28ページ目: SPARKFUNのすべての商品

Description。These are the surface mount 50 pin 0.5mm Board to Board Double Slot Male Connectors found on the Alchitry FPGA boards. These headers allow for Alchitry FPGA Boards to stack on one another by being soldered to the underside of the board.。These connectors are sold in single units. Four of these connectors are needed for the topside of an Alchitry Board.

Description。This sealed digital temperature probe lets you precisely measure temperatures in wet environments with a simple 1-Wire interface. The DS18B20 provides 9 to 12-bit(configurable)temperature readings over a 1-Wire interface， so that only one wire(and ground)needs to be connected from a central microprocessor. Power for reading， writing， and performing temperature conversions can be derived from the data line itself with no need for an external power source.。Because each DS18B20 contains a unique silicon serial number， multiple DS18B20s can exist on the same 1-Wire bus. This allows for placing temperature sensors in many different places. Applications where this feature is useful include HVAC environmental controls， sensing temperatures inside buildings， equipment or machinery， and process monitoring and control.。Note：The pinout for this sensor is as follows：RED=Vcc BLACK=GND WHITE=SIG。Features。3.0-5.5V input voltage。-55℃ to +125℃ temperature range。±0.5℃ accuracy from -10℃ to +85℃。Waterproof。1 Wire interface。Probe is 7mm in diameter and roughly 26mm long. Overall length(including wire)is 6 feet.。Thermometer resolution is programmable from 9 to 12 bits.。Electrical performance：no flicker or breakdown within AC 1200V/1S ，within DC 500V theinsulation resistance shall be greater than 100MΩ

Description。The A0 in the latest in Macchina's line of OBD-II interfaces. The A0 uses the power of the ESP32 BLE and WiFi module to allow for wireless access to the OBD-II port most modern cars have.。The Macchina A0 module plugs directly into the OBD-II port found in most modern cars and receives its power from the port. From there， one can interface with the device through a few different methods. The easiest is with software such as SavvyCAN， Torque Lite on Android. Besides getting all on board diagnostic information， you're able to control certain aspects of the car and create cool projects such as dash-mounted， shift lights. The A0 can also be programmed in the Arduino IDE， so there's plenty of possibilities to customize the device for what you want to do with your car!。Features。ODB-II compatibility with all modern cars(1996 or newer)。Pre-loaded with SavvyCAN for plug and play(wireless!)reverse engineering。WiFi and Bluetooth(R)Functionality。ESP32 Processor。Super bright RGB LED。CAN Communication Functionality。Programmable with the Arduino IDE

Description。The Arducam 5MP Plus OV5642 Mini provides an easy to use camera solution for those working with low-cost microcontrollers such as those used with Arduino and the RP2040 from Raspberry Pi. It's a general purpose 5MP camera module that's SPI enabled reducing the complexity of controlling the camera. It's a step up in performance from it's predecessor， the Arducam-M-5MP. The most impressive aspect being that it's possible to control more than one of these from the same microcontroller. It features a M12 mount or CS-Mount lens holder with the ability to change lenses. Best of all， there's code libraries for Arduino， STM32， Chipkit， Raspberry Pi， and BeagleBone Black.。The Arducam 5MP Plus OV5642 Mini supports JPEG compression mode， single and multiple shoot mode， short movie recording， one-time capture multiple read operation， burst read operation， and low power mode.。Features。Power supply 3.3V～5V。Active array size：2592×1944。SPI speed：Max 8MHz。Shutter：rolling shutter。Frame buffer：8MByte。Pixel Size：1.4μm×1.4μm。Default M12 Lens：55°。Resolution support：5MP， 1080p， 720p， VGA， QVGA。Format support：RAW， YUV， RGB， JPEG。Size：34×24 mm。Weight：20g。Temperature Range：-10℃～+55℃。Lens Specification：sensor size：1/4″； EFL：4.9mm； F/N：2.2； BFL：1.2mm； HFOV：60 degree(SKU：U6067)

