内容量1個
仕様検出タイプ：レーダー●本体材質：PBT●電流 Max：20 mA●最大圧力：4バール●シリーズ：VEGAFLEX 61●2m rod is suitable for liquids only. VEGAFLEX 61 Guided Microwave Radar Level Transmitter. IP66 rated Measuring range up to 10m Unaffected by temperature， vacuum， pressure， vapours， gases， dust， foam or build-up Accurate to 5mm using Echofox technology Maintenance-free rugged design Also requires : Single stainless steel 10m long (O4mm) suspension cable (item ； 493-6830 493-6830 ) with gravity weight， or 2m (O6mm) rod (item ； 493-6846 493-6846 ) providing measurement to the vessel bottom (both can be shortened as required) Display/adjustment in head via PLICSCOM module or VEGADIS 61 remote housing (both types not supplied with unit see ； 493-6868 493-6868 and ； 468-3508 468-3508 ) 2-wire (20 to 36V loop powered) technology； HART protocol with universal commands Output signal: 0//4 to 20mA (HART) 3/4in. BSP mount Vessel pressure: -1 to +4 bar Housing material: PBT Transducer material: 316 stainless steel， PCTFE Viton seals Cable entries: 2 x M20 Simple calibration
注文コード48800308
品番FX-S.61A 10M
