47ページ目: プログラミング/ロボティクス

DescriptionRobots are fun， and the micro：bit is the perfect controller for learning how to build and program robots! Combining the micro：bit with the SparkFun moto：bit carrier board creates a flexible， low-cost， Qwiic-enabled robotics platform for robot enthusiasts young and old! With the SparkFun micro：bot kit you will be able to create simple robots quickly without spending hours learning how to build and program your bot.Inside each micro：bot kit you will find all the components required to build your micro：bit into a robotics powerhouse； the only part that's not included is the micro：bit itself. Simply add your own micro：bit to the provided moto：bit， assemble the kit， and you will be ready to start moving. The SparkFun micro：bot kit is a great way to get your feet wet in the world of robotics.The kit does not require any soldering and is recommended for anyone curious about robotics or the micro：bit platform.Note：The SparkFun micro：bot kit doesNOTinclude a micro：bit board. The micro：bit board will need to be purchased separately.The micro：bit is a pocket-sized computer that lets you get creative with digital technology. Between the micro：bit and our shield-like bit boards you can do almost anything while coding， customizing and controlling your micro：bit from almost anywhere! You can use your micro：bit for all sorts of unique creations， from robots to musical instruments and more. At half the size of a credit card， this versatile board has vast potential!Get started with the micro：bot kit Guide

DescriptionThe SparkFun NEO-M9N GPS Breakout is a high quality GPS board with equally impressive configuration options including SMA. The NEO-M9N module is a 92-channel u-blox M9 engine GNSS receiver， meaning it can receive signals from the GPS， GLONASS， Galileo， and BeiDou constellations with ～1.5 meter accuracy. This breakout supports concurrent reception of four GNSS. This maximizes position accuracy in challenging conditions increasing， precision and decreases lock time； and thanks to the onboard rechargeable battery， you'll have backup power enabling the GPS to get a hot lock within seconds! Additionally， this u-blox receiver supports I2C(u-blox calls this Display Data Channel)which makes it perfect for the Qwiic compatibility so we don't have to use up our precious UART ports. Utilizing our handy Qwiic system， no soldering is required to connect it to the rest of your system. However， we still have broken out 0.1"-spaced pins in case you prefer to use a breadboard.The NEO-M9N module detects jamming and spoofing events and can report them to the host， so that the system can react to such events. A SAW(Surface Acoustic Wave)filter combined with an LNA(Low Noise Amplifier)in the RF path is integrated into the NEO-M9N module which allows normal operation even under strong RF interferences.U-blox based GPS products are configurable using the popular， but dense， windows program called u-center. Plenty of different functions can be configured on the NEO-M9N：baud rates， update rates， geofencing， spoofing detection， external interrupts， SBAS/D-GPS， etc. All of this can be done within the SparkFun Arduino Library!The SparkFun NEO-M9N GPS Breakout is also equipped with an on-board rechargeable battery that provides power to the RTC on the NEO-M9N. This reduces the time-to-first fix from a cold start(～24s)to a hot start(～2s). The battery will maintain RTC and GNSS orbit data without being connected to power for plenty of time.This product requires an antenna：Be sure to check out the related products/hookup accessories and pick a suitable SMA antenna for your project.The SparkFun Qwiic Connect System is an ecosystem of I2C sensors， actuators， shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch， 4-pin JST connector. This reduces the amount of required PCB space， and polarized connections mean you can't hook it up wrong.The NEO-M9N GPS Breakout can also be automatically detected， scanned， configured， and logged using the OpenLog Artemis datalogger system. No programming， soldering， or setup required!Get Started With the SparkFun NEO-M9N GPS GuideFeaturesIntegrated SMA connector for use with antenna of your choice92-Channel GNSS Receiver1.5m Horizontal Accuracy25Hz Max Update Rate(four concurrent GNSS)Time-To-First-Fix：Cold：24sHot：2sMax Altitude：80，000mMax G：≦4Max Velocity：500m/sVelocity Accuracy：0.05m/sHeading Accuracy：0.3 degreesTime Pulse Accuracy：30ns3.3V VCC and I/OCurrent Consumption：～31mA Tracking GPS+GLONASSSoftware ConfigurableGeofencingOdometerSpoofing DetectionExternal InterruptPin ControlLow Power ModeMany others!Supports NMEA， UBX， and RTCM protocols over UART or I2C interfaces

