「llu」の検索結果

DescriptionThe Raspberry Pi Zero Case has been designed to fit both the Pi Zero and the Pi Zero W. These official cases consist of several parts and protect the Raspberry Pi Zero from things like rogue wires that might short it out while still allowing full access to the board. Simply snap the RPi into the bottom half of the enclosure， then snap on a desired top. No tools required!Each case has a standard base featuring a cut-out to allow access to the GPIO， and a choice of three lids：a standard lid， a GPIO lid(allowing access to the GPIO pins from above)and a camera lid(which， when used with the short camera cable supplied， allows the Raspberry Pi camera to be fitted neatly inside it). Additionally， each case includes a 4cm long CSI cable and four rubber feet.Note：This case doesNOTinclude a Raspberry Pi or Camera Module.

DescriptionThe SparkFun LP55231 LED Driver Breakout is a self-contained solution for developing and deploying the nine-channel I2C LED controller. Remarkably simple， the breakout is equipped primarily with just the LP55231 LED controller IC， plus thr

DescriptionRotary encoders can be used similarly to potentiometers. The difference being that an encoder has full rotation without limits(It just goes round and round). They output gray code so that you can tell how much and in which direction the encoder has been turned. They're great for navigating menu screens and things like that.This encoder is especially cool because it has a common anode RGB LED built in， as well as a push-button. This version has an updated material that is heat resistant and slightly changed dimensions， but should still work well with our rotary encoder breakout board.FeaturesSwitch Travel：0.5mmShaft Diameter：6.0mmShaft Length：18mmVertical Through-Hole Mount24 Pulses per RotationRed/Green/Blue LEDPushbutton

DescriptionThe Hologram eUICC SIM Card is a mix between legacy and new technology when cellular service is needed your project. This eUICC SIM Card enables profile switching capabilities so you can dynamically change the subscriber profile while your chosen devices are in the field， over-the-air. For those looking for IoT cellular service with no intentions on switching cellular carriers， this SIM card is for you.eUICC features are limited to certain modules at this point. This includes the u-blox SARA-R4 module used on our SparkFun LTE CAT M1/NB-IoT Shield - SARA-R4. For these situations， the functionality will be that of a normal SIM with cellular service through Hologram. You won't be able to change carriers.FeaturesTemperature Range：-25C to 85CNano SIM 8.8mm x 12.3mmMinimum 500，000 Read/write cyclesMinimum 25 yrs at 25℃ Data retention

DescriptionThis is a 50mm long 4-conductor cable with 1mm JST termination. It's designed to connect Qwiic enabled components together but can be used for other applications as well. The cable insulation is made from a highly malleable material making it more flexible than our original Qwiic cable particularly in tight spaces or enclosures.Each Qwiic Cable's wires have been color coded to red， black， blue and yellow.The SparkFun Qwiic connect system is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.FeaturesDimensions：50mm(1.96")Length

DescriptionThis sealed digital temperature probe lets you precisely measure temperatures in wet environments with a simple 1-Wire interface. The DS18B20 provides 9 to 12-bit(configurable)temperature readings over a 1-Wire interface， so that only one wire(and ground)needs to be connected from a central microprocessor. Power for reading， writing， and performing temperature conversions can be derived from the data line itself with no need for an external power source.Because each DS18B20 contains a unique silicon serial number， multiple DS18B20s can exist on the same 1-Wire bus. This allows for placing temperature sensors in many different places. Applications where this feature is useful include HVAC environmental controls， sensing temperatures inside buildings， equipment or machinery， and process monitoring and control.Note：The pinout for this sensor is as follows：RED=Vcc BLACK=GND WHITE=SIGFeatures3.0-5.5V input voltage-55℃ to +125℃ temperature range±0.5℃ accuracy from -10℃ to +85℃Waterproof1 Wire interfaceProbe is 7mm in diameter and roughly 26mm long. Overall length(including wire)is 6 feet.Thermometer resolution is programmable from 9 to 12 bits.Electrical performance：no flicker or breakdown within AC 1200V/1S ，within DC 500V theinsulation resistance shall be greater than 100MΩ

