「seed」の検索結果

DescriptionThe SN74HC595N is a simple 8-bit shift register IC. Simply put， this shift register is a device that allows additional inputs or outputs to be added to a microcontroller by converting data between parallel and serial formats. Your chosen microprocessor is able to communicate with the The SN74HC595N using serial information then gathers or outputs information in a parallel(multi-pin)format. Essentially it takes 8 bits from the serial input and then outputs them to 8 pins.This small DIP packaged IC contains an 8-bit， serial-in parallel-out shift register that feeds an 8-bit D-type storage register with parallel 3-state outputs.Note：This is a drop-in replacement for the 74HC595 shift register IC and should function just fine in any application the previous version could.Get started with the Shift Register GuideFeatures8-Bit Serial-In， Parallel-Out ShiftWide Operating Voltage Range of 2 V to 6 VHigh-Current 3-State Outputs Can Drive Up to 15 LSTTL LoadsLow Power Consumption：80-μA±6-mA Output Drive at 5 V

DescriptionThe Raspberry Pi Zero Case has been designed to fit both the Pi Zero and the Pi Zero W. These official cases consist of several parts and protect the Raspberry Pi Zero from things like rogue wires that might short it out while still allowing full access to the board. Simply snap the RPi into the bottom half of the enclosure， then snap on a desired top. No tools required!Each case has a standard base featuring a cut-out to allow access to the GPIO， and a choice of three lids：a standard lid， a GPIO lid(allowing access to the GPIO pins from above)and a camera lid(which， when used with the short camera cable supplied， allows the Raspberry Pi camera to be fitted neatly inside it). Additionally， each case includes a 4cm long CSI cable and four rubber feet.Note：This case doesNOTinclude a Raspberry Pi or Camera Module.

DescriptionWith the SparkFun Qwiic Connect System expanding every day， we want to make sure it becomes as accessible as possible but we understand there are other systems that can compliment it out there. The Qwiic to Grove Adapter Cable allows interoperability between the SparkFun Qwiic Connect System and the I2C based Grove boards from Seeed Studio. Now you can plug Seeed Studio boards you may have onto the Qwiic bus or you can use this cable to introduce Qwiic sensors， inputs， and outputs into your Grove system.Note：The Grove system has a variety of different signal systems that use the same connector. This cableonlyworks with the I2C variety.The SparkFun Qwiic connect system is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.FeaturesLength：100mm

DescriptionThis sealed digital temperature probe lets you precisely measure temperatures in wet environments with a simple 1-Wire interface. The DS18B20 provides 9 to 12-bit(configurable)temperature readings over a 1-Wire interface， so that only one wire(and ground)needs to be connected from a central microprocessor. Power for reading， writing， and performing temperature conversions can be derived from the data line itself with no need for an external power source.Because each DS18B20 contains a unique silicon serial number， multiple DS18B20s can exist on the same 1-Wire bus. This allows for placing temperature sensors in many different places. Applications where this feature is useful include HVAC environmental controls， sensing temperatures inside buildings， equipment or machinery， and process monitoring and control.Note：The pinout for this sensor is as follows：RED=Vcc BLACK=GND WHITE=SIGFeatures3.0-5.5V input voltage-55℃ to +125℃ temperature range±0.5℃ accuracy from -10℃ to +85℃Waterproof1 Wire interfaceProbe is 7mm in diameter and roughly 26mm long. Overall length(including wire)is 6 feet.Thermometer resolution is programmable from 9 to 12 bits.Electrical performance：no flicker or breakdown within AC 1200V/1S ，within DC 500V theinsulation resistance shall be greater than 100MΩ

DescriptionThe SparkFun Soil Moisture Sensor is a simple breakout for measuring the moisture in soil and similar materials. The soil moisture sensor is pretty straightforward to use. The two large， exposed pads function as probes for the sensor， together acting as a variable resistor. The more water that is in the soil means the better the conductivity between the pads will be， resulting in a lower resistance and a higher SIG out. This version of the Soil Moisture Sensor includes a 3-pin screw pin terminal pre-soldered to the board for easy wiring and setup.To get the SparkFun Soil Moisture Sensor functioning， all you will need is to connect the VCC and GND pins to your Arduino-based device(or compatible development board). You will receive a SIG out， which will depend on the amount of water in the soil. One commonly known issue with soil moisture senors is their short lifespan when exposed to a moist environment. To combat this， we've had the PCB coated in gold finishing(ENIG， or Electroless Nickel Immersion Gold).Note：Check the Hookup Guide below for assembly and weatherproofing instructions， as well as a simple example project that you can put together yourself!Get Started with the Soil Moisture Sensor Guide

