuits while still isolating your system from higher voltages. The 6N137 optoisolator is presented in an 8-pin DIP package.The output features is an open collector and coupler parameters are guaranteed over the temperature range from -40℃～5℃. The internal shield provides a guaranteed Common Mode Transient Immunity(typical)10KV/μs.FeaturesHigh Speed：10MBdCommon Mode Rejection：10KV/μs

DescriptionThe 6-Channel Temperature Monitor can measure temperatures from as low as -240℃ up to +850℃(real-world limits greatly depend on the sensors being used). Up to six 3-wire PT100 sensors(not included)can be connected for measuring up to six temperatures. Measured temperature values are sent on a serial port for data logging and/or further processing. The kit includes an optional serial LCD for displaying readouts right on the board.Note：The kit requires soldering， a Serial to USB converter， and 9V power supply. See related products for these and PT100 temperature sensors.

DescriptionThis is a 16mm deluxe thumb joystick and is very similar to the 'analog' joysticks found inside PlayStation controllers. Directional movements are provided simply by two potentiometers - one for each axis. These 10k potentiometers will read the position changes for the joystick's full range of physical motion. This joystick also has a select button that is actuated when the joystick is pressed down.The mechanical parts found in this joystick are mostly metal and are considered far sturdier(rugged， if you will)than other， plastic joystick options.Note：This thumb joystick does not include a top cap and it will need to be purchased separately. Additionally， the leads on the housing of this joystick are much thicker than the leads on the trimpots &； push button components. When soldering to BOB-9110， we recommend using a pair of fine tip tweezers to guide each pin into the correct hole before pushing down.

DescriptionThe MicroMod Qwiic Carrier Board can be used to rapidly prototype with other Qwiic devices. The MicroMod M.2 socket provides users the freedom to experiment with any processor board in the MicroMod ecosystem. This board also features two Qwiic connectors and four 4-40 screw inserts to connect and mount Qwiic devices.This version of the SparkFun MicroMod Qwiic Carrier Board features a single port for our standard 1in. by 1in. Qwiic Breakouts. However， you aren't beholden to attaching just one Qwiic breakout since you are able to stack the boards on top of each other， allowing you to hook up a full circuit of Qwiic sensors and accessories to fully utilize your next project!MicroMod is a modular interface ecosystem that connects a microcontroller "processor board" to various "carrier board" peripherals. Utilizing the M.2 standard， the MicroMod standard is designed to easily swap out processors on the fly. Pair a specialized carrier board for the project you need with your choice of compatible processor!Get Started With the MicroMod Qwiic Carrier Board GuideFeaturesM.2 MicroMod(Processor Board)ConnectorUSB-C Connector3.3V 1A Voltage RegulatorQwiic ConnectorsBoot/Reset ButtonsCharge CircuitFour 4-40 Inserts

DescriptionThe SparkFun micro：climate kit is a full weather station kit that is built on top of the weather：bit carrier board. Unlike previous weather kits we've carried， this micro：climate kit is Qwiic enabled and includes our tried-and-true Weather Meters and Soil Moisture Sensor， so whether you're an agriculturalist， a professional meteorologist or a hobbyist， you will be able to build a high-grade weather station powered by the micro：bit. You can even talk via wireless communication between two micro：bits with this kit to be able to monitor the weather without being exposed to it!Inside each micro：climate kit you will find all the components required to build your micro：bit into a go-to weather sensor； the only parts not included are two AAA batteries， microSD card， and the micro：bit itself. Simply add your own micro：bit to the provided weather：bit， assemble the kit， and you will be ready to start sensing. The SparkFun micro：climate kit is a great way to get your feet wet in high-grade sensors --- just not literally； that's the weather：bit's job!The kit does not require any soldering and is recommended for anyone curious about weather-sensing technology or the micro：bit platform.The micro：bit is a pocket-sized computer that lets you get creative with digital technology. Between the micro：bit and our shield-like bit boards you can do almost anything while coding， customizing and controlling your micro：bit from almost anywhere! You can use your micro：bit for all sorts of unique creations， from robots to musical instruments and more. At half the size of a credit card， this versatile board has vast potential!Note：The SparkFun micro：climate kit doesNOTinclude a micro：bit board. The micro：bit board will need to be purchased separately. You will also need a microSD card when logging data and AAA batteries to power remotely.Get started with the micro：climate kit Guide