DescriptionLIDAR has never looked so good! This is the LIDAR-Lite v3HP， a compact， high-performance optical distance measurement sensor from Garmin(TM). The LIDAR-Lite v3HP istheideal optical ranging solution for drone， robot， or unmanned vehicle applications. Each sensor is housed in a durable， IPX7-rated housing and includes all the core features and user configurability of the popular LIDAR-Lite v3.The v3HP is very similar in function to that of the v3 but it can now sample faster at rates greater than 1kHz(where as the v3 is only capable of up to 500Hz). Another improvement is that this v3HP model is more power efficient with current consumption rates 40mA less than the v3(that's 65mA as opposed to 105mA while idle， and 85mA instead of 130mA while acquiring).Each LIDAR-Lite v3HP has a range of 1m to 40m and features an edge-emitting， 905nm(1.3 watts)， single-stripe laser transmitter， 8m Radian beam divergence， and an optical aperture of 12.5mm. This version of the LIDAR-Lite still operates at 5VDC(6V max)with a peak power of 1.3W and still possesses an accuracy of +/- 2.5cm at >2m. On top of everything else， the LIDAR-Lite is user-configurable， allowing adjustment between accuracy， operating range and measurement time and can be interfaced via I2C or PWM with the attached 200mm cable.Note：CLASS 1 LASER PRODUCT CLASSIFIED EN/IEC 60825-1 2014. This product is in conformity with performance standards for laser products under 21 CFR 1040， except with respect to those characteristics authorized by Variance Number FDA-2016-V-2943 effective September 27， 2016.Get Started with the LIDAR-Lite v3HP GuideFeaturesResolution：1 cmTypical accuracy：+/- 2.5cm at distances greater than 2 meters(Refer to operating manual for complete operating specifications)Range：1m to 40mUpdate rate：Greater than 1kHzInterface：I2C or PWMPower(operating voltage)：4.75-5VDC； 6V MaxCurrent consumption：65ma idle； 85ma during acquisitionOperating temperature：-20℃ to 60℃Laser wave length/Peak power：905nm/1.3WBeam divergence：8m RadianOptical aperture：12.5mmWater rating：IPX7Unit dimensions：24.5mm×53.5mm×33.5mm(1.0in×2.1in×1.3in)Weight：34g(1.2oz)

DescriptionThe SparkFun NEO-M9N GPS Breakout is a high quality GPS board with equally impressive configuration options including SMA. The NEO-M9N module is a 92-channel u-blox M9 engine GNSS receiver， meaning it can receive signals from the GPS， GLONASS， Galileo， and BeiDou constellations with ～1.5 meter accuracy. This breakout supports concurrent reception of four GNSS. This maximizes position accuracy in challenging conditions increasing， precision and decreases lock time； and thanks to the onboard rechargeable battery， you'll have backup power enabling the GPS to get a hot lock within seconds! Additionally， this u-blox receiver supports I2C(u-blox calls this Display Data Channel)which makes it perfect for the Qwiic compatibility so we don't have to use up our precious UART ports. Utilizing our handy Qwiic system， no soldering is required to connect it to the rest of your system. However， we still have broken out 0.1"-spaced pins in case you prefer to use a breadboard.The NEO-M9N module detects jamming and spoofing events and can report them to the host， so that the system can react to such events. A SAW(Surface Acoustic Wave)filter combined with an LNA(Low Noise Amplifier)in the RF path is integrated into the NEO-M9N module which allows normal operation even under strong RF interferences.U-blox based GPS products are configurable using the popular， but dense， windows program called u-center. Plenty of different functions can be configured on the NEO-M9N：baud rates， update rates， geofencing， spoofing detection， external interrupts， SBAS/D-GPS， etc. All of this can be done within the SparkFun Arduino Library!The SparkFun NEO-M9N GPS Breakout is also equipped with an on-board rechargeable battery that provides power to the RTC on the NEO-M9N. This reduces the time-to-first fix from a cold start(～24s)to a hot start(～2s). The battery will maintain RTC and GNSS orbit data without being connected to power for plenty of time.This product requires an antenna：Be sure to check out the related products/hookup accessories and pick a suitable SMA antenna for your project.The SparkFun Qwiic Connect System is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.The NEO-M9N GPS Breakout can also be automatically detected， scanned， configured， and logged using the OpenLog Artemis datalogger system. No programming， soldering， or setup required!Get Started With the SparkFun NEO-M9N GPS GuideFeaturesIntegrated SMA connector for use with antenna of your choice92-Channel GNSS Receiver1.5m Horizontal Accuracy25Hz Max Update Rate(four concurrent GNSS)Time-To-First-Fix：Cold：24sHot：2sMax Altitude：80，000mMax G：≦4Max Velocity：500m/sVelocity Accuracy：0.05m/sHeading Accuracy：0.3 degreesTime Pulse Accuracy：30ns3.3V VCC and I/OCurrent Consumption：～31mA Tracking GPS+GLONASSSoftware ConfigurableGeofencingOdometerSpoofing DetectionExternal InterruptPin ControlLow Power ModeMany others!Supports NMEA， UBX， and RTCM protocols over UART or I2C interfaces

DescriptionThe full-color LilyPad Sewable Electronics Kit Guidebook contains step-by-step instructions for creating four interactive projects from the materials contained in the kit. Examples and circuits are provided and explained. The manual also includes a glossary and troubleshooting tips. Once you make your way through all of the projects， you will have a much better grasp on e-textiles!Note：This is just the manual for the LilyPad Sewable Electronics Kit. The kit itself or the individual parts used in this book will need to be purchased separately.ExamplesProject 1：Glowing PinProject 2：Illuminated MaskProject 3：Light-Up PlushProject 4：Night-Light Pennant