Description。The micro：bit v2 Educator's Lab Pack includes 10 micro：bit v2 boards and everything you need to get you started with the new learning platform. The Lab Pack has everything you need， including micro：bits， cables， battery packs and a few parts to experiment with. This package provides an easy way to introduce your students to the micro：bit without any difficulty or parts hunting.。SparkFun packages everything educators need to get started with the micro：bit in a variety of classroom settings and learning environments. The hardware boards， cables and extra parts come pre-packaged. Examples and curriculum materials are available from SparkFun and micro：bit， as well as from other educators involved in this growing maker education movement.。Lab Packs are your classroom entry point. By combining our kits， popular boards and other educational tools with support materials(to be updated)， SparkFun brings all the power of the open source community to the classroom. We've also updated the battery pack to be closer to what is in other micro：bit kits. It now requires 2xAAA batteries.。The micro：bit is a pocket-sized computer that lets you get creative with digital technology. Between the micro：bit and our shield-like bit boards you can do almost anything while coding， customizing and controlling your micro：bit from almost anywhere! You can use your micro：bit for all sorts of unique creations， from robots to musical instruments and more. At half the size of a credit card， this versatile board has vast potential!。。Features。Micro：bit 2.0：64 MHz Arm Cortex-M4 with FPU。512KB Flash。128KB RAM。5x5 Red LED Array。Two Programmable Buttons， one touch sensitive logo。MEMS microphone and LED indicator。Onboard Light， Compass， Accelerometer， Temp Sensors and Speaker。2.4 Ghz Micro：bit Radio/BLE 5.0 Smart Antenna。25-pin Edge Connector。4 dedicated GPIO， PWM， i2c， SPI， and ext. power。Three Digital/Analog Input/Output Rings。Two Power Rings --- 3V and GND。Dedcated I2C bus for peripherals。MicroUSB Connector(5V)。JST-PH Battery Connector(。Not。JST-XH)(3V)。Power/reset Button with Status LED。200 mA available for accessories。Program with C++， MakeCode， Python， Scratch

Description。Note：。Since these cables belong to our "Ding &； Dent" category， once we are out of stock， we will not carry it again. Get them while you can! We also cannot accept requests/returns/exchanges， provide documentation， or provide support on any aspect of these items.。Features。28 AWG

Description。This is the SparkFun RFM69 Breakout， a small piece of tech that breaks out all the pins available on the RFM69HCW module as well as making the transceiver easy to use. The RFM69HCW is an inexpensive and versatile radio module that operates in the unlicensed ISM(Industry， Science and Medicine)radio band. It's perfect for building inexpensive short-range wireless networks of sensors and actuators for home automation， citizen science and more.。This RFM69HCW operates on the 434MHz frequency and is capable of transmitting at up to 100mW and up to 300kbps， but you can change both of those values to fit your application. For example， you can maximize range by increasing the transmit power and reducing the data rate， or you can reduce both for short-range sensor networks that sip battery power. At full power and with simple wire antennas， we can get messages from one side of a large office building to the other through numerous internal walls. In open air you can reach 500 meters or more. With more complex antennas and modulation schemes， similar parts have successfully transmitted from space to the ground(by very smart amateur radio enthusiasts； your mileage may vary)!。The RFM69HCW uses an SPI(Serial Peripheral Interface)to communicate with a host microcontroller， and several good Arduino libraries are available. It supports up to 256 networks of 255 nodes per network， features AES encryption to keep your data private， and transmits data packets up to 66 bytes long.。SparkFun sells two versions of the RFM69HCW：a 915MHz version and this 434MHz version. Although the ISM band is license-free， the band itself is different in different areas. Very roughly， 915MHz is for use in the Americas， and the 434MHz version is for use in Europe， Asia and Africa. Check your local regulations for other areas.。Get Started with the RFM69HCW Hookup Guide。Features。Transmit power：-18dBm(0.016mW)to +20dBm(100mW)in 1dBm steps。Receive sensitivity：down to -120dBm at 1.2kbps。Modulation types：FSK GFSK MSK GMSK OOK。Bit rates(FSK)：1.2kbps to 300kbps。Voltage range：1.8V to 3.6V。Current consumption：0.1uA sleep， 1.25mA standby， 16mA receive， 130mA transmit(max)。Encryption：AES 128-bit(optional)。Packet buffer(FIFO)：66 bytes。0.8"×1.1"