DescriptionThe SparkFun Inventor's Kit for micro：bit v2 Lab Pack includes 10 complete micro：bit v2 Inventor's Kits， an SIK Refill Pack and 25 AAA-sized batteries to get your students started in the world of electronics. The SIKs inside the Lab Pack have everything you need， including micro：bit v2s， connector breakouts， breadboards and all the cables and accessories to hook up all the projects listed in our online Experiment Guide.The kit does not require any soldering and is recommended for all users， from beginners to engineering students. We have provided a complete Experiment Guide in the Documents tab for you to check out now! If you are new to teaching electronics or have taught with the original SparkFun Inventor's Kit and are looking for something new， the SIK for micro：bit v2 is the perfect kit for you!SparkFun packages everything educators need to get started with this platform in a variety of classroom and makerspace settings with diverse student populations. The hardware boards， cables and extra parts come pre-packaged， and our online support materials --- including an online Experiment Guide(to be updated)--- help you bring the power of the open source community to your classroom. Examples and curriculum materials are available from SparkFun and Arduino， as well as from other educators involved in this growing maker movement.The micro：bit is a pocket-sized computer that lets you get creative with digital technology. Between the micro：bit and our shield-like bit boards you can do almost anything while coding， customizing and controlling your micro：bit from almost anywhere! You can use your micro：bit for all sorts of unique creations， from robots to musical instruments and more. At half the size of a credit card， this versatile board has vast potential!

DescriptionThe SparkFun Inventor's Kit(SIK)for micro：bit v2 is a great way to get creative， connected and coding with the micro：bit. The SIK for micro：bit v2 provides not only the micro：bit v2 board but everything you need to hook up and experiment with multiple electronic circuits! With the SIK for micro：bit v2 you will be able to complete circuits that will teach you how to read sensors， move motors， build Bluetooth(R)devices and more.The SparkFun Inventor's Kit for micro：bit is the latest and greatest in single-board computer kits. Surrounding the micro：bit v2 SIK is one core philosophy --- that anyone can(and should)experiment with cutting-edge electronics in a fun and playful way without breaking the bank.The kit does not require any soldering and is recommended for all users， from beginners to engineers. We have provided a complete Experiment Guide in the Documents tab for you to check out now! If you have ever been interested in learning about electronics， or if you have used the original SparkFun Inventor's Kit and are looking for something new， the SIK for micro：bit is the perfect kit for you!The micro：bit is a pocket-sized computer that lets you get creative with digital technology. Between the micro：bit and our shield-like bit boards you can do almost anything while coding， customizing and controlling your micro：bit from almost anywhere! You can use your micro：bit for all sorts of unique creations， from robots to musical instruments and more. At half the size of a credit card， this versatile board has vast potential!ExamplesCircuit 0：Hello， micro：bit!Circuit 1：Blinking an LEDCircuit 2：Reading a PotentiometerCircuit 3：Reading a PhotoresistorCircuit 4：Driving an RGB LEDCircuit 5：Reading an SPDT SwitchCircuit 6：Reading a Button PressCircuit 7：Reading the Temperature SensorCircuit 8：Using a Servo MotorCircuit 9：Using a BuzzerCircuit 10：Using the AccelerometerCircuit 11：Using the Compass

