14ページ目:

DescriptionThe full-color LilyPad Sewable Electronics Kit Guidebook contains step-by-step instructions for creating four interactive projects from the materials contained in the kit. Examples and circuits are provided and explained. The manual also includes a glossary and troubleshooting tips. Once you make your way through all of the projects， you will have a much better grasp on e-textiles!Note：This is just the manual for the LilyPad Sewable Electronics Kit. The kit itself or the individual parts used in this book will need to be purchased separately.ExamplesProject 1：Glowing PinProject 2：Illuminated MaskProject 3：Light-Up PlushProject 4：Night-Light Pennant

DescriptionThe LilyMini ProtoSnap is a great way to get started learning about creating interactive e-textile circuits before you start sewing. Like other LilyPad ProtoSnap boards， the LilyMini ProtoSnap has all of its pieces wired together out of the box， enabling you to test the circuit's function before you sew. At the center of the board is a pre-programmed LilyMini microcontroller connected to a LilyPad Light Sensor， LilyPad Button and two pairs of LilyPad LEDs.The LilyMini ProtoSnap ships with pre-loaded code that uses all the LilyPad pieces connected to it. This sample code has three modes， which can be selected by pressing the LilyPad Button on the bottom-left side of the ProtoSnap. The built-in RGB LED on the LilyMini will change color to indicate which mode has been selected：White：All LEDs on.Magenta：LEDs fade in and out in a breathing pattern. When the light sensor is covered， LEDs fade faster.Cyan：LEDs off. When the light sensor is covered， LEDs will twinkle.The LilyMini board， at the center of the ProtoSnap， has a built-in battery holder for a CR2032 battery(included). On the opposite side of the LilyMini you will find the SAMD11 brain， which controls the ProtoSnap.Note：A portion of this sale is given back to Dr. Leah Buechley for continued development and education in e-textiles.Note：The LilyPad LilyMini ProtoSnap does NOT include sewing needles or conductive thread. These items will need to purchased separately.Warning：You cannot reprogram this product and any attempt at programming is at your own risk!Get Started with the LilyMini ProtoSnap Guide

DescriptionThis is the FemtoBuck， a small-size single-output constant current LED driver. Each FemtoBuck has the capability to dim a single high-power channel of LEDs from 0-350mA at up to 36V while the dimming control can be either accessed via PWM or analog signal from 0-2.5V. This board is based off of the PicoBuck LED Driver， developed in collaboration with Ethan Zonca， except instead of blending three different LEDs on three different channels the FemtoBuck controls just one.For the FemtoBuck， we've increased the voltage ratings on the parts to allow the input voltage to cover the full 36V range of the AL8805 driver. Since the FemtoBuck is a constant current driver， the current drawn from the supply will drop as supply voltage rises. In general， efficiency of the FemtoBuck is around 95%， depending on the input voltage. On board each FemtoBuck you will find two inputs for both power input and dimming control pins and an area to install a 3.5mm screw terminal. Finally at either side of the board you will find small indents or "ears" which will allow you to use a zip tie to secure the wires to the board after soldering them down. This version of the FemtoBuck is equipped with a small solder jumper that can be closed with a glob of solder to double the output current from 330mA to 660mA.

DescriptionYou don't have to worry about adding a resistor to an LED if you get an LED with a built in resistor! This pack of 25 green 5mm LEDs will help alleviate any frustrations you've had with accidentally burning them out by having a resistor in the diode itself. Each LED has an operating voltage range of 3.0V to 5V to help make your next project shine!Each pack of these LEDs are conveniently bagged in reusable ESD safe packaging to make sure nothing accidentally gets damaged before you are able to use them.FeaturesOperating Voltage Range：3.0V-5.0VStandard Size - T1 3/4 5mmBrightness：15000-20000 MCDColor：520-525 NM