DescriptionThe SparkFun LTE CAT M1/NB-IoT Shield equips your Arduino or Arduino-compatible microcontroller with access to data networks across the globe. This shield adds wireless， high-bandwidth cellular functionality to your IoT project while maintaining low power consumption and small footprint. The SparkFun LTE CAT M1/NB-IoT Shield is based off the Arduino R3's footprint that allows you to easily incorporate it with favorite Arduino-based device.At the heart of the LTE Cat M1/NB-IoT shield is u-blox SARA-R410M-02B LTE Cat M1/NB-IoT modem. Cat M1(Category M1)and NB-IoT(Narrowband IoT)are both Low Power Wide Area Network(LPWAN)technologies that are designed to provide cellular communication to small IoT devices. They operate on LTE network bands just like most smartphones， and should be supported by most cellular network carriers. The u-blox SARA-R4 module communicates over UART via simple AT command set. We've provided library to help you get started with everything from sending SMS text messages to communicating with servers over TCP/IP connection. Additionally， both the module and library support an I2C GPS interface via Qwiic connector， so you can plug in u-blox GPS module and start remotely tracking your project.Each SparkFun LTE CAT M1/NB-IoT Shield also includes ceramic， Molex 1462000001 SMD antenna. The antenna has gain of 3.8dBi around 1.7GHz to 2.7GHz. However， if you would prefer to use an external antenna， we have provided U.FL connector that can be utilized by simply slicing through jumper with hobby knife.Please be aware that there are few extra parts required to get this shield fully functioning， other than an Arduino-based device. First， you'll need to supply your own SIM card， such as this one from Hologram(we do also offer this shield with an included one as well)and your own headers which will need to be soldered on.Note：Be sure to check theHardware Overviewsection in the Hookup Guide for compatible GPS modules. The onboard Qwiic connector is only designed to support u-blox-based GPS modules. It does not support any other GPS modules or sensors. We are continuing to add more modules so be sure to check back every so often to find out more!Need custom board?This component can be found in SparkFun's La Carte board builder. You can have custom design fabricated with this component and your choice of hundreds of other sensors， actuators and wireless devices delivered to you in just few weeks.Get Started with the SparkFun LTE CAT M1/NB-IoT Shield GuideDocumentsSchematicEagle FilesHookup GuideDatasheetsSARA-R4Ceramic AntennaSARA-R4 AT Command SetArduino LibraryGitHub

DescriptionAdd another eight pins to your microcontroller using a MCP23008 port expander. The MCP23008 uses two I2C pins which can be shared with other I2C devices， and in exchange gives you eight general purpose pins. You can set each of eight pins to be input， output， or input with a pullup. There's even the ability to get an interrupt via an external pin when any of the inputs change so you don't have to keep polling the chip.Use this chip from 2.7-5.5V(good for any 3.3V or 5V setup)， and you can sink/source up to 20mA from any of the I/O pins so this will work for LEDs and such. Team it up with a high-power MOSFET if you need more juice. DIP package means it will plug into any breadboard or perfboard.You can set the I2C address by tying the ADDR0-2 pins to power or ground， for up to eight unique addresses. That means eight chips can share a single I2C bus - that's 64 I/O pins!Features8-bit remote bidirectional I/O portHigh-speed I2C interface(MCP23008)Hardware address pinsConfigurable interrupt output pinConfigurable interrupt sourcePolarity Inversion register for input port data polarity config.External reset inputLow standby current：1 μA(max.)・ Operating voltage：1.8V to 5.5V @ -40℃ to +85℃ I2C @ 100 kHz SPI @ 5 MHz2.7V to 5.5V @ -40℃ to +85℃ I2C @ 400 kHz SPI @ 10 MHz4.5V to 5.5V @ -40℃ to +125℃ I2C @ 1.7 kHz SPI @ 10 MHz

DescriptionThe SparkFun MicroMod Update Tool is built to interface with the MicroMod Asset Tracker Carrier Board and also makes it simple to communicate directly with the u-blox SARA-R510M8S module using u-blox's sophisticated m-center cellular evaluation software. If you're familiar with u-center， u-blox's GNSS evaluation software， you'll know how excellent their software is. m-center is every bit as good. Attach a USB-C cable and away you go!The Update Tool is not a full MicroMod Processor Board， it is much simpler than that. It has a CH340C USB-Serial converter on it which gives you full access to all eight pins of the SARA-R5's UART interface via the Asset Tracker's USB-C connector. Think of it as a bridge from USB to serial.The Update Tool features eight pairs of Plated Through Hole connections for the UART signals. You can use these to connect directly to the SARA UART using 3.3V signals if you want to. The split pads on the rear of the Tool can be opened to isolate the CH340C completely； the pins nearest the M.2 will link straight to the SARA UART.Get Started with the MicroMod Update Tool Hookup GuideFeaturesCH340C USB-Serial converterEight pairs of Plated Through Hole connections with split pad jumper links for：Serial Transmit(TX)Serial Receive(RX)Request To Send(RTS)Clear To Send(CTS)Data Terminal Ready(DTR)Data Set Ready(DSR)Ring Indicator(RI)Data Carrier Detect(DCD)LED indicator for：Power(3.3V)

