メーカー名：ブレンボメーカー品番：208.A985.47ブレーキディスク「T-DRIVE」は、「MotoGP」や「SBK」で得た経験をもとに開発された製品です。ブレーキディスクとインナーベルの間を、機械加工の許容誤差を研究し開発された、特許出願中の8個の「T型」の特殊なギロチンサーフェイスによってマウントされています。径方向及び軸方向のフローティングを可能にするだけではなく、円形ブッシュを用いた従来型のブレーキディスクより総重量を大幅に低減させています。特にレースの過酷な動作時に熱的・機械的な応力への体制を向上させ、制動時のトルクをより効率的に伝達することができます。また、ブレーキディスクの厚みを5.5mmに維持したまま、摺動面を狭める事にも成功し重量を低減させました。これらの結果、重量と慣性は最小限に抑えられ、従来よりハンドリングや乗り心地を快適なものとし、走行性を飛躍的に向上させています。販売備考：ディスク径:Φ320 MVアグスター800/675 ※非分解式のためオーバーホールは対応しておりません。適合情報：エムブイアグスタ[MV AGUSTA] F3 675 11-13エムブイアグスタ[MV AGUSTA] BRUTALE800 [ブルターレ] 18-19エムブイアグスタ[MV AGUSTA] F3 800 13-19エムブイアグスタ[MV AGUSTA] BRUTALE800 DRAGSTER [ドラッグスター] 15-19厚み：5.5色[カラー]：インナーローター：ブラック材質[素材]：アウターローター：ステンレス / インナーベル：アルミニウム仕様：ブラックアノダイズド使用箇所：フロント内容量[数量]：ディスクローター：左右2枚セット外径：320製法：インナーベル(CNC削り出し)使用上の注意：ブレーキパッドとディスクを交換した際にはアタリ付け(慣らし)が必要になります。オーバーホール対応：不可

メーカー名：ブレンボメーカー品番：208.9737.47ブレーキディスク「Super Sport」は、ストリートやサーキットで最大限の性能レベルを提供するべく開発された製品です。ソリッドメタルから削り出されたインナーベルとアウターローターから組み合わせられ、緻密なFEM解析を行って製造されます。ドリルドホールが開いたアウターローターは、ステンレス製のフルフローティング構造を取っており、優れた放熱性能を持っています。これは、ブレーキキング時の制動力とコントロール性を最大限に発揮するのと同時に、回転モーメントを減少させ車両のハンドリングを向上させるのが特徴です。10箇所のフランジ部をジュラルミン製のフローティング・ブッシュにより結合されており、耐久性・耐熱性からも評価され世界的なレースでも使用されております。販売備考：ディスク径:Φ320 F3 800/675に適合します。適合情報：エムブイアグスタ[MV AGUSTA] F3 675 11-13エムブイアグスタ[MV AGUSTA] BRUTALE800 [ブルターレ] 18-19エムブイアグスタ[MV AGUSTA] F3 800 13-19エムブイアグスタ[MV AGUSTA] BRUTALE800 DRAGSTER [ドラッグスター] 15-19厚み：5.5色[カラー]：インナーローター：ゴールド材質[素材]：アウターローター：ステンレス / インナーベル：アルミニウム仕様：ゴールドアノダイズド使用箇所：フロント内容量[数量]：ディスクローター：左右2枚セット外径：320製法：インナーベル(CNC削り出し)使用上の注意：ブレーキパッドとディスクを交換した際にはアタリ付け(慣らし)が必要になります。オーバーホール対応：不可

Festo Double-Acting Pneumatic Guided Cylinder， 80 mm Bore， 125 mm Stroke - DFM Series - DFM-80-125-P-A-GF This actuator from Festo combines the functions of a guide and a drive in one compact unitIts typically used for clamping， lifting and stopping tasks in factory automation setupsThanks to its large-diameter guide rods and four plain-bearing bushes， the unit offers high rigidityIt absorbs torsion and shear stresses with ease， so you can use it for intensive applicationsA choice of multiple supply ports means its easy to install and maintain. Fast installation saves you time and effort High resistance to torque and lateral forces for use in heavy-duty applications Wide range of mounting options for added versatility Application Information Conveyor and assembly systems Manufacturing units Electrical sectorFesto の DFM シリーズのガイド付きアクチュエータは、柔軟なクッションプレートを備えていて、操作中のノイズを軽減し、サービス寿命を延ばします。アクチュエータ本体の一体型スロットにより、近接センサを組み込んでピストンの直線運動を測定できます。ピストン径は 80 mm で、ストローク長は 125 mm で、任意の位置で組み立てられます。 Does this unit need external cushioning 周囲温度： -20 → 80 ℃ 作業荷重からヨークプレートまでの重心距離 125 mmThis guided actuator is fitted with flexible cushioning rings or plates at both ends to reduce stress and damage due to impact forcesWhat type of seals does this unit use This guided actuator is fitted with NBR (nitrile butadiene rubber) seals， which offer good resistance to abrasion and compressionThe seals can also withstand contact with petroleum oils， as well as common lubricants and greases， without degrading.