Here is a very simple breadboard power supply kit that takes power from a DC wall wart and outputs a selectable 5V or 3.3V regulated voltage. The .1" headers are mounted on the bottom of the PCB for simple insertion into a breadboard. Pins labeled VCC and GND plug directly into the power lines. The lone pair of pins have no electrical connection but help support the PCB.There are two pins available within the barrel jack footprint. Any stripped +/- DC supply can be connected instead of the barrel connector. Board has both an On/Off switch and a voltage select switch(3.3V/5V).Comes as a bag of parts kit and is easily assembled if you can follow the silkscreen indicators and have beginning experience with a soldering iron. You will need to read the resistor bands or use a multimeter to determine the resistor sizes.Dimensions：1.25x1.25"Kit Includes：DC Barrel Connector(2.1mm center positive)TO-220 Voltage Regulator(LM317 1.5A max current)1N4004 Reverse Protection Diode100uF 25V Capacitor10uF 25V Capacitor0.1uF 50V CapacitorRed Power LED - High Brightness2×SPDT Slide Switch4×0.1" Header Pins2×330 Resistor 1/6W390 Resistor 1/6W240 Resistor 1/6WBare PCB with Silkscreen IndicatorsPTC resettable fuse

DescriptionThe Solder-Mate(TM)Solder Dispenser provides you with an easy way to， well...dispense solder! This handy tool provides a continuous supply of solder(until the roll runs out， that is)， freeing up hand space and minimizing downtime. Each solder dispenser can hold up to a 1lb solder spool. This is a great addition to any workbench!Note：Solder is NOT included with the Solder-Mate and will need to be purchased separately.

DescriptionRotary encoders can be used similarly to potentiometers. The difference being that an encoder has full rotation without limits(It just goes round and round). They output gray code so that you can tell how much and in which direction the encoder has been turned. They're great for navigating menu screens and things like that.This encoder is especially cool because it has a common anode RGB LED built in， as well as a push-button. This version has an updated material that is heat resistant and slightly changed dimensions， but should still work well with our rotary encoder breakout board.FeaturesSwitch Travel：0.5mmShaft Diameter：6.0mmShaft Length：18mmVertical Through-Hole Mount24 Pulses per RotationRed/Green/Blue LEDPushbutton

DescriptionThis is the FemtoBuck， a small-size single-output constant current LED driver. Each FemtoBuck has the capability to dim a single high-power channel of LEDs from 0-350mA at up to 36V while the dimming control can be either accessed via PWM or analog signal from 0-2.5V. This board is based off of the PicoBuck LED Driver， developed in collaboration with Ethan Zonca， except instead of blending three different LEDs on three different channels the FemtoBuck controls just one.For the FemtoBuck， we've increased the voltage ratings on the parts to allow the input voltage to cover the full 36V range of the AL8805 driver. Since the FemtoBuck is a constant current driver， the current drawn from the supply will drop as supply voltage rises. In general， efficiency of the FemtoBuck is around 95%， depending on the input voltage. On board each FemtoBuck you will find two inputs for both power input and dimming control pins and an area to install a 3.5mm screw terminal. Finally at either side of the board you will find small indents or "ears" which will allow you to use a zip tie to secure the wires to the board after soldering them down. This version of the FemtoBuck is equipped with a small solder jumper that can be closed with a glob of solder to double the output current from 330mA to 660mA.

DescriptionBe still my beating heart! With the heART Surface Mount Soldering Kit you will be able to learn the basics of SMD soldering by being able to assemble a beating heart pendant! Each heART kit takes about 20-40min to assemble depending on your soldering skill level with basic soldering materials(not included). This little kit provides a great learning tool to help you practice and improve your overall soldering skills without proving to be an impossible challenge!Every heART pendant kit includes one heart-shaped PCB， a CR2032 SMD battery holder， SMD LEDs， capacitors， switch， and an ATtiny85(the heart of the heART). All you need to supply(besides a soldering iron and solder)is a CR2032 coin cell battery since it isnotincluded to make shipping easier and some way to hang the completed pendant from your neck when you assemble it. The battery you provide should last over a week if left on continuously and much longer if switched off when not in use.Note：Since this product is a kit， assembly and a healthy knowledge of soldering will be required. The heART pendant kit does not come pre-assembled.