DescriptionThe LilyPad Sewable Electronics Kit lets you explore the wonderful world of electronic sewing(e-sewing)and e-textiles through a series of introductory projects using the LilyPad system. You'll learn how to sew basic circuits to light up LEDs， control them with buttons and switches and even experiment with a pre-programmed LilyMini circuit that reacts to ambient light levels. In addition to LilyPad LEDs and battery holders， the kit comes with two LilyPad ProtoSnap boards that let you explore the circuit before you sew the pieces into a project.The full-color LilyPad Sewable Electronics Kit Guide(included)contains step-by-step instructions for using LilyPad pieces to create four complete sewable circuit projects with conductive thread. Easy-to-follow diagrams and troubleshooting tips make this a great introductory resource for crafters and creatives.LilyPad is a wearable technology developed by Dr. Leah Buechley and cooperatively designed by Dr. Buechley and SparkFun. Each LilyPad component was creatively constructed with large sew tabs to allow for stitching into clothing. Various input， output， power and sensor boards are available. They're even washable!Note：A portion of this sale is given back to Dr. Buechley for continued development and education in e-textiles.Note：Due to the requirements of shipping the batteries in this kit， orders may take longer to process and therefore do not qualify for same-day shipping. Additionally， these batteries can not be shipped via Ground or Economy methods to Alaska or Hawaii. Sorry for any inconvenience this may cause.ExamplesSewable Electronics Projects：Project 1：Glowing PinProject 2：Illuminated MaskProject 3：Light-Up PlushProject 4：Night-Light Pennant

DescriptionThe SparkFun 2D Barcode Scanner Breakout is a nifty little breakout board featuring the DE2120 barcode scanner module from DYScan. The DE2120 reads 20 different barcode symbologies(both 1D and 2D)using a camera coupled with on-board image processing to identify and decode everything from UPC codes to QR codes. The module also features two LEDs：one for illumination and one to project the red line that you're used to seeing from laser-based scanners.This breakout board makes it easy to explore all of the capabilities of the DE2120 without dealing with finicky flat flex cables. The scanner's USB interface is exposed via the on-board USB-C connector. A buzzer and status LED are connected to the module through appropriate drive circuits and a push button tactile switch is provided on the "trigger" pin. When you're ready to incorporate the module into your embedded project， you can leverage the 5 pin header for direct access to the TTL serial pins， power pins， and trigger input.The module can be configured either by using the serial interface or by scanning command barcodes found in the Settings Manual.All keyboard， HID， and serial can be transmitted over the single USB-C connector. The DE2120 has the unique ability to enumerate all three protocols including a CDC serial driver so the device appears as a standard COM port.Get Started with the 2D Barcode Scanner Breakout Hookup GuideFeaturesUSB-C Connector for USB HID Interface and Virtual COM portReads 20 different symbologies1D SymbologiesUPC-AUPC-EEAN-8EAN-13Code 128GS1-128Code 39Code 93Code 11Interleaved 2-of-5Matrix 2-of-5Industrial 2-of-5CodabarMSIGS1 DataBarDatalogic 2-of-52D SymbologiesQR CodeData MatrixPDF 417Micro PDF 417Aztec Code

DescriptionThe SparkFun Line Follower Array is a long board consisting of eight IR sensors that have been configured to read as digital bits! We have designed the SparkFun Line Follower Arrays to follow a dark line of about 3/4 inch width or smaller(spray paint or electrical tape)on a light background. Each array features visible LEDs that point upward when the board is attached(properly)so you can see what the robot sees， brightness control right on the board， and an I2C interface for reading and power control. Here at SparkFun， the RedBot Shadow Chassis was used as a test platform but really this was designed as an add-on for almost any bot.The line follower functions by taking an 8-bit reading of reflectance for use with following lines or reading dark/light patterns and can see from about 1/4 to 3/4 inches away. The IR brightness control and indicator can be adjusted with the on-board potentiometer and is capable of showing you the strength of the IR LEDs. Illumination can be turned on and off with software to conserve power， or left on all the time for faster readings. The SparkFun Line Follower Array requires 5V of power with a supply current range of 25-185mA with strobing disabled and 16-160mA with it enabled. Additionally we have added six mounting holes to the line follower with the two inner holes designed to fit our Shadow Chassis while the other four are general purpose.Note：As you know our Sun emits quite a bit of infrared light， making the SparkFun Line Follower Array much less effective in direct sunlight. Plan your projects accordingly!Features8 sensor eyes(QRE1113， like in our line sensor breakout)I2C interfaceAdjust IR brightness on the fly with a knobSwitch IR on and off with softwareSwitch visual indicators on and off with softwareInvert dark/light sight with softwareBased on the SX1509 I/O expander