DescriptionYou'll have no need for a screwdriver with this terminal! This is a 3-pin Latch Terminal with 5mm pitch pins. Each pin is rated up to 250V @ 11A and will line up well with the standard 0.19" spacing. Please note that the pins are thick enough(1.20mm OD)that you may need to increase the hole diameter on some boards. Each of the terminals can accept 18-22AWG wire.FeaturesLatch Terminal5mm Pitch3-PinTin Plated Brass Terminals18-22AWG Wire RangeOperation Temperature：-55℃～+100℃

DescriptionYou asked for more wires， so you are going to get more wires! This is a large kit of jumper wires - cut， stripped， and pre-bent for your prototyping pleasure. Included with this kit are 14 various lengths of 22AWG wire - 2， 5， 7， 10， 12， 15， 17， 20， 22， 25， 50， 75， 100， and 125mm - 50 pieces of each.On top of getting five times more jumper wires that the smaller version， this large kit also comes with a durable carrying case with adjustable dividers in case you want to use it for something other than hooking up a project!

DescriptionJumper wires are awesome. Just a little bit of stranded core wire with a nice solid pin connector on either end. They have the flexibility of stranded wire but will fit directly into breadboards and female pin headers. These are six inch long， 26 AWG jumper wires with breadboard-friendly male connectors on both ends. Combine these with our female to female jumpers to create a male to female jumper. Multiple jumpers can be connected next to one another on a 0.1in header.These jumper wires can be used for pretty much everything! They work great with breadboards， Arduinos， and really any 0.1in pitch prototyping board.Features6in. long26 AWG

DescriptionThese are 101mm long 26AWG jumpers with male connectors on both ends. Use these to jumper from any female header on any board to any other female header. Combine these with our female-to-female jumpers to create a male-to-female jumper. Multiple jumpers can be installed next to one another on a 0.1" header.Comes as one pack of 30 jumpers with an assortment of colors.Features4" long

DescriptionWith this high-strength， acrylic gasket， you will be able to attach the 1.2W panels(P124)to an enclosure or almost any other flat surface. The gasket creates a waterproof and secure connection between the panel and a wide variety of materials including plastic and aluminum.For best results， clean both surfaces with isopropyl alcohol and apply with approximately 14PSI.Features3M VHBCreates Waterproof and Secure Seal(when properly applied)Dimensions：66×113×1.1mmCompatible with 1.2W Panel(P124)

DescriptionWith this high-strength， acrylic gasket， you will be able to attach the 0.3W panels(0.3 Watt， 2 Volt and 0.3 Watt， 6 Volt)to an enclosure or almost any other flat surface. The gasket creates a waterproof and secure connection between the panel and a wide variety of materials including plastic and aluminum.For best results， clean both surfaces with isopropyl alcohol and apply with approximately 14PSI.Features3M VHBCreates Waterproof and Secure Seal(when properly applied)Dimensions：47×47×1.1mmCompatible with 0.3W Panels(P121， P122)

DescriptionBe still my beating heart! With the heART Surface Mount Soldering Kit you will be able to learn the basics of SMD soldering by being able to assemble a beating heart pendant! Each heART kit takes about 20-40min to assemble depending on your soldering skill level with basic soldering materials(not included). This little kit provides a great learning tool to help you practice and improve your overall soldering skills without proving to be an impossible challenge!Every heART pendant kit includes one heart-shaped PCB， a CR2032 SMD battery holder， SMD LEDs， capacitors， switch， and an ATtiny85(the heart of the heART). All you need to supply(besides a soldering iron and solder)is a CR2032 coin cell battery since it isnotincluded to make shipping easier and some way to hang the completed pendant from your neck when you assemble it. The battery you provide should last over a week if left on continuously and much longer if switched off when not in use.Note：Since this product is a kit， assembly and a healthy knowledge of soldering will be required. The heART pendant kit does not come pre-assembled.