DescriptionThe Raspberry Pi 400 is a complete Raspberry Pi 4-based personal computer， integrated into a keyboard. By incorporating the board into a keyboard， it removes the need for a case and other accessories normally needed to run a Raspberry and

DescriptionThe Raspberry Pi 400 is a complete Raspberry Pi 4-based personal computer， integrated into a keyboard. By incorporating the board into a keyboard， it removes the need for a case and other accessories normally needed to run a Raspberry and

DescriptionIf you do anything with electronics， you're probably already using transistors， but you're probably using them in large， prepackaged clusters of just one type. The SparkFun Discrete Semiconductor Kit addresses your needs of only needing one

These 5mm units have four pins - Cathode is the longest pin. One for each color and a common cathode. Use this one LED for three status indicators or pulse width modulate all three and get mixed colors!NoteAs of 1/2010、the pins in the datasheet ar

DescriptionThis is a super small， 2x5 pin male PTH header. This header is in the common configuration for JTAG applications. Each pin has a spacing of 1.27mm in between each other and can be cut down to smaller increments if the need arises.FeaturesPin style：squareNumber of pins：10(2x5)Pin spacing：1.27mm(0.05")

DescriptionThough the Clincher connector can be used with FFCs， we also like to use them with our FlexiForce sensors and other flex/force sensors found in theRecommended Productssection below.Note：Please be aware that we will not be able to accept returns on this connector if it has been closed. Sorry for any inconvenience this may cause.

DescriptionThough the Clincher connector can be used with FFCs， we also like to use them with our FlexiForce sensors and other flex/force sensors found in theRecommended Productssection below.Note：Please be aware that we will not be able to accept returns on this connector if it has been closed. Sorry for any inconvenience this may cause.

DescriptionThese Clincher connectors from Amphenol FCI can be used to terminate Flat Flexible Cables(FFCs)to an easy-to-use standard header. Simply insert the end of the cable into the connector and press it closed. The teeth inside the connector will "clinch" around the conductors and break them out to three male 0.1" spaced pin headers!Though the Clincher connector can be used with FFCs， we also like to use them with our FlexiForce sensors and other flex/force sensors found in theRecommended Productssection below.Note：Please be aware that we will not be able to accept returns on this connector if it has been closed. Sorry for any inconvenience this may cause.

DescriptionThe LilyMini ProtoSnap is a great way to get started learning about creating interactive e-textile circuits before you start sewing. Like other LilyPad ProtoSnap boards， the LilyMini ProtoSnap has all of its pieces wired together out of the box， enabling you to test the circuit's function before you sew. At the center of the board is a pre-programmed LilyMini microcontroller connected to a LilyPad Light Sensor， LilyPad Button and two pairs of LilyPad LEDs.The LilyMini ProtoSnap ships with pre-loaded code that uses all the LilyPad pieces connected to it. This sample code has three modes， which can be selected by pressing the LilyPad Button on the bottom-left side of the ProtoSnap. The built-in RGB LED on the LilyMini will change color to indicate which mode has been selected：White：All LEDs on.Magenta：LEDs fade in and out in a breathing pattern. When the light sensor is covered， LEDs fade faster.Cyan：LEDs off. When the light sensor is covered， LEDs will twinkle.The LilyMini board， at the center of the ProtoSnap， has a built-in battery holder for a CR2032 battery(included). On the opposite side of the LilyMini you will find the SAMD11 brain， which controls the ProtoSnap.Note：A portion of this sale is given back to Dr. Leah Buechley for continued development and education in e-textiles.Note：The LilyPad LilyMini ProtoSnap does NOT include sewing needles or conductive thread. These items will need to purchased separately.Warning：You cannot reprogram this product and any attempt at programming is at your own risk!Get Started with the LilyMini ProtoSnap Guide

DescriptionThe 6-Channel Temperature Monitor can measure temperatures from as low as -240℃ up to +850℃(real-world limits greatly depend on the sensors being used). Up to six 3-wire PT100 sensors(not included)can be connected for measuring up to six temperatures. Measured temperature values are sent on a serial port for data logging and/or further processing. The kit includes an optional serial LCD for displaying readouts right on the board.Note：The kit requires soldering， a Serial to USB converter， and 9V power supply. See related products for these and PT100 temperature sensors.