DescriptionThe MQ-9B is a CO and CH4 gas detection sensor form Winsen. The sensing material of the MQ-9B is SnO2， which has a low conductivity in clean air. It detects carbon monoxide(1.5V)by method of cycling high and low temperature. The sensor's conductivity gets higher with the CO and CH4 gas concentration rising. The sensing range is 10-500ppm CH4. A simple circuit makes measuring this change in conductivity and turning it into data fairly straight-forward， but does require some calibration.For easy Solderability； use our Gas Sensor Breakout Board.

DescriptionRobots are fun， and Arduinos are easy. So wouldn't it be nice if there were kit that included everything you need to get your Arduino device set up to control simple two-motor-circuit buddy? The SparkFun Ardumoto Shield Kit is perfect for any robot enthusiast and includes an Ardumoto Shield， as well as pairs of tires， motors， connectors and wires. And， of course， it's all stuffed in classic SparkFun red box(which may come in handy as robot chassis).The Ardumoto Shield is an easy-to-use dual-motor controller for Arduino. Combined with an Arduino， the Ardumoto makes fantastic controller platform for RC vehicles or even small autonomous robots. At the heart of the Ardumoto --- the big， black chip right in the middle --- is an L298， one of our favorite dual-channel motor drivers around， capable of driving up to 2A per channel. The board takes its power from the same Vin line as the Arduino board and includes blue and yellow LEDs to indicate active direction. All driver lines are diode protected from back EMF.Note：The motors included with this kit are not compatible with the Wheel Encoder kit. Sorry for the inconvenience.Get Started with the SparkFun Ardumoto Kit Guide

DescriptionYour 5V system can wield great power with this big， beefy relay board. How does 10A on the NC contacts and 20A on the NO contacts at 220VAC sound? The SparkFun Beefcake Relay Control Kit contains all the parts you need to get your high-power load under control. Only minimal assembly is required!The heart of the board is sealed， SPDT 20A/10A Relay. The relay is controlled by 5V logic through transistor， and an LED tells you when the relay is closed. This is kit， so it comes as through-hole parts with assembly required， which makes for some nice soldering practice. Screw terminal connectors on either side of the board make it easy to incorporate into your project.There are some pretty beefy traces connecting the relay to the load pins， but the 3-pin terminals are only rated for 15A max! If you plan on connecting larger load， you'll need to solder directly to the board. As always with high current and voltage， play it safe and use your judgment when deciding how much of load you want to put on board -- in open airflow the PCB can handle the full 20A for few minutes at time， but in an enclosed area heat can build up.Note：Please keep in mind that this board is really meant for someone with experience and good knowledge of electricity. If you're uncomfortable soldering or dealing with high voltage， please check out the IoT Power Relay. The IoT Power Relay is fully enclosed， making it lot safer.Get Started With the Beefcake Hookup Assembly GuideFeaturesVoltage Rating：220VAC/28VDCVCC requirements：4-6V， 150mA capableSPDT pins exposed(Form C)14 AWG screw terminals for relay connections.10 AWG solder lugs for relay connections.Flyback diode includedZener recovery diode included(decreases turn-off time)Heavy oz. copper on PCB