DescriptionThis is an evaluation board for the Silicon Laboratories Si4703 FM tuner chip. Beyond enabling you to tune in to FM radio stations， the Si4703 is also capable of detecting and processing both Radio Data Service(RDS)and Radio Broadcast Data Service(RBDS)information. The Si4703 even does a very good job of filtering and carrier detection. It also enables data such as the station ID and song name to be displayed to the user.Using this board， you will be able to pick up multiple stations just as well as with a standard FM radio. The board breaks out all major pins and makes it easy to incorporate this great chip into your next radio project. The power bus， the 3.3V and GND pins are broken out For communication. The breakout provides access to SDIO and SCLK for I2C communication while RST can be used for easy resetting. The SEN pin enables the user to change the mode of functionality of the IC. The last two pins broken out are GPIO1 and GPIO2 which can be used as general input/output pins， but also can be used for things like the RDS ready， seeking or tuning functions.Keep in mind， by plugging headphones into the 3.5mm audio jack， you effectively use the cable in your headphones as an antenna! Therefore， this board does not require an external antenna if using headphones or a 3.5mm audio cable longer than 3 feet.

DescriptionThe SparkFun BME280 Atmospheric Sensor Breakout is the easy way to measure barometric pressure， humidity， and temperature readings all without taking up too much space. Basically， anything you need to know about atmospheric conditions you can find out from this tiny breakout. The BME280 Breakout has been design to be used in indoor/outdoor navigation， weather forecasting， home automation， and even personal health and wellness monitoring.The on-board BME280 sensor measures atmospheric pressure from 30kPa to 110kPa as well as relative humidity and temperature. The breakout provides a 3.3V SPI interface， a 5V tolerant I2C interface(with pull-up resistors to 3.3V)， takes measurements at less than 1mA and idles less than 5μA. The BME280 Breakout board has 10 pins， but no more than six are used at a single time. The left side of the board provide power， ground， and I2C pins. The remaining pins which provide SPI functionality and have another power and ground， are broken out on the other side.Note：The breakout does NOT have headers installed and will need to purchased and soldered on yourself. Check theRecommended Productssection below for the type of headers we use in the Hookup Guide!FeaturesOperation Voltage：3.3VI2C SPI Communications InterfaceTemp Range：-40C to 85CHumidity Range：0 - 100% RH， =-3% from 20-80%Pressure Range：30，000Pa to 110，000Pa， relative accuracy of 12Pa， absolute accuracy of 100PaAltitude Range：0 to 30，000 ft(9.2 km)， relative accuracy of 3.3 ft(1 m)at sea level， 6.6(2 m)at 30，000 ft.Incredibly Small

DescriptionThis is an ET Series replacement soldering tip for the Weller WE1010 soldering station. It is a "screwdriver" type of soldering tip， measuring 1/16"(1.6mm)wide. Replacing the tip is a breeze --- simply unscrew the currently attached tip， slip the replacement tip in， and screw it into place.This Weller tip has been pre-tinned with a lead-free alloy. Although this soldering tip is called a "screwdriver，" this is in name only and functions in no way similar to the tool it is named after.

DescriptionThis is a simple knob that connects to the small and medium sized linear slide potentiometers. Each knob uses friction to secure itself to fit onto the slide pot. Once attached， this small knob provides you with an easier to use potentiometer for your project!