DescriptionNormal GPS antennas are optimized for the US based GPS reception which is great but with more and more modules capable of tracking additional constellations(termed GNSS receivers)you're going to need the right antenna! This exceptional GPS/GNSS antenna is designed for both GPS and GLONASS reception. When used in conjunction with the SparkFun GPS ground plate this antenna achieved excellent TTFF and SIV statistics for both GPS and GLONASS constellations. The magnetic mount allows it to be easily mounted to a metal base such as a ground plate or car roof. The antenna is terminated with a 3m cable and standard SMA connector.We recommend this antenna for RTK use when combined with the ground plate. If you need Beidou reception and additional gain consider the GPS/GNSS embedded antenna.FeaturesDimensions：50x38x17mmWeight：75g including 3m cableFrequency Range：1575 - 1610MHzGPS Center Frequency：1575.42MHzGLONASS Center Frequency：1602MHzLNA Voltage：3 to 5VDCLNA Gain：28dBLNA Current：10mATermination Connector：SMAImpedance：50ΩRight hand polarizationCable Length：3 meter

DescriptionThis tri-band GNSS antenna is ideal for GPS L1， GLONASS L1， and Beidou B2 reception. At 45x45mm it is alargeceramic antenna with an incredible 38dB LNA gain.This antenna works well with the GPS-RTK providing reception of Beidou satellites where other more basic GPS antennas cannot. We've chosen to have the antenna manufactured without an enclosure to decrease the weight(45g including cable)making this antenna more ideal for rover and quad-copter applications. Additionally， the cable length has been reduced to 1m to reduce weight and to make a more clean installation.We recommend this antenna for RTK use when combined with the ground plate. This antenna is ideal for advanced raw， RTK， and post-processed measurements of GPS， GLONASS， and Beidou constellations. If all you need is GPS and GLONASS(basic GNSS)consider our lower cost magnetic mount GNSS antenna.Antenna is terminated with a standard SMA connector. Check out the related items below for any conversion cables you may need.FeaturesDimensions：45x45x9mmWeight：45g including 1m cableFrequency Range：1558 - 1615MHzLNA Voltage：3.3 to 15VDCPrimary Antenna Gain：4dBLNA Gain：38dBLNA Current：<= 35mATermination Connector：SMAImpedance：50ΩRight hand polarizationCable Length：1 meter

DescriptionThe LIDAR-Lite v4 LED sensor is the next step in the LIDAR-Lite line. A small， lightweight， low-power optical ranging sensor. It's the first to incorporate ANT profile wireless networking technology into an optical sensor. Its built-in nRF52840 processor means that developers can create custom applications， or be operated as a stand-alone device right out of the box by using the preloaded stock application.Like the LIDAR-Lite v3 and LIDAR-Lite v3HP sensors； it can also be directly connected to an external micro-controller running a custom user application. As such， it provides a highly adaptable option for OEM and maker applications in robotics， Internet of Things， and unmanned vehicles ― or any application where an ultrasonic sensor might otherwise be used. It's perfect as the basic building block for applications where wireless capabilities， small size， light weight， low power consumption and high performance are important factors in a short-range， 10-meter， optical distance measuring sensor.The LIDAR-Lite v4 requires an external 5VDC power source and soldering is required. This Time-of-Flight ranging module uses a LED and optics for ranging. It does not use a laser； therefore， it is inherently eye-safe under normal usage.FeaturesResolution：1 cmMeasurement repeatability：As measured indoors to a 90% reflective target1 cm is equivalent to 1 standard deviationUsing "high accuracy" mode， with averaging：+/- 1 cm to 2 meters+/- 2 cm to 4 meters+/- 5 cm to 10 metersRange：5 cm to 10 meters(as measured from back of unit)Update rate：I2C = >200 Hz typicalANT(R)= up to 200 Hz to a 90% target indoors at 2m in normal operating modeInterface：I2C or ANT； user configurable for SPI using the Nordic SDKPower(operating voltage)：4.75 - 5.25 VDCCurrent consumption：2mA idle， 85mA during acquisitionOperating temperature：-20 to 60° CLED wavelength：940 nmBeam divergence：4.77°Optical aperture：14.9 mmUnit size(HxWxD)：2.1"×0.8"×0.9"(52.2×21.2×24.0 mm)Weight：14.6 g(0.5 oz)

