。Description。Copper tape has countless applications in electronics from creating low-profile traces for electrical components to RF-shielding and antenna-making. Copper tape is even used to join things together using solder， like the stained glass on Tiffany lamps.。This copper tape is backed by a conductive adhesive， is a whopping 2" wide， and comes in rolls of 50 feet. That's a lot of copper.

。Description。Do you need help soldering a difficult project， reworking a botched pin or just making your life easier? This 10mL no-clean flux pen from Chip Quik(R)is great for all of your solder， desolder， rework and reflow purposes! For those of you unfamiliar， flux is a handy substance that prevents beading of the solder and helps the solder flow cleanly onto the parts you are soldering. This is a must-have tool for any hobbyist's workbench.。Each of these flux pens can be used in leaded and lead-free applications and is VOC， halide and rosin free --- making it RoHS II and REACH compliant. Since this is a "no-clean" style flux， you won't have to worry about any sort of conductivity issues associated with it interfering with your board or project. However， it is advisable to still clean whatever you are using this flux pen on with basic isopropyl alcohol(IPA)， because a clean board is a happy board!。Note：It isn't recommended to use this flux with solder that has a water-soluble or rosin flux core in scenarios that require your boards operate at a high reliability rate. At a hobbyist level you should have no issues.。Features。Flux Type：No-Clean Liquid Flux(for leaded and lead-free applications)。Flux Classification：INM0。Packaging：10mL Pen。Shelf Life：Refrigerated >24 months； Unrefrigerated >24 months

。Description。Cherry MX Keyswitches are top-of-the-line mechanical keyboard switches. They're satisfyingly "clicky"， reliable up to tens-of-millions of key presses， and a standard in gaming and programming keyboards across the globe. This 'blue' version Cherry MX Switch is favored by most due to its secondary internal actuator making it less likely to "double-tap." If you are looking for a noticeably audible and high-quality key switch， this is the perfect option for you!。Most Cherry MX Switches - including this blue， MX1A-E1NW switch we carry - have a recess in their body designed to fit a small 3mm LED. Additionally， the weighting for this switch is just around 50cN(centi-Newtons).。Note：。If you are looking for an easy way to incorporate this switch to your project， be sure to check out or breakout board! CLICK HERE!。Get Started with the Cherry MX Switch Guide。Features。Contact Form：SPST。Current Rating：10mA。Voltage Rating：12V。Switch Weighting：50cN。3mm LED Slot

。This is your standard solderless breadboard - three binding posts、two power buses、black aluminum plate backing. It works with a wide variety of wire gauges(29-20 AWG).。Note。The power rails are unbroken on both sides.。Dimensions。Board：165x56x8.5 mm。Aluminum Plate：183x95x1.5 mm

。Description。The Bourns Absolute Encoder is a digital control knob that provides 128 unique results evenly spaced around a full circle. It is designed as a control panel knob but can be adapted for other uses. This can be a good alternative to using a potentiometer and analog pin， as this allows for full-turn and multi-turn operation.。It differs from the more common incremental rotary encoder which has only two or four values in a rotation and is designed to measure full rotations and direction. This measures。angles。and absolute position is maintained between power cycles.。Features。128 rotary positions。360 degree continuous rotation。Rotational life - 50，000 revolutions(min)。Max RPM - up to 120。Absolute digital output will retain its last position between power cycles or in the event of a power failure。Threaded M9x0.75 in. bushing。3/4 in. rotating encoder shaft。Rear mount terminals

。Description。This is a foot-long white audio cable that has been terminated with two TRRS connectors at each end. TRRS connectors are the 3.5mm audio-style connectors that you see on some phones， MP3 players and development boards. TRRS stands for "Tip， Ring， Ring， Sleeve，" which reflects the fact that， unlike a standard stereo connector， this actually has three conductors and a ground. Some devices use the extra conductor for a microphone(as in hands-free headsets)or to carry a video signal(as in some MP3/MP4 players). If you're hacking on something that has a 4-conductor audio jack， being able to plug straight in will keep your build clean and simple.。We use and recommend this specific audio cable for our Spectacle product line.。Features。1ft long(30.5 cm)