DescriptionDo you own micro：bit or micro：bit Go Bundle and want to expand your skills with the new microcontroller? You are in luck! The SparkFun Inventor's Kit Bridge Pack for micro：bit was designed to provide you with an easy way to transform your m：b into full fledged learning kit! Each Bridge Pack includes all of the parts found in the SIK for micro：bit that aren't included with the Go Bundle. With the SIK Bridge Pack for micro：bit you will be able to complete circuits that will teach you how to read sensors， move motors， build Bluetooth(R)devices and more.The micro：bit is pocket-sized computer that lets you get creative with digital technology. Between the micro：bit and our shield-like bit boards you can do almost anything while coding， customizing and controlling your micro：bit from almost anywhere! You can use your micro：bit for all sorts of unique creations， from robots to musical instruments and more. At half the size of credit card， this versatile board has vast potential!Note：The Bridge Pack is NOT full SparkFun Inventor's Kit and only includes the parts to complement micro：bit Go Bundle or standalone board. That also means that this kit doesnotinclude micro：bit， which will need to be purchased separately.Get started with the micro：bit SIK Experiment GuideExamplesCircuit 0：Hello， micro：bit!Circuit 1：Blinking an LEDCircuit 2：Reading PotentiometerCircuit 3：Reading PhotoresistorCircuit 4：Driving an RGB LEDCircuit 5：Reading an SPDT SwitchCircuit 6：Reading Button PressCircuit 7：Reading the Temperature SensorCircuit 8：Using Servo MotorCircuit 9：Using BuzzerCircuit 10：Using the AccelerometerCircuit 11：Using the Compass

USB Type 'B' Female connector. The 4 connection pins have .1" spacing allowing it to be inserted into development boards and perf boards with mild modification. You can either drill two 80mil holes for the support posts、or cut them off completely.

DescriptionThis is the Teensy 4 Audio Shield(Rev D)that can be added to a Teensy 4.0 for your next audio project. The shield provides you with an easy-to-use tool to add high quality 16 bit， 44.1 kHz sample rate audio to your Teensy. With the audio li

DescriptionThe SparkFun Large Digit Driver is a chainable controller backpack that can be soldered directly to the back of our large 6.5" 7-segment displays. Large numerical displays are a great addition to any project where you want to be able to see

DescriptionThe Elektor STM32 Nucleo Starter Kit is the perfect entry point into the world of the widely popular STM32 microcontroller line. This bundle covers many projects using most features of the STM32 Nucleo development boards with the full softw

DescriptionThe Alchitry Au+ is the "gold" standard for FPGA development boards and it's possibly one of the strongest boards of its type on the market. The Au+ substitutes a more robust scalable FPGA chip(Xilinx XC7A100T)that allows for more complex a

DescriptionThere are a couple must-have boards that every engineer and hobbyist should have on their desk， and this PCA9306 dual， bidirectional voltage-level translator breakout is one of them! Because different parts sometimes use different voltage

DescriptionThe SparkFun Wireless Joystick Kit provides an easy way to control your next XBee project. Before the wireless joystick， radio-controlled projects used hobby RC transmitters， the same ones used for RC cars， boats and planes. The problem with these transmitters is that many aren't customizable， and the ones that are tend to be too expensive for many of us. The Wireless Joystick Kit offers a custom wireless solution for those who want to control their project their own way.Equipped with the increasingly popular SAMD21 onboard， all you need is to assemble the SparkFun Wireless Joystick into the configuration you want and add your own XBee and lithium ion battery into the provided sockets. The Wireless Joystick Kit can be assembled into a configuration that utilizes dual joysticks for better RC steering robots(like tanks)or a single joystick configuration with four 12mm momentary pushbuttons(a setup similar to what older game consoles used). We have provided a full Hookup Guide that gives assembly instructions， as well as a tank-steering motor controller tutorial to help get you started!Please be aware that the SparkFun Wireless Joystick Kit isNOT supported on Windows 7/8due to a lack of support drivers for those specific OS's.Note：This kit will need to be assembled before use， so a beginner's knowledge of soldering will be required. Additionally， in an effort to keep shipping rates down and make this kit available to people throughout the world without delay， there is no XBee or lithium ion battery included.Get Started with the Wireless Joystick Kit Guide