DescriptionThe SparkFun RV-8803 Real Time Clock Module is a Qwiic-enabled breakout board for the RV-8803 RTC. The RV-8803 boasts some impressive features including a temperature compensated crystal providing extremely precise time-keeping， low power consumption， and time stamp event input along with a user-programmable timing offset value. The RV-8803 also has an improved I2C interface compared to the RV-1805 RTC that removes the need to sequence commands/writes to the device. Best of all， the temperature compensation comes factory calibrated. Utilizing our handy Qwiic system so no soldering is required to connect it to the rest of your system. However， we still have broken out 0.1"-spaced pins in case you prefer to use a breadboard.Adding a real-time clock to your project is the perfect way to get more accurate data； timing or otherwise. Using the Qwiic connector makes for a fast， solid way to incorporate this into your project. The RTC module has counters for hundredths of seconds， seconds， minutes， hours， date， month， year and weekday with a number of alarm and interrupt settings available as well. Plus the large operating temperature range(-40 to +105℃)and temperature compensated crystal makes for a good addition for field applications or harsh environments.The SparkFun Qwiic Connect System is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.Get Started with the SparkFun RV-8803 Real Time Clock Module GuideFeaturesFactory Calibrated Temperature CompensationHigh Time Accuracy±1.5 ppm 0 to +50℃±3.0 ppm -40 to +85℃±7.0 ppm +85 to +105℃1.5V to 5.5V Operating Voltage Range240nA @ 3.3v Low-Power ConsumptionI2C Address：0x32Periodic Countdown Timer Interrupt functionPeriodic Time Update Interrupt function(seconds， minutes)Alarm Interrupts for weekday or date， hour and minute settingsExternal Event Input with Interrupt and Time Stamp functionProgrammable Clock Output pin for peripheral devices.Operating temperature range：-40 to +105℃2x Qwiic Connectors

DescriptionThe SparkFun Load Cell Amplifier is a small breakout board for the HX711 IC that allows you to easily read load cells to measure weight. By connecting the amplifier to your microcontroller you will be able to read the changes in the resistance of the load cell， and with some calibration you'll be able to get very accurate weight measurements. This can be handy for creating your own industrial scale， process control or simple presence detection.This version of the SparkFun Load Cell Amplifier features a few changes that you specifically asked for! We have separated the analog and digital supply， as well as added a 3.3uH inductor and a 0.1uF filter capacitor for digital supply. Need even more? Checkout the SparkFun Qwiic Scale. It has all the features of the HX711 but with additional library support， a true I2C interface， and no soldering required!The HX711 uses a two-wire interface(Clock and Data)for communication. Any microcontroller's GPIO pins should work， and numerous libraries have been written， making it easy to read data from the HX711. Check the hookup guide below for more information.Load cells use a four-wire Wheatstone bridge configuration to connect to the HX711. These are commonly colored RED， BLK， WHT， GRN and YLW. Each color corresponds to the conventional color coding of load cells：Red(Excitation+ or VCC)Black(Excitation- or GND)White(Amplifier-， Signal- or Output-)Green(A+， S+ or O+)Yellow(Shield)The YLW pin acts as an optional input that is not hooked up to the strain gauge but is utilized to ground and shield against outside EMI(electromagnetic interference). Please keep in mind that some load cells might have slight variations in color coding.Note：Special thanks to Bodge for supplying the Library for the HX711!Get Started with the HX711 Load Cell Amplifier GuideFeaturesOperation Voltage：2.7V--5VOperation Current：< 1.5mASelectable 10SPS or 80SPS output data rateSimultaneous 50 and 60Hz supply rejection

DescriptionAdd another eight pins to your microcontroller using a MCP23008 port expander. The MCP23008 uses two I2C pins which can be shared with other I2C devices， and in exchange gives you eight general purpose pins. You can set each of eight pins to be input， output， or input with a pullup. There's even the ability to get an interrupt via an external pin when any of the inputs change so you don't have to keep polling the chip.Use this chip from 2.7-5.5V(good for any 3.3V or 5V setup)， and you can sink/source up to 20mA from any of the I/O pins so this will work for LEDs and such. Team it up with a high-power MOSFET if you need more juice. DIP package means it will plug into any breadboard or perfboard.You can set the I2C address by tying the ADDR0-2 pins to power or ground， for up to eight unique addresses. That means eight chips can share a single I2C bus - that's 64 I/O pins!Features8-bit remote bidirectional I/O portHigh-speed I2C interface(MCP23008)Hardware address pinsConfigurable interrupt output pinConfigurable interrupt sourcePolarity Inversion register for input port data polarity config.External reset inputLow standby current：1 μA(max.)・ Operating voltage：1.8V to 5.5V @ -40℃ to +85℃ I2C @ 100 kHz SPI @ 5 MHz2.7V to 5.5V @ -40℃ to +85℃ I2C @ 400 kHz SPI @ 10 MHz4.5V to 5.5V @ -40℃ to +125℃ I2C @ 1.7 kHz SPI @ 10 MHz