DescriptionThe Solder-Mate(TM)Solder Dispenser provides you with an easy way to， well...dispense solder! This handy tool provides a continuous supply of solder(until the roll runs out， that is)， freeing up hand space and minimizing downtime. Each solder dispenser can hold up to a 1lb solder spool. This is a great addition to any workbench!Note：Solder is NOT included with the Solder-Mate and will need to be purchased separately.

DescriptionThis Digital LED Voltmeter measures the voltage at a particular point of the system it has been hooked up to and then provides a readout on its three 7-segment LEDs. This voltmeter is able to provide a readout of voltages from 2.5VDC to 30

DescriptionThe full-color LilyPad Sewable Electronics Kit Guidebook contains step-by-step instructions for creating four interactive projects from the materials contained in the kit. Examples and circuits are provided and explained. The manual also includes a glossary and troubleshooting tips. Once you make your way through all of the projects， you will have a much better grasp on e-textiles!Note：This is just the manual for the LilyPad Sewable Electronics Kit. The kit itself or the individual parts used in this book will need to be purchased separately.ExamplesProject 1：Glowing PinProject 2：Illuminated MaskProject 3：Light-Up PlushProject 4：Night-Light Pennant

DescriptionThe Raspberry Pi Zero and Zero W are both equipped with a smaller CSI(Camera Serial Interface)port than on a full-sized Raspberry Pi board --- luckily， that's where this cable can help! The Raspberry Pi Zero Camera Cable replaces the pre-existing camera module cable， allowing your Zero or Zero W light and imaging capabilities.This cable measures 15cm from end to end and can easily be swapped in and out.Note：This product only includes the CSI cable and doesNOTinclude a Raspberry Pi Camera Module. The module will need to be purchased separately.

DescriptionThe SparkFun OpenScale is a simple-to-use， open source solution for measuring weight and temperature. It has the ability to read multiple types of load cells and offers a simple-to-use serial menu to configure calibration value， sample rate， time stamp and units of precision.Simply attach a four-wire or five-wire load cell of any capacity， plug the OpenScale into a USB port， open a terminal window at 9，600bps， and you'll immediately see mass readings. The SparkFun OpenScale will enable you to turn a load cell or four load sensors in a Wheatstone bridge configuration into the DIY weigh scale for your application.The OpenScale was designed for projects and applications where the load was static(like the beehive in front of SparkFun HQ)or where constant readings are needed without user intervention(for example， on a conveyor belt system). A load cell with an equipped OpenScale can remain in place for months without needing user interaction!On board the SparkFun OpenScale is the ATmega328P microcontroller， for addressing your communications needs and transferring your data to a serial terminal or to a data logger such as the OpenLog， an FT231 with mini USB， for USB to serial connection； the HX711， a 24-bit ADC for weigh scales； and the TMP102， for recording the ambient temperature of your system. The OpenScale communicates at a TTL level of 9，600bps 8-N-1 by default and possesses a baud rate configurable from 1，200bps to 1，000，000bps.Get Started with the OpenScale GuideFeaturesOperating Voltage：5VOperating Ampage：80-100mAPower Cycling above 500msSelectable 10SPS or 80SPS Output Data RateLocal External Temperature SensorsFixed Adjustable Gain

DescriptionThe SparkFun Weather Shield is an easy-to-use Arduino shield that grants you access to barometric pressure， relative humidity， luminosity and temperature. There are also connections on this shield to optional sensors such as wind speed， dir

DescriptionThese are the surface mount 50 pin 0.5mm Board to Board Double Slot Male Connectors found on the Alchitry FPGA boards. These headers allow for Alchitry FPGA Boards to stack on one another by being soldered to the underside of the board.These connectors are sold in single units. Four of these connectors are needed for the topside of an Alchitry Board.