DescriptionPassive Infrared(PIR)sensors are great for detecting motion in a small area around the sensor. The 170μA SparkFun EKMC4607112K PIR Breakout is a simple board equipped with an EKM-series PIR sensor from Panasonic(R). The EKM-series PIR sensors are optimized for small movements to offer motion-sensing options for continuously powered applications.PIR sensors do not return specific distance data but instead monitor for IR light coming from objects in their field of view and will activate their signal when motion is detected in their sensing area， making them perfect for applications such as turning devices on automatically when motion is detected. Applications include home and building automation for energy saving， automated on/off lighting control， security， appliances， and IoT.Panasonic's low-profile PIR motion sensors(10.9mm versus standard 14.4mm height offer space savings for constrained designs)consist of a lens to create various detection zones， an optical filter to block non-infrared light， pyroelectric sensing elements， electromagnetic shielding to all circuitry， and an impedance converter to get an electrical signal. This PIR sensor offers digital output across 32 zones at 5m detection distance with 90°×90° detection area.Note：The sensitivity of passive infrared sensors is influenced by environmental conditions， so a performance evaluation test under representative conditions is recommended.Get Started with the SparkFun PIR Breakout GuideFeaturesOperating Voltage：2.3-4.0V170 μAstandby current consumptionLens diameter - 10.4mmLens Height - 10.9mm5m detection distance90°×90°(±45°)detection area

DescriptionThe SparkFun Inventor's Kit(SIK)for Arduino Uno is a great way to get started with programming and hardware interaction with the Arduino programming language. The SIK includes everything you need to complete five overarching projects consisting of 16 interconnected circuits that teach everything from blinking an LED to reading sensors. The culminating project is your very own autonomous robot! No previous programming or electronics experience is required to use this kit.The online guide contains step-by-step instructions with circuit diagrams and hookup tables for building each project and circuit with the included parts. Full example code is provided， new concepts and components are explained at point of use， and troubleshooting tips offer assistance if something goes wrong.The kit does not require any soldering and is recommended for beginners ages 10 and up who are looking for an Arduino starter kit. For SIK version 4.1 we took an entirely different approach to teaching embedded electronics. In previous versions of the SIK， each circuit focused on introducing a new piece of technology. With SIK v4.1， components are introduced in the context of the circuit you are building， and each circuit builds upon the last， leading up to a project that incorporates all of the components and concepts introduced throughout the guide. With new parts and a completely new strategy， even if you've used the SIK before， you're in for a brand-new experience!This version of the SIK replaces the SparkFun RedBoard Qwiic with the Arduino Uno(SMD version)and comes without the SIK guidebook and carrying case. With these components being swapped and removed， we were able to reduce the overall size and weight of the kit， making shipping cheaper and easier for anyone ordering internationally.Note：As stated above， this SIK does NOT include a carrying case or print guidebook.Get Started With the SparkFun Inventor's Kit v4.1 Experiment GuideExamplesProject 1：LightCircuit 1A：Blinking an LEDCircuit 1B：PotentiometerCircuit 1C：PhotoresistorCircuit 1D：RGB Night-LightProject 2：SoundCircuit 2A：BuzzerCircuit 2B：Digital TrumpetCircuit 2C："Simon Says" GameProject 3：MotionCircuit 3A：Servo MotorsCircuit 3B：Distance SensorCircuit 3C：Motion AlarmProject 4：DisplayCircuit 4A：LCD "Hello， World!"Circuit 4B：Temperature SensorCircuit 4C："DIY Who Am I?" GameProject 5：RobotCircuit 5A：Motor BasicsCircuit 5B：Remote-Controlled RobotCircuit 5C：Autonomous Robot