DescriptionThe HM01B0 from Himax Imaging is an ultra low power CMOS Monochrome Image Sensor that enables the integration of an "Always On" camera for computer vision applications such as gestures， intelligent ambient light and proximity sensing， tracking and object identification. The sensor allows the sensor to consume very low power of <2mW at QVGA 30FPS. This low power consumption and vision applications camera comes with a ribbon cable that mates to the camera connector populated on the following products：MicroMod Machine Learning Carrier BoardArtemis Development KitEdge Development Board - Apollo3 BlueThe HM01B0 contains 320×320 pixel resolution and supports a 320×240 window mode which can be readout at a maximum frame rate of 60FPS， and a 2×2 monochrome binning mode with a maximum frame rate of 120FPS. The video data is transferred over a configurable 1bit， 4bit or 8bit interface with support for frame and line synchronization. The sensor integrates black level calibration circuit， automatic exposure and gain control loop， self-oscillator and motion detection circuit with interrupt output to reduce host computation and commands to the sensor to optimize the system power consumption.FeaturesImage SensorUltra Low Power Image Sensor(ULPIS)designed for Always On vision devices and applicationsHigh sensitivity 3.6μ BrightSenseTM pixel technology320×320 active pixel resolution with support for QVGA window， vertical flip and horizontal mirror readoutProgrammable black level calibration target， frame size， frame rate， exposure， analog gain(up to 8x)and digital gain(up to 4x)Automatic exposure and gain control loop with support for 50 / 60Hz flicker avoidanceFlexible 1bit， 4bit and 8bit video data interface with video frame and line syncMotion Detection circuit with programmable ROI and detection threshold with digital output to serve as an interruptOn-chip self oscillatorI2C 2-wire serial interface for register accessHigh CRA for low profile module designSensor ParametersActive Pixel Array 320×320Pixel Size 3.6 μm×3.6 μmFull Image Area 1152 μm×1152 μmDiagonal(Optical Format)1.63 mm(1/11″)Scan Mode：ProgressiveShutter Type：Electronic Rolling ShutterFrame Rate MAX 51 fps @ 320×320， 60 fps @ 320×240(QVGA)CRA(maximum)30℃Sensor SpecificationsSupply Voltage：Analog - 2.8 V， Digital - 1.5V(Internal LDO：1.5V - 2.8V)， I/O - 1.5 - 2.8VInput Reference Clock：3 - 50 MHzSerial Interface(I2C)：2-wire， 400 KHz max.Video Data Interface：1b， 4b， 8b with frame / line SYNCOutput Clock Rate MAX：50 MHz for 1bit， 12.5 MHz for 4bit， 6.25 MHz for 8bitEst. Power Consumption(include IO with 5pF load)：QVGA 60FPS(Typical)<4 mWQVGA 30FPS(Typical)<2 mW

DescriptionThe Binho Nova Multi-Protocol USB Host Adapter allows one to interface their computer directly to hardware circuits. This device is powered by the USB connection to the host PC and is also able to provide downstream power to test circuits.The Binho Nova Multi-Protocol USB Host Adapter features 5 signal pins， one×3v3 pin， one×VUSB pin， and three×GND pins on its 10pin wire harness. The wire harness terminates with a female 1.27mm 2x5 IDC connector. In IO Mode， the five signal pins can be used for varying functions such as Digital Input， Digital Output， PWM Output， Digital Interrupt(on rising edge， falling edge， or change)， Analog Input， or Analog Output.Additionally， the host adapter is able to utilize these pins to communicate on several digital buses：I2C， SPI， UART，(Dallas)1-Wire， and(Atmel)Single-Wire Interface. While in these modes of operation， remaining available pins can be assigned to other related or unrelated purposes such as gpio， interrupts， chip selects， PWM signals， or analog input or outputs.The Binho Nova Multi-Protocol USB Host Adapter is ideal for manual testing during firmware development and debugging as well as a perfect way to automate hardware testing and validation. A common use-case of this product in production environments is for EEPROM/Flash Memory programming along with functional testing activities.FeaturesSupport for SPI @ 12MHz max clockSupport for I2C @ 3.4MHz max clockSupport for UART @ 1000000 max baudSupport for Dallas 1-WireSupport for Atmel Single-Wire InterfaceProvides 3v3 and VUSB power rails1×DAC Output， 5×ADC InputsGPIO / Interrupt / PWM SupportProgrammable RGB Status LEDField-Upgradeable Device FirmwareCross-platform Support for Windows，Mac， LinuxRobust， low-profile AluminumEnclosureUSB Type-C Connector
