RS PRO 中継用端子台 6極
仕様
極数：6
定格電流：20A
端子方法：埋め込みネジ
ケーブルサイズ：22 → 12 AWG
素材：ナイロン
定格電圧：450 V
動作温度 Min：-5℃
動作温度 Max：+85℃
Multi-purpose Terminal Box. A multi-purpose terminal box that houses six poles. First three poles are marked E，L ； N for mains fixing and are screw and/or tab fixing. Output for these poles are 4tabs per pole. Three spare poles are also provided， each having three fixing tabs. Mains input is via a screw cable clamp and 3 cable grip ports are available for fitting up to three output cables. A spare cable grip port on the input is also provided. The cover snaps into position and can only be opened by levering snap points with a screwdriver. Box can be mounted via two fixing ears. Rated at 400V.10A the box is self extinguishing white polymide to UL94V-2 and IEC 695-2 to 850oC. Operating temperature is 125oC max.
RoHS指令(10物質対応)対応
内容量1個
定格電流：20A
端子方法：埋め込みネジ
ケーブルサイズ：22 → 12 AWG
素材：ナイロン
定格電圧：450 V
動作温度 Min：-5℃
動作温度 Max：+85℃
Multi-purpose Terminal Box. A multi-purpose terminal box that houses six poles. First three poles are marked E，L ； N for mains fixing and are screw and/or tab fixing. Output for these poles are 4tabs per pole. Three spare poles are also provided， each having three fixing tabs. Mains input is via a screw cable clamp and 3 cable grip ports are available for fitting up to three output cables. A spare cable grip port on the input is also provided. The cover snaps into position and can only be opened by levering snap points with a screwdriver. Box can be mounted via two fixing ears. Rated at 400V.10A the box is self extinguishing white polymide to UL94V-2 and IEC 695-2 to 850oC. Operating temperature is 125oC max.