DescriptionProduct Restrictions：To access certain features of the ATECC608A， users will need to contact Microchip and sign an NDA contract to obtain the complete datasheet. Due to the required NDA - technical support， an Arduino library， and hookup guide are not provided for users on this product.The SparkFun ATECC608A Cryptographic Co-processor Breakout allows you to add strong security to your IoT node， edge device， or embedded system. This includesasymmetricauthentication，symmetricAES-128 encryption/decryption， and much more. As stated above， the ATECC608A has limited Arduino support and the complete datasheet is under NDA with Microchip.This breakout board includes two Qwiic ports for plug and play functionality. Utilizing our handy Qwiic system， no soldering is required to connect it to the rest of your system. However， we still have broken out 0.1"-spaced pins in case you prefer to use a breadboard. The ATECC608A chip is capable of many cryptographic processes， including， but not limited to：Creating and securely storing unique asymmetric key pairs based on Elliptic Curve Cryptography(FIPS186-3).AES-128：Encrypt/Decrypt， Galois Field Multiply for GCMCreating and verifying 64-byte digital signatures(from 32-bytes of message data).Creating a shared secret key on a public channel via Elliptic Curve Diffie-Hellman Algorithm.SHA-256 HMAC Hash including off-chip context save/restoreInternal high quality FIPS random number generator.Embedded in the chip is a 10Kb EEPROM array that can be used for storing keys， certificates， data， consumption logging， and security configurations. Access to the sections of memory can then be restricted and the configuration locked to prevent changes. Each ATECC608A Breakout ships with a guaranteed unique 72-bit serial number and includes several security features to prevent physical attacks on the device itself， or logical attacks on the data transmitted between the device.A summary datasheet for the ATECC608A is available here. The full datasheet is under NDA with Microchip. You will need to contact them for access to the entire datasheet. Meanwhile， the ArduinoATECCX08 Library currently only supports the ATECC608A with SAMD21 Arduino boards.We do have much more support for the ATECC508A version of this chip. Please check out our ATECC508A Hookup Guide and Arduino Library(which includes six examples). This will get you familiar with the basics of elliptic curve cryptography and signing/verifying data with the ATECC508A version of the chip.Note：The I2C address of the ATECC608A is 0x60 and is software-configurable to any address. A multiplexer/Mux is required to communicate to multiple ATECC608A sensors at the default address when on a single bus. If you need to use more than one ATECC608A sensor at the default address， consider using the Qwiic Mux Breakout.Note：The ATECC608A can be only configured once before it isPERMANENTLYlocked. It is advisable that users purchase multiple boards in order to use other configurations and explore the advanced functions of the ATECC608A.Additionally， this boardIScapable of encrypting and decrypting data. However， to access these additional features， you will need to contact Microchip and sign an NDA contract to obtain the complete datasheet.It is recommended that an SparkFun RedBoard Turbo - SAMD21 Development Board is used with this product due to the buffer size required on the I2C bus.The SparkFun Qwiic Connect System is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.FeaturesOperating Voltage：2.0V-5.5V(Default on Qwiic System：3.3V)Active Current Draw(for ATECC608A)：16 mASleep Current(for ATECC608A)：<150 nAGuaranteed Unique 72-bit Serial Number10 Kb EEPROM Memory for Keys， Certificates， and DataStorage for up to 16 Keys256-bit Key LengthInternal High-Quality FIPS Random Number Generator(RNG)Configurable I2C Address(7-bit)：0x60(Default)

DescriptionThe SparkFun Load Cell Amplifier is a small breakout board for the HX711 IC that allows you to easily read load cells to measure weight. By connecting the amplifier to your microcontroller you will be able to read the changes in the resistance of the load cell， and with some calibration you'll be able to get very accurate weight measurements. This can be handy for creating your own industrial scale， process control or simple presence detection.This version of the SparkFun Load Cell Amplifier features a few changes that you specifically asked for! We have separated the analog and digital supply， as well as added a 3.3uH inductor and a 0.1uF filter capacitor for digital supply. Need even more? Checkout the SparkFun Qwiic Scale. It has all the features of the HX711 but with additional library support， a true I2C interface， and no soldering required!The HX711 uses a two-wire interface(Clock and Data)for communication. Any microcontroller's GPIO pins should work， and numerous libraries have been written， making it easy to read data from the HX711. Check the hookup guide below for more information.Load cells use a four-wire Wheatstone bridge configuration to connect to the HX711. These are commonly colored RED， BLK， WHT， GRN and YLW. Each color corresponds to the conventional color coding of load cells：Red(Excitation+ or VCC)Black(Excitation- or GND)White(Amplifier-， Signal- or Output-)Green(A+， S+ or O+)Yellow(Shield)The YLW pin acts as an optional input that is not hooked up to the strain gauge but is utilized to ground and shield against outside EMI(electromagnetic interference). Please keep in mind that some load cells might have slight variations in color coding.Note：Special thanks to Bodge for supplying the Library for the HX711!Get Started with the HX711 Load Cell Amplifier GuideFeaturesOperation Voltage：2.7V--5VOperation Current：< 1.5mASelectable 10SPS or 80SPS output data rateSimultaneous 50 and 60Hz supply rejection