。Description。Arduino is an open-source physical computing platform based on a simple i/o board and a development environment that implements the Processing/Wiring language. Arduino can be used to develop stand-alone interactive objects or can be connected to software on your computer(e.g. Flash， Processing， MaxMSP). The open-source IDE can be downloaded for free(currently for Mac OS X， Windows， and Linux).。The Arduino Mega is a microcontroller board based on the ATmega2560. It has 54 digital input/output pins(of which 14 can be used as PWM outputs)， 16 analog inputs， 4 UARTs(hardware serial ports)， a 16 MHz crystal oscillator， a USB connection， a power jack， an ICSP header， and a reset button. It contains everything needed to support the microcontroller； simply connect it to a computer with a USB cable or power it with a AC-to-DC adapter or battery to get started.。Never fear for accidental electrical discharge， either since since the Mega also includes a plastic base plate to protect it!。The Mega 2560 R3 also adds SDA and SCL pins next to the AREF.。In addition， there are two new pins placed near the RESET pin. One is the IOREF that allow the shields to adapt to the voltage provided from the board.。The other is a not connected and is reserved for future purposes.。The Mega 2560 R3 works with all existing shields but can adapt to new shields which use these additional pins.。Not sure which Arduino or Arduino-compatible board is right for you? Check out our Arduino Buying Guide!。Features。ATmega2560 microcontroller。Input voltage - 7-12V。54 Digital I/O Pins(14 PWM outputs)。16 Analog Inputs。256k Flash Memory。16Mhz Clock Speed

。A staple for the electrical engineer. I can't tell you how many times I've been one clip short!。※ 販売は1個単位です。

。Description。This is a 10-pack of wires that are pre-terminated with an alligator clip on one end and a female header on the other. Alligator clips are a staple item for any workbench or makerspace， and with these cables you will be able to easily incorporate those clips into a breadboard， development platform or anything else to which you would normally be able to attach a hookup wire.。Each alligator clip with female header cable has a wire length of 30cm(that's a little less than 1ft)and a port that easily accepts a standard 0.1" connector.

。Description。This is a 40-pin surface mount FPC(Flat Printed Circuit)connector. Nothing too fancy here， except that it can be plugged in either way - contacts up or down. This is useful for manufacturers because they only have to keep one item in stock. It is useful for consumers because they can use one connector to fit in multiple orientations.。This product fits the 1.77 TFT LCD Display 160x128 RGB - 3 Wire and thanks to its dual-sided nature you can use it upside down or all-around.。TFT Display Not Included。This product mates and is pictured with the 1.8in. TFT LCD 160x128 RGB。Features。40 pins。0.5mm pitch。Top/bottom side contacts(both)。Locking

。Description。Features。28 AWG

。Description。Features。Black Color(If you're looking for the white variation， contact support@sparkfun.com)

。Description。USB-C is fantastic. What makes this cable even better is that one of the features we love so much about USB-C has been replicated to the USB-A 2.0 plug! These cables have minor， yet genius modifications that allow them to be plugged into their ports regardless of orientation. No longer will you fight the USB "super position" where both orientations of your plug seem incorrect. A simple solution to a problem that nearly everyone has faced.。Until we have converted all our hubs， chargers， and ports over to USB-C this is the cable you're going to need for basic USB 2.0 connections. This cable is much thinner and flexible than its 3.1 counterpart and is perfect for USB to serial applications as well as for direct connection to basic microcontrollers.。This cable has the D+/D- wires along side large-gauge VBUS/GND wires. Rated for 2A， we've successfully pulled 2A@5V with minimal voltage drop. If you're looking for a the full USB-C implementation checkout our USB 3.1 cable.。Features。Reversible USB-A connector。Reversible USB-C connector