DescriptionSweepy 2.0 is our new Dust Boot made from clear polycarbonate.Version 2.0 features a number of enhancements， that stem from customer feedback. These include：Sweepy 65 V2 - now can now travel up and down the spindle body allowing greater flexibility when millingNow fits a 2.5" Shopvac as standardIncludes adapters for：2.5" direct hose2.25" shop vac36mm Festool/FeinIncludes our affectionally-named "Winston" a clear brush free base for 3d carving and video makingThis 69mm size is for the Dewalt spindles.Sweepy mounts directly to your spindle and is clamped with a machined quick-release. The compact design means that no travel is lost， and it works with any Shapeoko Z-axis with no adapters. The lower half is detachable and held in place using neodymium magnets， which means that the top half remains in place while the lower half detaches for easy access when changing bits.(For the legal sticklers out there， the Shapeoko and Compact Router shown in the photos are not included with Sweepy.)

DescriptionThese are the surface mount 50 pin 0.5mm Board to Board Double Slot Female Connectors found on the Alchitry FPGA boards. These headers allow for Alchitry FPGA Boards to stack on one another by being soldered to the topside of the board.These connectors are sold in single units. Four of these connectors are needed for the underside of an Alchitry Board.

DescriptionYou'll have no need for a screwdriver with this terminal! This is a 3-pin Latch Terminal with 5mm pitch pins. Each pin is rated up to 250V @ 11A and will line up well with the standard 0.19" spacing. Please note that the pins are thick enough(1.20mm OD)that you may need to increase the hole diameter on some boards. Each of the terminals can accept 18-22AWG wire.FeaturesLatch Terminal5mm Pitch3-PinTin Plated Brass Terminals18-22AWG Wire RangeOperation Temperature：-55℃～+100℃

DescriptionYou'll have no need for a screwdriver with this terminal! This is a 4-pin Latch Terminal with 5mm pitch pins. Each pin is rated up to 250V @ 11A and will line up well with the standard 0.19" spacing. Please note that the pins are thick enough(1.20mm OD)that you may need to increase the hole diameter on some boards. Each of the terminals can accept 18-22AWG wire.FeaturesLatch Terminal5mm Pitch4-PinTin Plated Brass Terminals18-22AWG Wire RangeOperation Temperature：-55℃～+100℃

DescriptionWhether you're an agriculturalist， a professional meteorologist or a weather hobbyist， building your own weather station can be a really rewarding project. When you're measuring weather， however， you need some pretty specialized sensors. T

DescriptionThe SparkFun BME280 Atmospheric Sensor Breakout is the easy way to measure barometric pressure， humidity， and temperature readings all without taking up too much space. Basically， anything you need to know about atmospheric conditions you can find out from this tiny breakout. The BME280 Breakout has been design to be used in indoor/outdoor navigation， weather forecasting， home automation， and even personal health and wellness monitoring.The on-board BME280 sensor measures atmospheric pressure from 30kPa to 110kPa as well as relative humidity and temperature. The breakout provides a 3.3V SPI interface， a 5V tolerant I2C interface(with pull-up resistors to 3.3V)， takes measurements at less than 1mA and idles less than 5μA. The BME280 Breakout board has 10 pins， but no more than six are used at a single time. The left side of the board provide power， ground， and I2C pins. The remaining pins which provide SPI functionality and have another power and ground， are broken out on the other side.Note：The breakout does NOT have headers installed and will need to purchased and soldered on yourself. Check theRecommended Productssection below for the type of headers we use in the Hookup Guide!FeaturesOperation Voltage：3.3VI2C SPI Communications InterfaceTemp Range：-40C to 85CHumidity Range：0 - 100% RH， =-3% from 20-80%Pressure Range：30，000Pa to 110，000Pa， relative accuracy of 12Pa， absolute accuracy of 100PaAltitude Range：0 to 30，000 ft(9.2 km)， relative accuracy of 3.3 ft(1 m)at sea level， 6.6(2 m)at 30，000 ft.Incredibly Small