Description。If you are not needing a lot of power to start your FPGA adventure， or are looking for a more economical option， the Alchitry Cu FPGA Development Board might be the perfect option for you! The Alchitry Cu is a "lighter" FPGA version than the Alchitry Au but still offers something completely unique. FPGAs， or Field-Programmable Gate Arrays， are an advanced development board type for engineers and hobbyists alike to experience the next step in programming with electronics. The Cu truly exemplifies the trend of more affordable and increasingly powerful FPGA boards arriving each year. This board is a fantastic starting point into the world of FPGAs and the heart of your next project. Finally， now that this board is built by SparkFun， we added a Qwiic connector for easy I2C integration!。The Alchitry Cu uses the Lattice iCE40 HX FPGA with 7680 logic cells and is supported by the open source tool chain Project IceStorm. The Cu possesses 79 IO pins with eight general purpose LEDs； a 100MHz on-board clock that can be manipulated internally by the FPGA； a USB-C connector to configure and power the board； and a USB to serial interface for data transfer.。By adding stackable expansion boards similar to shields or HATs called "Elements，" the Alchitry Cu is able to expand its own hardware capabilities by adding prototyping spaces， buttons， LEDs， and more!。The SparkFun Qwiic Connect System is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.。Get Started with our Learning FPGA Tutorials。Features。Lattice iCE40-HX8K FPGA - 7680 logic elements。79 IO pins(3.3V logic level)。USB-C to configure and power the board。Eight general purpose LEDs。One button(typically used as a reset)。100MHz on-board clock(can be multiplied internally by the FPGA)。Powered with 5V through USB-C port， 0.1" holes， or headers。USB to serial interface for data transfer(up to 12Mbaud)。Qwiic Connector。Dimensions of 65mm×45mm。。Examples。First FPGA Project - Getting Fancy with PWM。External IO and Metastability

Description。The DHT20 is a low cost humidity and temperature sensor with a I2C digital output protocol. It can be applied to HVAC， dehumidifier， automatic control， data loggers， weather stations， and many other projects. The sensor is calibrated and doesn't require extra components so you can get right to measuring relative humidity and temperature.。Features。Supply Voltage：2.2-5.5V。Communication：Standard I2C Protocol。Humidity from 0-100% RH。Typical accuracy：RH：±3%， T：±0.5℃。-40 - 80 degrees C temperature range

Description。The SparkFun Load Sensor Combinator is a bare PCB that combines four load sensors into a standard four-wire Wheatstone bridge configuration. If you open up an electronic bathroom scale， you'll find a large rat's nest of wires. The Load Sensor Combinator was created to combine the 12 wires found in a bathroom scale into the standard four-wire Wheatstone bridge configuration.。This version of the SparkFun Load Sensor Combinator features a few changes that you specifically asked for! We updated the silk on the breakout to read "C/+/-" instead of "R/W/B" and moved the temperature sensor connector away from the standoff hole.。You can either use four individual load sensors or simply purchase an off-the-shelf bathroom scale and hack the combinator into it rather than trying to design a base to properly mount four load sensors.。This board works great with our Load Cell Amplifier breakout board； the five pins on the edge of the combinator line up directly to the five pins on the amplifier.。If your amplifier and supporting electronics are more than a few inches away from the scale， an RJ45 footprint is provided. The four Wheatstone pins(E+/E-/S+/S-)as well as the shield pin are connected to twisted pairs within a standard cheap Ethernet cable. This allows the amplifier board to be placed many feet away from the scale itself.。The combinator board also includes a footprint for the DS18B20 one-wire temperature sensor. This allows the user to gather the temperature of the scale in case there is a large variance between the scale and the amplifier. These three pins are accessed through the RJ45 connection as well， allowing remote temperature readings to be gathered over one twisted pair Ethernet cable.。NOTE：。The SparkFun Load Sensor Combinator will only work with 3 wire load sensors， it is not compatible with 4 wire load cells.