DescriptionThe SparkFun AS7263 Near Infrared(NIR)Spectral Sensor Breakout brings spectroscopy to the palm of your hand， making it easier than ever to measure and characterize how different materials absorb and reflect different wavelengths of light. The AS7263 Breakout is unique in its ability to communicate by both an I2C interface and serial interface using AT commands. Hookup is easy， thanks to the Qwiic connectors attached to the board --- simply plug one end of the Qwiic cable into the breakout and the other into one of the Qwiic shields， then stack the board on a development board. You'll be ready to upload a sketch to start taking spectroscopy measurements in no time.The AS7263 spectrometer detects wavelengths in the visible range at 610， 680， 730， 760， 810 and 860nm of light， each with 20nm of full-width half-max detection. The board also has multiple ways for you to illuminate objects that you will try to measure for a more accurate spectroscopy reading. There is an onboard LED that has been picked out specifically for this task， as well as two pins to solder your own LED into.Note：The I2C address of the AS7263 is 0x49 and is hardware defined. A multiplexer/Mux is required to communicate to multiple AS7263 sensors on a single bus. If you need to use more than one AS7263 sensor consider using the Qwiic Mux Breakout.The SparkFun Qwiic Connect System is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.Get Started with the SparkFun AS726X Spectral Sensor Breakout GuideFeatures6 near-IR channels：610nm， 680nm， 730nm， 760nm， 810nm and 860nm， each with 20nm FWHMNIR filter set realized by silicon interference filters16-bit ADC with digital accessProgrammable LED drivers2.7V to 3.6V with I2C interface2x Qwiic connectors

DescriptionThe SparkFun RTK Surveyor is an easy to use GNSS receiver for centimeter-level positioning. Perfect for surveying， this preprogrammed device can also be used for autonomous driving， navigation， asset tracking and any other application where there is a clear view of the sky. The RTK Surveyor can also be used as a base station. With the flick of a switch， two RTK Surveyors can be used to create an RTK system capable of 14mm horizontal positional accuracy. The built-in Bluetooth(R)connection via an ESP32 WROOM enables the user to use the RTK Surveyor with their choice of GIS application on a phone or tablet. The built in battery allows field use for up to four hours and is compatible with common USB battery banks.This device can be used in four modes：GNSS Positioning(～30cm accuracy)GNSS Positioning with RTK(1.4cm accuracy)GNSS Base StationGNSS Base Station NTRIP ServerIn Position mode the device receives L1/L2 signals from a user-provided antenna and the high-grade GNSS receiver provides lat/long and altitude with accuracies around 300mm.In Positioning with RTK mode the device receives L1/L2 signals from the antenna and correction data from a base station. The correction data can be obtained from a cellular link to online correction sources or over a radio link to a 2nd RTK Surveyor setup as a base station.In Base Station mode the device is mounted to a temporary position(like a tripod)and begins transmitting correction data over a radio or internet connection. A base is often used in conjunction with a second unit set to 'Positioning with RTK' to obtain the 14mm relative accuracy.In Base Station NTRIP Server mode the device is mounted to a semi or permanently fixed position(like a roof)and connects over WiFi to transmit the correction data to a NTRIP caster so that any rover can access the correction data over a cellular or internet connection. This type of base is a very easy way to setup a very precise absolute correction source.Two cables are provided with the RTK Surveyor allowing a user to plug on our easy to use Serial Telemetry Radios or their own radio link. If a local correction source is within 10km， a user can also use their phone to provide correction data over the Bluetooth(R)link(no external radio needed!).Note：The SparkFun RTK Surveyor is just the enclosed device and does NOT include an antenna， serial telemetry radio， or associated mounting pieces. These items will need to be purchased separately from the Hookup Accessories below.Get Started With the SparkFun RTK Surveyor GuideFeaturesGNSS Receiver：ZED-F9PConcurrent reception of GPS， GLONASS， Galileo and BeiDouReceives both L1C/A and L2C bandsCurrent：68mA - 130mA(varies with constellations and tracking state)Time to First Fix：25s(cold)， 2s(hot)Max Navigation Rate：PVT(basic location over UBX binary protocol)- 25HzRTK - 20HzRaw - 25HzHorizontal Position Accuracy：2.5m without RTK0.010m with RTKMax Altitude：50km(31 miles)Max Velocity：500m/s(1118mph)Bluetooth(R)Transceiver：ESP32 WROOMXtensa(R)dual-core 32-bit LX6 microprocessorUp to 240MHz clock frequency16MB of flash storage520kB internal SRAMIntegrated 802.11 BGN WiFi transceiverIntegrated dual-mode Bluetooth(R)(classic and BLE)Hardware accelerated encryption(AES， SHA2， ECC， RSA-4096)2.5 μA deep sleep currentOverall DeviceInternal Battery：LiPo 1000mAh with 500mA chargingRadio Port：3.3V TTL Serial(57600bps RTCM TX/RX)Data Port：3.3V TTL Serial(115200bps NMEA)Weight：132g(entire device including battery)Dimensions：118mm×79mm×30mm(4.7in×3.1in×1.2in)1x Qwiic Connector1x microSD Socket for optional loggingChanges：This version(which replaces SPX-17369)uses a reinforced edge mount SMA connector for better resiliency when a fixed 'stub' antenna is used.