DescriptionThe LilyPad E-Sewing ProtoSnap Kit is a great way to incorporate buttons and switches into an e-textile project without any programming required. Like other LilyPad ProtoSnap series boards， the individual pieces of the included E-Sewing ProtoSnap are pre-wired --- allowing you to try out the function of the circuit before sewing. We have also included a CR2032 battery， needle set， conductive thread bobbin and a swatch of white felt. With all of these parts combined and the featured guide(found in the Documents tab)， you will be able to plan and create fantastic projects straight out of the box!The E-Sewing ProtoSnap includes three white LilyPad LEDs：two connected to a LilyPad Slide Switch and one connected to a LilyPad Button Board. A LilyPad Coin Cell Battery Holder with the included CR2032 coin cell battery provides all the power you need for the circuit. All you need to do is design how you want your project to be laid out， and then snap everything apart!Note：A portion of this sale is given back to Dr. Leah Buechley for continued development and education in e-textiles.Note：Due to the requirements of shipping the battery in this kit， orders may take longer to process and therefore do not qualify for same-day shipping. Additionally， these batteries cannot be shipped via Ground or Economy methods to Alaska or Hawaii. Sorry for any inconvenience this may cause.Get Started with the LilyPad E-Sewing ProtoSnap Guide

DescriptionThe XBee3 Thing Plus is an ultra capable and easy way for getting into wireless device development. The combination of XBee and Qwiic in a space conscious design represents a much needed update to our XBee offering. With 20 I/O pins and Lithium Polymer Ion battery management， the XBee3 Thing Plus has all the basics for quickly prototyping or developing a connected device such as a remote sensor. The Qwiic connector and JST connector for the battery make for a solder-less option when working with the board which shortens setup time.The new XBee3 Micro Module provides the classic all-but plug and play 802.15.4 2.4GHz wireless connection(Zigbee 3.0 Protocol)that makes it so desirable， but with a new addition of being programmable with MicroPython(32KB of memory available for it). RF data rates up to 250 Kbps and 200ft indoor ranges and up to 4000ft line-of-sight outdoor range. Communicating with/Configuring the module happens via an AT Command set or the Digi API， X-CTU， both locally or over-the-air. There's even a mobile version of X-CTU now； Digi XBee(R)Mobile.This variation features a U.FL antenna connector for longer range communications. Check out the related products for compatible antennas.Get Started With the SparkFun XBee3 Thing Plus GuideFeaturesXBee3 Micro ModuleSilicon Labs EFR32MG SoC250Kbps RF， 1Mbps Serial data ratesIndoor/Urban range up to 200 ft(60 m)Outdoor/RF Line of Sight range up to 4000 ft(1200 m)+8 dBm transmit power-103 dBm receiver sensitivityUART， I2C， SPI Interfaces(SPI currently not available at this time， but broken out on the board)ISM 2.4GHz Frequency Band(802.15.4)1MB of memory， 128KB RAM(32KB available for MicroPython)20 GPIO PinsConfigurable via X-CTU or AT Command set via both USB and Wirelessly(second XBee 3 device required for wireless configuration unless you're using the mobile app)Qwiic CompatibleOn-board charging circuit and connector for 3.3v Lithium Polymer Ion Batteries(see related products for compatible batteries)2.6VDC - 3.6VDC supply voltageU.FL Antenna Connector