Description。The SCD30 from Sensirion is a high quality Nondispersive Infrared(NDIR)based CO2 sensor capable of detecting 400 to 10000ppm with an accuracy of ±(30ppm+3%). In order to improve accuracy the SCD30 has temperature and humidity sensing built-in， as well as commands to set the current altitude. For additional accuracy the SCD30 also accepts ambient pressure readings!。We've written an Arduino library to make reading the CO2， humidity， and temperature very easy. It can be downloaded through the Arduino Library manager：search for 'SparkFun SCD30' or it can be found in the。Documents。tab above.。The SCD30 Humidity and Temperature Sensor can also be automatically detected， scanned， configured， and logged using the OpenLog Artemis datalogger system. No programming， soldering， or setup required!。Note：The SCD30 has an automatic self-calibration routine. Sensirion recommends 7 days of continuous readings with at least 1 hour a day of 'fresh air' for self-calibration to complete.。Features。Power supply voltage：3.3V - 5.5V。NDIR CO2 sensor technology。Integrated temperature and humidity sensor。Best performance-to-price ratio。Dual-channel detection for superior stability。Small form factor：35 mm×23 mm×7 mm。Measurement range：400 ppm - 10.000 ppm。Accuracy：±(30 ppm + 3%)。Current consumption：19 mA @ 1 meas. per 2 s.。Energy consumption：120 mJ @ 1 measurement。Fully calibrated and linearized。Digital interface UART or I2C

Description。Are you low on I/O? No problem! The SX1509 Breakout is 16-channel GPIO expander with an I2C interface that means with just two wires， your microcontroller can interface with 16 fully configurable digital input/output pins. But the SX1509 can do so much more than just simple digital pin control. It can produce PWM signals， so you can dim LEDs. It can be set to blink or even breathe pins at varying rates. This breakout is similar to multiplexer or "mux，" in that it allows you to get more IO from less pins. And， with built-in keypad engine， it can interface with up to 64 buttons set up in an 8x8 matrix.。Two headers at the top and bottom of the breakout board function as the input and control headers to the board. This is where you can supply power to the SX1509， and where your I2C signals SDA and SCL will terminate. GPIO and power buses are broken out in every-which direction， and configurable jumpers cover most of the rest of the board.。Since the I/O banks can operate between 1.2V and 3.6V(5.5V tolerant)independent of both the core and each other， this device can also work as level-shifter. The SX1509 breakout makes it easy to prototype so you can add more I/O onto your Arduino or I/O limited controller. We've even spun up an Arduino Library to get you started!。Features。Enable Direct Level Shifting Between I/O Banks and Host Controller。5.5V Tolerant I/Os， Up to 15mA Output Sink on All I/Os。Integrated LED Driver with Intensity Control。On-Chip Keypad Scanning Engine Supports Up to 8x8 Matrix(64 Keys)。16 Channels of True Bi-directional Style I/O。400kHz I2C Compatible Slave Interface

Description。A 13.20×12.10 mm self-adhesive pure copper heatsink designed to dissipate heat away from your boards and ICs.。Features。Material：Copper。Length：13.20 mm。Width：12.10 mm。Self-Adhesive

Description。This high-gain duck antenna is designed for LTE devices that operate in the 690-960MHz and 1710-2690 MHz bands.。Combined with an SMA to U.FL Adapter， this duck antenna works perfectly with our LTE Cat M1/NB-IoT Shield.。Features。Center Frequency：690～960/1710～2690 MHz。Polarization：Linear。Gain：3dBi typ.。V.S.W.R：< 3.0。Impedance 50Ω