DescriptionNote - Please read before purchasing!：The SparkFun LTE GNSS Breakout - SARA-R5 uses the "00B" product version of the SARA-R5 module(specifically the SARA-R510M8S-00B-00). LTE NB-IoT Radio Access Technology， and the LTE FDD bands：66， 71， 85 are not supported by this version. Refer to the SARA-R5 datasheet for more information.The SparkFun SARA-R5 LTE GNSS Breakout is a robust development tool for u-blox's impressive SARA-R510M8S module. The SARA-R510M8S combines u-blox's UBX-R5 cellular chipset with their M8 GNSS receiver chipset to provide a 5G-Ready wireless IoT device complete with positioning data all on a single chip. As an asset tracker， the LTE GNSS Breakout offers Secure Cloud LTE-M communication for multi-regional use and has an integrated u-blox M8 GNSS receiver for accurate positioning information.The UBX-R5 chipset supports many different forms of data communication from full TCP/IP sockets and packet switched data， through HTTP Get/Put/Post， FTP(the SARA has a built-in file system)， Ping， to good old SMS text messaging! The built-in u-blox M8 GNSS receiver provides accurate and reliable positioning with a separate GNSS antenna interface for an external antenna. Both the GNSS antenna and LTE connections are made via a pair of SMA connectors.This breakout routes nearly all of the functional pins on the SARA-R510M8S module to user interfaces(USB or plated-through hole)so you can take full advantage of all of the features available on this impressive LTE/GNSS module. The SARA-R5's UART interface can be configured into one of five variants， providing connectivity over one or two UARTs. A separate USB port provides access to the SARA's trace log for diagnostic purposes. This breakout provides access to all three interfaces(UART1， UART2 and SARA Diag)via three separate USB-C connections. All eight 3.3V serial signals are available on a 0.1"-pitch breakout header. Separate 0.1"-pitch headers break out the SARA's I2C bus， power pins as well as GPIO pins for various functionalities.Get Started with the SARA-R5 LTE GNSS Breakout GuideFeaturesu-blox SARA-R510M8S module providing Secure Cloud LTE-M data communication for multi-regional usePlease check that your service provider offers LTE-M coverage for your area before purchasingIntegrated u-blox M8 GNSS receiver for accurate positioning informationNano SIM socketSeparate， robust SMA connections for LTE and GNSS antennasSwitchable 3.3V power for an active GNSS antennaUSB-C connectivityLED indicators for：Power(VIN and 3.3V)SARA-R5 onNetwork indicatorGNSS timing pulse(1PPS)3.3V plated through-hole(PTH)pins for：SARA onNetwork indicatorUART1GNSS timing pulse(1PPS)I2C bus

DescriptionIf you'd like to use a larger tool in your Nomad， this collet and nut will let you use tools with a .25" shank. The extra collet nut included will let you quickly switch between collets without having to remove them from the collet nut.

DescriptionIf you have ever wanted to get into FPGAs but never knew where to begin， the Alchitry Au FPGA kit from SparkFun provides you with the boards you need to get started! Included in this kit is the Alchitry Au， Alchitry Io Element， Alchitry Br Prototype， and a 4-pack of female headers. The only thing you'll need to supply are a USB-C cable to power and program the Au and Qwiic cables to add I2C accessory integration.The Alchitry Au， included in this kit， features a Xilinx Artix 7 XC7A35T-1C FPGA with over 33，000 logic cells and 256MB of DDR3 RAM. The Au offers 102 3.3V logic level IO pins， 20 of which can be switched to 1.8V； Nine differential analog inputs； Eight general purpose LEDs； a 100MHz on-board clock that can be manipulated internally by the FPGA； a USB-C connector to configure and power the board； and a USB to serial interface for data transfer. To make getting started even easier， all Alchitry boards have full Lucid support， a built in library of useful components to use in your project， and a debugger!Thanks to the included Io and Br Element boards also included in this kit， you will also have access to 7-segment LEDs， five momentary push buttons， 24 basic LEDs， and 24 DIP switches， a the broken out header pins， and a large prototyping area!Get Started with our Learning FPGA TutorialsExamplesFirst FPGA Project - Getting Fancy with PWMExternal IO and Metastability

DescriptionThis is a two pack of Zrn coated flat mills from Carbide 3D that are perfect for fabricating with aluminum. Each mill in this pack features a cutting and shank diameter of 0.25 inches and a cutting length of 0.75 inches. These cutters really are great for precision 3D machining and fabrication.These cutters are coated with Zirconium Nitride(Zrn). This is a specialty coating which makes it most suitable for temperature sensative materials. ZrN had excellent corrosion-resistance， lubricity and hardness to suit many applications. This coating has a unique ability to reduce the build-up edge on cutting tools which results in a better surface finish. ZrN works well for machining Titanium and Aluminum Alloys， Nickel， Brass， Copper， Cast Iron and Zinc. Each cutter is made of solid carbide to ensure long lasting use.FeaturesCutting Diameter：0.25"Cutting Length：0.75"Shank Diameter：0.25"3 Flute， center cutting2.5" Overall Length