DescriptionDo you need help soldering a difficult project， reworking a botched pin or just making your life easier? This 10mL no-clean flux pen from Chip Quik(R)is great for all of your solder， desolder， rework and reflow purposes! For those of you unfamiliar， flux is a handy substance that prevents beading of the solder and helps the solder flow cleanly onto the parts you are soldering. This is a must-have tool for any hobbyist's workbench.Each of these flux pens can be used in leaded and lead-free applications and is VOC， halide and rosin free --- making it RoHS II and REACH compliant. Since this is a "no-clean" style flux， you won't have to worry about any sort of conductivity issues associated with it interfering with your board or project. However， it is advisable to still clean whatever you are using this flux pen on with basic isopropyl alcohol(IPA)， because a clean board is a happy board!Note：It isn't recommended to use this flux with solder that has a water-soluble or rosin flux core in scenarios that require your boards operate at a high reliability rate. At a hobbyist level you should have no issues.FeaturesFlux Type：No-Clean Liquid Flux(for leaded and lead-free applications)Flux Classification：INM0Packaging：10mL PenShelf Life：Refrigerated >24 months； Unrefrigerated >24 months

DescriptionGet with the times， already! This SparkFun Real Time Clock(RTC)Module is a Qwiic-enabled breakout board for the RV-1805 chipset. The RTC is ultra-low power(running at only about 22nA in its lowest power setting)so it can use a supercapacitor for backup power instead of a normal battery. This means you get plenty of charge and discharge cycles without any degradation to the "battery." To make it even easier to get your readings， all communication is enacted exclusively via I2C， utilizing our handy Qwiic system so no soldering is required to connect it to the rest of your system. However， we still have broken out 0.1"-spaced pins in case you prefer to use a breadboard.This RTC module's built in RV-1805 has not one， but two internal oscillators：a 32.768kHz tuning fork crystal and a low power RC based oscillator and can automatically switch between the two using the more precise crystal to correct the RC oscillator every few minutes. This feature allows the module to maintain a very accurate date and time with the worst case being +/- about three minutes over a year. The RV-1805 also has a built in trickle charger so as soon as the RTC is connected to power the it will be fully charged in under 10 minutes and has the ability to switch power to other systems allowing it to directly turn on or off a power hungry device such as a microcontroller or RF engine.There is also the option to add a battery to the board if the supercapacitor just isn't going keep your project powered long enough(keep in mind， the supercap can hypothetically make the board keep time for around 35 days)， you can solder on an external battery. That means you can let board sit with no power or connection to the outside world and the current hour/minute/second/date will be maintained.Note：The I2C address of the RV-1805 is 0x69 and is hardware defined. A multiplexer/Mux is required to communicate to multiple RV-1805 sensors on a single bus. If you need to use more than one RV-1805 sensor consider using the Qwiic Mux Breakout.The SparkFun Qwiic connect system is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.Get Started with the RV-1805 Real Time Clock Module GuideFeaturesOperating Voltage(Startup)：1.6V - 3.6VOperating Voltage(Timekeeping)：1.5V - 3.6VOperating Temperature：-40℃ - 85℃Time Accuracy：±2.0 ppmCurrent Consumption：22nA(Typ.)I2C Address：0xD2Supercapacitor for Backup Power2x Internal Oscillators2x Qwiic Connectors