Description。The SparkFun Soil Moisture Sensor is a simple breakout for measuring the moisture in soil and similar materials. The soil moisture sensor is pretty straightforward to use. The two large， exposed pads function as probes for the sensor， together acting as a variable resistor. The more water that is in the soil means the better the conductivity between the pads will be， resulting in a lower resistance and a higher SIG out. This version of the Soil Moisture Sensor includes a 3-pin screw pin terminal pre-soldered to the board for easy wiring and setup.。To get the SparkFun Soil Moisture Sensor functioning， all you will need is to connect the VCC and GND pins to your Arduino-based device(or compatible development board). You will receive a SIG out， which will depend on the amount of water in the soil. One commonly known issue with soil moisture senors is their short lifespan when exposed to a moist environment. To combat this， we've had the PCB coated in gold finishing(ENIG， or Electroless Nickel Immersion Gold).。Note：Check the Hookup Guide below for assembly and weatherproofing instructions， as well as a simple example project that you can put together yourself!。Get Started with the Soil Moisture Sensor Guide

Description。The SparkFun Alphanumeric Display Arduino library makes printing strings to the display as easy as calling the print()function. With this library， you'll be able to send I2C commands to the VK16K33 LED driver chip to light up segments(including the decimal point or colon)and even scroll your string across the display. You can download the library through the Arduino library manager by searching 'SparkFun Alphanumeric Display' or you can get the GitHub repo as a .zip file and install the library from there.。The SparkFun Qwiic Connect System is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.。Get Started with the Qwiic Alphanumeric Display Hookup Guide。Features。Operating Voltage：3.3V。Integrated RC oscillator。Maximum display segment numbers：128 patterns。13×3 matrix key scan circuit。16-step dimming circuit。I2C Addresses：0x70(0x71， 0x72， 0x73)。2x Qwiic connectors。2x Wall Mounting Points

Description。The Xcelite 8-in-1 Screwdriver Set provides eight high-quality bits in a single ergonomic tool. Each bit is easily accessible with a spring-loaded magnetic housing that holds the seven included bits you aren't currently using. Though the screwdriver set includes eight unique bits， the end of the shaft features a 0.25" hex driver that can fit most of your existing 1/4" bits. With a strong magnetic hold and no-roll handle design， this is one of the best all-in-one tools we have used!。The shaft of this multiple-tip driver is made from a chrome-molybdenum vanadium steel that makes for great durability and longevity.

Description。This is a three pack of ball mills from Carbide 3D that are perfect for fabricating complex， organic surfaces. Each mill in this pack features a cutting diameter of 0.0312 inches， a shank diameter of 0.125 inches， and a cutting length of 0.0625 inches. These cutters really are great for precision 3D machining and fabrication.。Each cutter is made of solid carbide to ensure long lasting use.。Features。Cutting Diameter：0.0312in。Cutting Length：0.0625in。Shank Diameter：0.125in

Description。The gator：log is the perfect data logging tool for your next experiment. With the automation of the data collection process， gone are the days of rushing around with a pen and composition notebook to simultaneously record data and your observations. Now， you only need to sit back and observe your experiment.。The gator：log allows a student(s)to focus more on what is happening in the experiment than watching a thermometer or sensor readout. Additionally， a micro：bit can still be used to provide a graphical display for observing changes in data， when a sensor readout is required. If tied in conjunction with the gator：RTC， stop watches on time based experiments can become a thing of the past too(with the added benefit of more accurate timing results)!。The micro：bit is a pocket-sized computer that lets you get creative with digital technology. Between the micro：bit and our shield-like bit boards you can do almost anything while coding， customizing and controlling your micro：bit from almost anywhere! You can use your micro：bit for all sorts of unique creations， from robots to musical instruments and more. At half the size of a credit card， this versatile board has vast potential!。Get Started with the SparkFun gator：log Hookup Guide。Features。ATmega328P microcontroller。μSD(micro SD)card slot for μSD card for data storage。Two status indicator LEDs。Serial connection via RX and TX pads。GND and 3V3 pads for 3.3V power connection

Description。The Lock Stop is a low profile， high-quality stainless steel stop that can be used on the Nomad or the Shapeoko in conjunction with the Tiger Claw(Standard or Compact)， or Gator Tooth Clamps.。These hard stops help secure your job with a tight grip and serrated face， no matter what you're making.