DescriptionThe XBee3 Thing Plus is an ultra-capable and easy way for getting into wireless device development. The combination of XBee and Qwiic in a space-conscious design represents a much-needed update to our XBee offering. With 20 I/O pins and Lithium-Polymer Ion battery management， the XBee3 Thing Plus has all the basics for quickly prototyping or developing a connected device such as a remote sensor. The Qwiic connector and JST connector for the battery make for a solder-less option when working with the board which shortens setup time.The new XBee3 Micro Module provides the classic， near plug and play 802.15.4 2.4GHz wireless connection(Zigbee 3.0 Protocol)that makes it so desirable， but with a new addition of being programmable with MicroPython(32KB of memory available for it). RF data rates up to 250Kbps and 200 ft indoor ranges and up to 4000 ft line-of-sight outdoor range. Communicating with/Configuring the module happens via an AT Command set or the Digi API， X-CTU， both locally or over-the-air. There's even a mobile version of X-CTU now； Digi XBee(R)Mobile.Note：This variation uses a chip antenna and is not compatible with external antennas.Get Started With the SparkFun XBee3 Thing Plus GuideFeaturesXBee3 Micro ModuleSilicon Labs EFR32MG SoC250Kbps RF， 1Mbps Serial data ratesIndoor/Urban range up to 200 ft(60 m)Outdoor/RF Line of Sight range up to 4000 ft(1200 m)+8 dBm transmit power-103 dBm receiver sensitivityUART， I2C， SPI Interfaces(SPI currently not available at this time， but broken out on the board)ISM 2.4GHz Frequency Band(802.15.4)1MB of memory， 128KB RAM(32KB available for MicroPython)20 GPIO PinsConfigurable via X-CTU or AT Command set via both USB and Wirelessly(second XBee 3 device required for wireless configuration unless you're using the mobile app)Qwiic CompatibleOn-board charging circuit and connector for 3.3v Lithium Polymer Ion Batteries(see related products for compatible batteries)2.6VDC - 3.6VDC supply voltageOn-board Chip Antenna

DescriptionThe SparkFun 2D Barcode Scanner Breakout is a nifty little breakout board featuring the DE2120 barcode scanner module from DYScan. The DE2120 reads 20 different barcode symbologies(both 1D and 2D)using a camera coupled with on-board image processing to identify and decode everything from UPC codes to QR codes. The module also features two LEDs：one for illumination and one to project the red line that you're used to seeing from laser-based scanners.This breakout board makes it easy to explore all of the capabilities of the DE2120 without dealing with finicky flat flex cables. The scanner's USB interface is exposed via the on-board USB-C connector. A buzzer and status LED are connected to the module through appropriate drive circuits and a push button tactile switch is provided on the "trigger" pin. When you're ready to incorporate the module into your embedded project， you can leverage the 5 pin header for direct access to the TTL serial pins， power pins， and trigger input.The module can be configured either by using the serial interface or by scanning command barcodes found in the Settings Manual.All keyboard， HID， and serial can be transmitted over the single USB-C connector. The DE2120 has the unique ability to enumerate all three protocols including a CDC serial driver so the device appears as a standard COM port.Get Started with the 2D Barcode Scanner Breakout Hookup GuideFeaturesUSB-C Connector for USB HID Interface and Virtual COM portReads 20 different symbologies1D SymbologiesUPC-AUPC-EEAN-8EAN-13Code 128GS1-128Code 39Code 93Code 11Interleaved 2-of-5Matrix 2-of-5Industrial 2-of-5CodabarMSIGS1 DataBarDatalogic 2-of-52D SymbologiesQR CodeData MatrixPDF 417Micro PDF 417Aztec Code

DescriptionThe Lock Stop is a low profile， high-quality stainless steel stop that can be used on the Nomad or the Shapeoko in conjunction with the Tiger Claw(Standard or Compact)， or Gator Tooth Clamps.These hard stops help secure your job with a tight grip and serrated face， no matter what you're making.

DescriptionThe Lock Stop is a low profile， high-quality stainless steel stop that can be used on the Nomad or the Shapeoko in conjunction with the Tiger Claw(Standard or Compact)， or Gator Tooth Clamps.These hard stops help secure your job with a tight grip and serrated face， no matter what you're making.

DescriptionThis is a 16mm deluxe thumb joystick and is very similar to the 'analog' joysticks found inside PlayStation controllers. Directional movements are provided simply by two potentiometers - one for each axis. These 10k potentiometers will read the position changes for the joystick's full range of physical motion. This joystick also has a select button that is actuated when the joystick is pressed down.The mechanical parts found in this joystick are mostly metal and are considered far sturdier(rugged， if you will)than other， plastic joystick options.Note：This thumb joystick does not include a top cap and it will need to be purchased separately. Additionally， the leads on the housing of this joystick are much thicker than the leads on the trimpots &； push button components. When soldering to BOB-9110， we recommend using a pair of fine tip tweezers to guide each pin into the correct hole before pushing down.