DescriptionThis is a 100mm long 4-conductor cable with 1mm JST termination. It's designed to connect Qwiic enabled components together but can be used for other applications as well. The cable insulation is made from a highly malleable material making it more flexible than our original Qwiic cable particularly in tight spaces or enclosures.Each Qwiic Cable's wires have been color coded to red， black， blue and yellow.The SparkFun Qwiic connect system is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.FeaturesDimensions：100mm(3.93")Length

DescriptionThis is a two pack of flat mills from Carbide 3D that are perfect for milling flat or prismatic surfaces. Each mill in this pack features a cutting and shank diameter of 0.25 inches and a cutting length of 0.75 inches. These cutters really are great for specialized 3D machining and fabrication.Each cutter is made of solid carbide to ensure long lasting use.Note：If you are using these cutters with a Nomad， you will also need a 0.25in collet.FeaturesCutting Diameter：0.25"Cutting Length：0.75"Shank Diameter：0.25"

Electrolytic decoupling capacitors 100uF/25V. These capacitors are great transient/surge suppressors. Attach one between the power and ground of your project to ensure smooth power delivery. High quality radial electrolytic capacitors.

DescriptionThe MQ-9B is a CO and CH4 gas detection sensor form Winsen. The sensing material of the MQ-9B is SnO2， which has a low conductivity in clean air. It detects carbon monoxide(1.5V)by method of cycling high and low temperature. The sensor's conductivity gets higher with the CO and CH4 gas concentration rising. The sensing range is 10-500ppm CH4. A simple circuit makes measuring this change in conductivity and turning it into data fairly straight-forward， but does require some calibration.For easy Solderability； use our Gas Sensor Breakout Board.

DescriptionStandard 'Watch' or Real-Time-Clock crystal. 32.768kHz means it is precisely half of a 16-bit counter. Start counting at 0x8000(or 32768). When the counter rolls over from 65535 to 0， then you know that exactly one second has passed. Reset the interrupt， reset the counter， and start counting again! Rated at 12.5pF load capacitance， 35K ohm max(18K ohm typical)series resistance， and +/- 20ppm stability. Small cylinder package.

DescriptionCherry MX Keyswitches are top-of-the-line mechanical keyboard switches. They're satisfyingly "clicky"， reliable up to tens-of-millions of key presses， and a standard in gaming and programming keyboards across the globe. With the SparkFun Cherry MX Switch Breakout we have made the switches more easily adaptable to breadboard or perfboard-based projects. The Cherry MX Switch Breakout is a perfect prototyping tool for projects ranging from a single-key user-input to fully-custom 101-key keyboards.In addition to breaking out the switch contacts to breadboard-compatible headers， the Cherry MX Switch Breakout also provides access to an optional switch-mounted LED. Plus， the pin break-outs are designed with keyboard matrix-ing in mind， so you can interconnect as many boards as you'd like into a row-column configuration， keeping the I/O-pin requirements as low as possible.Note：If you are looking for a Cherry MX Switch to use with this breakout， we've got you covered! CLICK HERE!Get Started with the Cherry MX Switch GuideFeaturesSupport for 3mm LEDFootprint for LED current-limiting resistorFootprint for switch-isolating diodeChain-able in row/column matricesDesigned to match standard key spacing and keyboard row offsets

A row of headers - break to fit. 40 pins that can be cut to any size. Used with custom PCBs or general custom headers.

DescriptionThese are the surface mount 50 pin 0.5mm Board to Board Double Slot Female Connectors found on the Alchitry FPGA boards. These headers allow for Alchitry FPGA Boards to stack on one another by being soldered to the topside of the board.These connectors are sold in single units. Four of these connectors are needed for the underside of an Alchitry Board.

DescriptionThis is a handy AVR programming cable that incorporates both the 10-pin and 6-pin ISP programming interfaces.Cable is about 12" long and mates with pins on 1/10in centers.