Description。Meet the Alchitry Ft Element Board! Alchitry Elements are expansion boards similar to Arduino shields or Raspberry Pi HATs that work with your Au and Au+ FPGA Development Boards. The Ft Element is equipped with four 50-pin board to board connectors on the underside and top of the board that snap to the Alchitry Au and Au(+)boards. It also adds a USB 3.0 200MB/s high speed interface to your Alchitry board stack via the USB-C connector.。Please note that this board is only functional with the higher end Au Au+ FPGA Dev boards that feature the Xilinx Artix 7.。Get Started with our Learning FPGA Tutorials。Features。USB-C connector w/ 200MB/s data rate to board to board connectors。For use with projects that require data transfer rates greater than standard on board USB to serial 12Mbaud

Description。The MicroMod Qwiic Carrier Board can be used to rapidly prototype with other Qwiic devices. The MicroMod M.2 socket provides users the freedom to experiment with any processor board in the MicroMod ecosystem. This board also features two Qwiic connectors and eight 4-40 screw inserts to connect and mount Qwiic devices.。This version of the SparkFun MicroMod Qwiic Carrier Board features two ports for our standard 1in. by 1in. Qwiic breakouts. However， you aren't beholden to attaching just a duo of Qwiic breakouts since you are able to stack the boards on top of each other， allowing you to hook up a full circuit of Qwiic sensors and accessories to fully utilize your next project!。MicroMod is a modular interface ecosystem that connects a microcontroller "processor board" to various "carrier board" peripherals. Utilizing the M.2 standard， the MicroMod standard is designed to easily swap out processors on the fly. Pair a specialized carrier board for the project you need with your choice of compatible processor!。Get Started With the MicroMod Qwiic Carrier Board Guide。Features。M.2 MicroMod(Processor Board)Connector。USB-C Connector。3.3V 1A Voltage Regulator。Qwiic Connectors。Boot/Reset Buttons。Charge Circuit。Eight 4-40 Inserts

Description。The Raspberry Pi Compute Module 3+ Lite contains the guts of a Raspberry Pi 3 Model B+(the BCM2837 processor and 1GB LPDDR2 RAM). This module allows a designer to leverage the Raspberry Pi hardware and software stack in their own custom systems and form factors. In addition this module has extra IO interfaces over and above what is available on the Raspberry Pi model A/B boards， opening up more options for the designer.。This is all integrated onto a small(67.6mm×31mm)board that fits into a standard DDR2 SODIMM connector. You get the full flexibility of the BCM2837 SoC(which means that many more GPIOs and interfaces are available than with a standard Raspberry Pi)， and designing the Module into a custom system should be relatively straightforward because all the tricky bits have been put onto the Module itself.。The CM3+ Lite product is the same as CM3+ except the eMMC Flash is not fitted， and the SD/eMMC interface pins are available for the user to connect their own SD/eMMC device. Note that the CM3+ is electrically identical and， with the exception of higher CPU z-height， physically identical to the legacy CM3 products.。Note：The CM3+ modules require a software/firmware image dated November 2018 or newer to function correctly.。Features。Broadcom BCM2837B0， Cortex-A53(ARMv8)64-bit SoC @ 1.2GHz。1GB LPDDR2 SDRAM。Operating Supply Voltage：1.8V， 3.3V。Minimum Operating Temperature：-25C。Maximum Operating Temperature：+80C。HDMI， MIPI， USB， and GPIO interfaces on edge connector

Description。USB-C is fantastic. What makes this cable even better is that one of the features we love so much about USB-C has been replicated to the USB-A 2.0 plug! These cables have minor， yet genius modifications that allow them to be plugged into their ports regardless of orientation. No longer will you fight the USB "super position" where both orientations of your plug seem incorrect. A simple solution to a problem that nearly everyone has faced.。Until we have converted all our hubs， chargers， and ports over to USB-C this is the cable you're going to need for basic USB 2.0 connections. This cable is much thinner and flexible than its 3.1 counterpart and is perfect for USB to serial applications as well as for direct connection to basic microcontrollers.。This cable has the D+/D- wires along side large-gauge VBUS/GND wires. Rated for 2A， we've successfully pulled 2A@5V with minimal voltage drop. If you're looking for a the full USB-C implementation checkout our USB 3.1 cable.。Features。Reversible USB-A connector。Reversible USB-C connector