DescriptionThis S-Type load cell(sometimes called a strain gauge)can translate up to 200kg of pressure(force)into an electrical signal. Each load cell is able to measure the electrical resistance that changes in response and proportion to the strain(e.g.， pressure or force)applied to the form. With this gauge you will be able to tell just how heavy an object is， if an object's weight changes over time， or if you simply need to sense the presence of an object by measuring strain or load applied to a surface.Each straight bar load cell is made from an alloy steel and is capable of reading a capacity up to 200kg. These load cells have four strain gauges that are hooked up in a Wheatstone bridge formation. The color code on the wiring is as follows：red = E+， green = O+， black = E-， and white = O-. Additionally， these load cells offer an IP66 protection rating and feature two M4 and two M5 sized through-holes for mounting purposes.Get Started with the Load Cell GuideFeatures51mm×19mm×76mm， 3m Wire

DescriptionThis straight bar load cell(sometimes called a strain gauge)can translate up to 10kg of pressure(force)into an electrical signal. Each load cell is able to measure the electrical resistance that changes in response to， and proportional of， the strain(e.g. pressure or force)applied to the bar. With this gauge you will be able to tell just how heavy an object is， if an object's weight changes over time， or if you simply need to sense the presence of an object by measuring strain or load applied to a surface.Each straight bar load cell is made from an aluminum-alloy and is capable of reading a capacity of 10kg. These load cells have four strain gauges that are hooked up in a wheatstone bridge formation. The color code on the wiring is as follows：red = E+， green = O+， black = E-， and white = O-. Additionally， these load cells offer an IP66 protection rating and feature two M4 and two M5 sized through-holes for mounting purposes.Get Started with the Load Cell GuideFeatures80mm×12.7mm×12.7mm， 250mm Wire

DescriptionThe SparkFun 9DoF IMU Breakout incorporates all the amazing features of Invensense's ICM-20948 into a Qwiic-enabled breakout board complete with a logic shifter and broken out GPIO pins for all your motion sensing needs. The ICM-20948 itself is an extremely low powered， I2C and SPI enabled 9-axis motion tracking device that is ideally suited for smartphones， tablets， wearable sensors， and IoT applications. Utilizing our handy Qwiic system， no soldering is required to connect it to the rest of your system. However， we still have broken out 0.1"-spaced pins in case you prefer to use a breadboard.In addition to the 3-Axis Gyroscope with four selectable ranges， 3-Axis Accelerometer， again with four selectable ranges， and 3-axis magnetometer with an FSR to ±4900μT， the ICM-20948 also includes a Digital Motion Processor that offloads the computation of motion sensing algorithms from the detectors， allowing optimal performance of the sensors. We've also broken out all the ICM-20948 pin functionality to GPIO and labeled them I2C on the front， SPI on the back for ease of identification.Note：The I2C address of the ICM-20948 is 0x69 and is jumper selectable to 0x68. A multiplexer/Mux is required to communicate to multiple ICM-20948 sensors on a single bus. If you need to use more than one ICM-20948 sensor consider using the Qwiic Mux Breakout.The SparkFun Qwiic Connect System is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.Need a custom board? This component can be found in SparkFun's A La Carte board builder. You can have a custom design fabricated with this component - and your choice of hundreds of other sensors， actuators and wireless devices - delivered to you in just a few weeks.Get Started with the SparkFun ICM-20948 9DoF IMU GuideFeatures1.95 V to 3.6 V supply voltageTriple-axis MEMS gyroscope with user-programmable full-scale range of ±250 dps， ±500 dps， ±1000 dps， and ±2000 dpsTriple-axis MEMS accelerometer with programmable full scale range of ±2g， ±4g， ±8g， and ±16gTriple-axis silicon monolithic Hall-effect magnetic sensor with full scale measurement range to ±4900 μTI2C at up to 100 kHz(standard-mode)or up to 400 kHz(fast-mode)or SPI at up to 7 MHz for communicationwith registersOn-board digital motion processor(DMP)Digital-output temperature sensor2x Qwiic Connection PortsI2C Address：0x69(0x68 with Jumper)DocumentsSchematicEagle FilesHookup GuideDatasheet(ICM-20948)Arduino LibraryPython Support(Qwiic_Py)GitHub Hardware Repo