DescriptionThe SparkFun Qwiic SHIM for Raspberry Pi is a small， easily removable breakout that easily adds a Qwiic connector to your Raspberry Pi. The SHIM design allows you to plug directly to the Pi's I2C bus with no soldering required and the thin

DescriptionThis straight bar load cell(sometimes called a strain gauge)can translate up to 5kg of pressure(force)into an electrical signal. Each load cell is able to measure the electrical resistance that changes in response to， and proportional of， the strain(e.g. pressure or force)applied to the bar. With this gauge you will be able to tell just how heavy an object is， if an object's weight changes over time， or if you simply need to sense the presence of an object by measuring strain or load applied to a surface.Each straight bar load cell is made from an aluminum-alloy and is capable of reading a capacity of 5kg. These load cells have four strain gauges that are hooked up in a wheatstone bridge formation. The color code on the wiring is as follows：red = Exc+， green = Sig+， black = Exc-， and white = Sig-. Additionally， these load cells offer an IP65 protection rating and features two M5 sized through-holes for mounting purposes.Get Started with the Load Cell GuideFeaturesCapacity：5kgMaterial：Aluminum-AlloyParallel Beam TypeIP65 Rating55mm×12.7mm×12.7mm， 200mm Wire

DescriptionThis miniature straight bar load cell(sometimes called a strain gauge)can translate up to 100g of pressure(force)into an electrical signal. Each load cell is able to measure the electrical resistance that changes in response to， and proportional of， the strain(e.g. pressure or force)applied to the bar. With this gauge you will be able to tell just how heavy an object is， if an object's weight changes over time， or if you simply need to sense the presence of an object by measuring strain or load applied to a surface.Each straight bar load cell is made from an aluminum-alloy and is capable of reading a capacity of 100g. These load cells have four strain gauges that are hooked up in a wheatstone bridge formation. The color code on the wiring is as follows：red = Exc+， green = Sig+， black = Exc-， and white = Sig-. Additionally， these load cells offer an IP65 protection rating and features four M3 sized through-holes for mounting purposes.Get Started with the Load Cell GuideFeaturesCapacity：100gMaterial：Aluminum-AlloyParallel Beam TypeIP65 Rating47mm×12mm×6mm， 110mm Wire

DescriptionThese flat mills are perfect for roughing or machining flat or prismatic parts.If you've got a Nomad or Shapeoko， these are great cutters for cutting plastic and aluminum.All of our cutters are manufactured here in the US and begin

DescriptionThese coated flat endmills are perfect for cutting aluminum. They have a ZrN coating which provides a better finish， longer lifespan， and a superior cut compared to a non-coated endmill.This cutter has a shorter flute length to provide

DescriptionTRRS connectors are the audio-style connectors that you see on some phones， MP3 players and development boards. TRRS stands for "Tip， Ring， Ring， Sleeve，" which reflects the fact that， unlike a standard stereo connector， this actually has three conductors and a ground. Some devices use the extra conductor for a microphone(like hands-free headsets)or to carry a video signal(like in some MP3/MP4 players). If you're hacking on something that has a 4-conductor audio jack， being able to plug straight in will keep your build clean and simple.Note：This plug allows you to add a custom length of wire to your connector or repair a broken shroud on an existing cable you just cannot live without. Unfortunately， the supplier has not provided a datasheet or dimensional drawing please see the similar documents provided by other SparkFun products on the "documents" tab.

DescriptionThe SparkFun Qwiic Connect System is constantly growing in popularity with makers. So to make it even easier to get started， we've assembled this Qwiic Cable Kit for everyone. If you aren't sure which Qwiic cable to use， this handy box includes all of them allowing you to save a little money and time! It has a little something for everyone.The SparkFun Qwiic Cable Kit includes 10 cables of various lengths and styles that will get your Qwiic boards connected together， to a development platform， or to a breadboard. Each Qwiic Cable's wires have been color coded to red， black， blue and yellow with 1mm JST termination.The SparkFun Qwiic connect system is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.