Description。The SparkFun ZOE-M8Q GPS Breakout is a high accuracy， miniaturized， GPS board that is perfect for applications that don't possess a lot of space. The on-board ZOE-M8Q is a 72-channel GNSS receiver， meaning it can receive signals from the GPS， GLONASS， BeiDou， and Galileo constellations. This increases precision and decreases lock time and thanks to the onboard rechargable battery you'll have backup power enabling the GPS to get a hot lock within seconds! Additionally， this u-blox receiver supports I2C(u-blox calls this Display Data Channel)which made it perfect for the Qwiic compatibility so we don't have to use up our precious UART ports. Utilizing our handy Qwiic system， no soldering is required to connect it to the rest of your system. However， we still have broken out 0.1"-spaced pins in case you prefer to use a breadboard.。U-blox based GPS products are configurable using the popular， but dense， windows program called u-center. Plenty of different functions can be configured on the ZOE-M8Q：baud rates， update rates， geofencing， spoofing detection， external interrupts， SBAS/D-GPS， etc. All of this can be done within the SparkFun Arduino Library. We've also made sure to configure the UART pin grouping on the breakout to an industry standard to insure that it easily connects to a Serial Basic.。The SparkFun ZOE-M8Q GPS Breakout is also equipped with an on-board rechargeable battery that provides power to the RTC on the ZOE-M8Q. This reduces the time-to-first fix from a cold start(～30s)to a hot start(～1s). The battery will maintain RTC and GNSS orbit data without being connected to power for up to five hours. Since the ZOE-M8Q is a tiny GPS receiver and to minimize its footprint， we've added a U.FL connector to allow the use of both large standard ceramic antennas as well as very small chip scale antennas.。Note：The I2C address of the ZOE-M8Q is 0x42 and is software configurable. A multiplexer/Mux is required to communicate to multiple ZOE-M8Q sensors on a single bus. If you need to use more than one ZOE-M8Q sensor consider using the Qwiic Mux Breakout.。The SparkFun Qwiic Connect System is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.。The ZOE-M8Q GPS Breakout can also be automatically detected， scanned， configured， and logged using the OpenLog Artemis datalogger system. No programming， soldering， or setup required!。Get Started With the SparkFun ZOE-M8Q Hookup Guide。Features。72-Channel GNSS Receiver。2.5m Horizontal Accuracy。18Hz Max Update Rate。Time-To-First-Fix：Cold：26s。Hot：1s。Max Altitude：50，000m。Max G：≦4。Max Velocity：500m/s。Velocity Accuracy：0.05m/s。Heading Accuracy：0.3 degrees。Time Pulse Accuracy：30ns。3.3V VCC and I/O。Current Consumption：～29mA Tracking GPS+GLONASS。Software Configurable。Geofencing。Odometer。Spoofing Detection。External Interrupt。Pin Control。Low Power Mode。Many others!。Supports NMEA， UBX， and RTCM protocols over UART or I2C interfaces

Description。You'll have no need for a screwdriver with this terminal! This is a 4-pin Latch Terminal with 5mm pitch pins. Each pin is rated up to 250V @ 11A and will line up well with the standard 0.19" spacing. Please note that the pins are thick enough(1.20mm OD)that you may need to increase the hole diameter on some boards. Each of the terminals can accept 18-22AWG wire.。Features。Latch Terminal。5mm Pitch。4-Pin。Tin Plated Brass Terminals。18-22AWG Wire Range。Operation Temperature：-55℃～+100℃