DescriptionYou don't have to worry about adding a resistor to an LED if you get an LED with a built in resistor! This pack of 25 blue 5mm LEDs will help alleviate any frustrations you've had with accidentally burning them out by having a resistor in t

DescriptionThis is a two pack of Zrn coated flat mills from Carbide 3D that are perfect for fabricating with aluminum. Each mill in this pack features a cutting and shank diameter of 0.125 inches and a cutting length of 0.5 inches. These cutters reall

DescriptionThe Raspberry Pi 4 Hardware Starter Kit provides a solid set of parts and instruction for working with the Raspberry Pi 4 in a more hardware-centric manner. While the Raspberry Pi isn't typically considered a go-to for hardware projects， its I/O pins hold a lot of benefits that you can use for a variety of applications. This kit covers the basics like using LEDs， and Buttons while providing a solid set of parts for working with any other hardware I/O and the 40-pin header. In addition， we've included all the parts needed for getting the Raspberry Pi 4 up and running whether it's on its own， or using a monitor(not included). The new 64GB MicroSD cards keep read/write commands running super fast， too.Most of the contents of the kit rely on the use of the 2x20， 40-pin header， so we've included a special extender to allow you to plug in the ribbon cable while using the provided heatsink case. We've also included a Qwiic Shim for easily working with I2C based Qwiic boards with the Pi. No soldering is required for this kit!Note：This variation includes the 4GB RAM option for the Raspberry Pi 4.Get Started with the Raspberry Pi 4 Model B Guide

DescriptionThe Raspberry Pi 4 Hardware Starter Kit provides a solid set of parts and instruction for working with the Raspberry Pi 4 in a more hardware-centric manner. While the Raspberry Pi isn't typically considered a go-to for hardware projects， its I/O pins hold a lot of benefits that you can use for a variety of applications. This kit covers the basics like using LEDs， and Buttons while providing a solid set of parts for working with any other hardware I/O and the 40-pin header. In addition， we've included all the parts needed for getting the Raspberry Pi 4 up and running whether it's on its own， or using a monitor(not included). The new 64GB MicroSD cards keep read/write commands running super fast， too.Most of the contents of the kit rely on the use of the 2x20， 40-pin header， so we've included a special extender to allow you to plug in the ribbon cable while using the provided heatsink case. We've also included a Qwiic Shim for easily working with I2C based Qwiic boards with the Pi. No soldering is required for this kit!Note：This variation includes the 8GB RAM option for the Raspberry Pi 4.Get Started with the Raspberry Pi 4 Model B Guide

DescriptionThe SparkFun Qwiic pHAT Extension for the Raspberry Pi 400 provides you with a quick and easy solution to access all of the 400's GPIO， stack your favorite HAT right-side up， or connect a Qwiic-enabled device to the I2C bus(GND， 3.3V， SDA

DescriptionDo you own micro：bit or micro：bit Go Bundle and want to expand your skills with the new microcontroller? You are in luck! The SparkFun Inventor's Kit Bridge Pack for micro：bit was designed to provide you with an easy way to transform your m：b into full fledged learning kit! Each Bridge Pack includes all of the parts found in the SIK for micro：bit that aren't included with the Go Bundle. With the SIK Bridge Pack for micro：bit you will be able to complete circuits that will teach you how to read sensors， move motors， build Bluetooth(R)devices and more.The micro：bit is pocket-sized computer that lets you get creative with digital technology. Between the micro：bit and our shield-like bit boards you can do almost anything while coding， customizing and controlling your micro：bit from almost anywhere! You can use your micro：bit for all sorts of unique creations， from robots to musical instruments and more. At half the size of credit card， this versatile board has vast potential!Note：The Bridge Pack is NOT full SparkFun Inventor's Kit and only includes the parts to complement micro：bit Go Bundle or standalone board. That also means that this kit doesnotinclude micro：bit， which will need to be purchased separately.Get started with the micro：bit SIK Experiment GuideExamplesCircuit 0：Hello， micro：bit!Circuit 1：Blinking an LEDCircuit 2：Reading PotentiometerCircuit 3：Reading PhotoresistorCircuit 4：Driving an RGB LEDCircuit 5：Reading an SPDT SwitchCircuit 6：Reading Button PressCircuit 7：Reading the Temperature SensorCircuit 8：Using Servo MotorCircuit 9：Using BuzzerCircuit 10：Using the AccelerometerCircuit 11：Using the Compass

DescriptionThe SparkFun QuickLogic Thing Plus EOS(TM)S3， is a small form factor system ideal for enabling the next generation of low-power Machine Learning(mL)devices. The QuickLogic Thing Plus is powered by QuickLogic's EOS S3， the first eFPGA-enable

DescriptionThis straight bar load cell(sometimes called a strain gauge)can translate up to 10kg of pressure(force)into an electrical signal. Each load cell is able to measure the electrical resistance that changes in response to， and proportional of， the strain(e.g. pressure or force)applied to the bar. With this gauge you will be able to tell just how heavy an object is， if an object's weight changes over time， or if you simply need to sense the presence of an object by measuring strain or load applied to a surface.Each straight bar load cell is made from an aluminum-alloy and is capable of reading a capacity of 10kg. These load cells have four strain gauges that are hooked up in a wheatstone bridge formation. The color code on the wiring is as follows：red = E+， green = O+， black = E-， and white = O-. Additionally， these load cells offer an IP66 protection rating and feature two M4 and two M5 sized through-holes for mounting purposes.Get Started with the Load Cell GuideFeatures80mm×12.7mm×12.7mm， 250mm Wire