Description。The Mountable MI：pro is a simple and compact protective case for the micro：bit. This case has been specifically designed with portability and expansion in mind and is compatible with both the original micro：bit V1 and the micro：bit V2. These cases feature a three-layer construction style with ability to wall-mount the whole assembly onto any surface you want while still providing access to all buttons and ports on the micro：bit. Though these cases do feature wall-mountable tabs， the biggest benefit of using a case is to not accidentally short out the pads on the back of the micro：bit.。Construction is simple， requiring only a small flathead screwdriver， and involves layering each plate on top of one another around the micro：bit and screwing it into place. Luckily， the MI：pro case enables easy access to the edge pins at the bottom of the micro：bit， allowing it to still be plugged into an edge connector found on many of our carrier boards. The only board that cannot be used in conjunction with the MI：pro case is the SparkFun gamer：bit due to its edge connector being located in the center of the board.。Note：The MI：pro case only includes the parts found in the Includes Tab. This case does NOT include a micro：bit， power source or mounting screws. These items will need to be purchased separately.。Features。Dimensions：Length(minus the mounting brackets on the side)：65mm.。Length(with the mounting brackets on the side)：91mm.。Width：37mm.。Depth(without screws)：9mm.。Depth(with screws)：14mm.。Provides excellent protection to the BBC micro：bit whilst allowing access to the bottom pins.。Full access to the A and B buttons on the BBC micro：bit.。The mounting points allow you to fix the micro：bit to a surface for sturdy and more permanent installations.。Full access to pins and connections including the micro USB connector.。Clear case material shows the on-board LEDs in perfect clarity.。The case is compatible with versions 1 and 2 of the micro：bit.

Description。This is a Screw Terminal with 3.5mm pitch pins. Comes in 2， 3， or 4 positions and have the really cool feature of slide-locking together to form any size you need(4， 5， up to 20 without problems). Rated up to 300V @ 10A. Terminal can accept 26 to 16AWG wire. 3.5mm/138mil pin pitch will not fit standard 0.1" perf boards but this is the most common pitch screw terminal.

Description。This is a 220 Ohm， 1/4th Watt， +/- 5% tolerance PTH resistor. Commonly used in breadboards and perf boards. We've opted for a new and more breadboard-friendly lead thickness(they're a bit thicker than our last ones).。Note：。Sold as singles.。Features。Tolerance：±5%。Power(Watts)：0.25W， 1/4W。Composition：Carbon Film。Features：Flame Retardant Coating， Safety。Temperature Coefficient：0/ -400ppm/℃。Operating Temperature：-55℃ ～ 155℃。Package / Case：Axial。Size / Dimension：0.091"" Dia x 0.236"" L(2.30mm x 6.00mm)。Number of Terminations：2。Resistance：220 Ohms

Description。Though the Clincher connector can be used with FFCs， we also like to use them with our FlexiForce sensors and other flex/force sensors found in the。Recommended Products。section below.。Note：。Please be aware that we will not be able to accept returns on this connector if it has been closed. Sorry for any inconvenience this may cause.

Description。It's time to say hip hip array for this IR Breakout! The MLX90640 SparkFun IR Array Breakout is equipped with a 32x24 array of thermopile sensors creating， in essence， a low resolution thermal imaging camera. With this breakout you can detect surface temperatures from many feet away with an accuracy of ±1.5℃(best case). To make it even easier to get your low-resolution infrared image， all communication is enacted exclusively via I2C， utilizing our handy Qwiic system. However， we still have broken out 0.1"-spaced pins in case you prefer to use a breadboard.。This specific IR Array Breakout features a 110°x75° field of view with a temperature measurement range of -40℃-300℃. The MLX90640 IR Array has pull up resistors attached to the I2C bus； both can be removed by cutting the traces on the corresponding jumpers on the back of the board. Please be aware that the MLX90640 requires complex calculations by the host platform so a regular Arduino Uno(or equivalent)doesn't have enough RAM or flash to complete the complex computations required to turn the raw pixel data into temperature data. You will need a microcontroller with 20，000 bytes or more of RAM. To achieve this， we recommend a Teensy 3.1 or above.。Note：The I2C address of the MLX90640 is 0x33 and is hardware defined. A multiplexer/Mux is required to communicate to multiple MLX90640 sensors on a single bus. If you need to use more than one MLX90640 sensor consider using the Qwiic Mux Breakout.。The SparkFun Qwiic connect system is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.。Get Started with the SparkFun IR Array Breakout Guide。Features。Operating Voltage：3V-3.6V。Current Consumption：～18mA。Field of View：110°x75°。Measurement Range：-40℃-300℃。Resolution：±1.5℃。Refresh Rate：0.5Hz-64Hz。I2C Address：0x33。2x Qwiic Connection Ports