DescriptionPlease note， these machines are built to order have an estimated lead time of 4 business days before shippingThis is the Shapeoko 4 XL， nearly double the cutting area of the Shapeoko 4 Standard! The Shapeoko is a 3-axis CNC Machine kit that allows you to create your 2D and 3D designs out of non-ferrous metals， hardwoods， and plastics. The Shapeoko 4 XL is designed to be affordable enough for any shop and powerful enough to do real work. Don't let the size intimidate you! This is an entry-level CNC machine designed for hobbyists， artists， and fabricators!Each Shapeoko 4 XL has a cutting area of 838.2mm(X)x 444.5 mm(Y)x 101.6mm(Z)(33"×17.5"×4")and an overall footprint of 1270mm(X)x 609.6mm(Y)x 482.6mm(Z)(50"×24"×19"). The power cable included in this kit is designed for the United States National Plug Standard. Don't forget you can put whatever you want on the adapter ring(as long as it fits)， whether that's a laser， 3D print extrusion head， or a marker. Get creative!Upgrades from the Shapeoko 3 include：New， more rigid v-wheel design15mm beltsInductive homing switchesNew electronicsIntegrated t-slot Hybrid Table(OPTIONAL)Fully-supported Y extrusionsLeadscrew-driven Z-axisNew， more rigid 65mm router mountSweepy 65mm V2 dust bootNote：This item is non-returnable. If this item arrives damaged or is not functioning properly， please do not hesitate to contact us to see if further actions may be taken.Not Compatible with the Shapeoko 4：Expansion PacksT-Track Clamp KitsZ-PlusProximity Switch KitMaintenance KitShapeoko 3 Bit SetterHDZ 4.0FeaturesFootprint：1270mm×609.6mm×482.6mm(50"×24"×19")Cutting Area：838.2mm×444.5mm×101.6mm(33"×17.5"×4")Weight 137lbs.Operating System：Mac(OSX 10.14 or higher)or PC(Windows 8.1 or 10， Intel or AMD)

LEGO互換のサーボモータ(回転角360°)LEGOと接続できる固定ブラケット付きの重量9gのサーボモータで、回転角は360°です。固定ブラケットは簡単に取り外し可能で、LEGOシリーズと簡単に組み合わることができます。【ご注意】360° サーボは速度と方向を制御できますが、角度を制御できません。焼き付き防止のため、電源電流と電圧にご注意ください。

DescriptionThe CD40106BE consists of six Schmitt-trigger circuits. Each circuit functions as an inverter with Schmitt-trigger action on the input. The trigger switches at different points for positive- and negative-going signals. The difference between the positive-going voltage(VP)and the negative-going voltage(VN)is defined as hysteresis voltage(VH).FeaturesSchmitt trigger action with no external componentsHysteresis voltage typ. at 0.9V at VDD = 5V， 2.3V at VDD = 10V， and 3.5V at VDD = 15VNoise immunity greater than 50%No limit on input rise and fall timesStandardised， symmetrical output characteristics100% tested for quiescent current at 20sVMaximum input current of 1μA at 18 V over full package temperature range； 100nA at 18V and 25℃Low VDD to VSS current during slow input ramp

DescriptionThese wireless receivers work with our 315MHz transmitters. They can easily fit into a breadboard and work well with microcontrollers to create a very simple wireless data link. Since these are only receivers， they will only work communicating data one-way， you would need two pairs(of different frequencies)to act as a transmitter/receiver pair.Note：These modules are indiscriminate and will receive a fair amount of noise. Both the transmitter and receiver work at common frequencies and don't have IDs. Therefore， a method of filtering this noise and pairing transmitter and receiver will be necessary. The example code below shows such an example for basic operation. Please refer to the example code and links below for ways to accomplish a robust wireless data link.Note：These receivers are almost identical to the RF link 434MHz receiver. SparkFun does everything in our power to make sure you receive the product you requested. However， if you are concerned you may have received the incorrect product you can verify which version receiver this is by running a simple test circuit.Features315 MHz500ft range(given perfect conditions)4800bps data rate5V supply voltage

The RF Explorer protection boot is a custom designed、high quality flexible silicone rubber shield to save your device from scratches、dings、or other nicks caused by dropping and other mishaps. The material is strong enough to withstand this type of damage while retaining its flexibility and soft、silky exterior.Features：High quality silicone rubber、protect RF Explorer from scratchesEasy to assemble/disassemble in/off the deviceCustom designed for RF Explorer、all input ports and holes accessibleRobust bottom design、allow RF Explorer to stand verticalCompatible with RF Explorer HolderSize：122x78x30mmWeight：62 gramsPart List：1×RF Explorer Protection Boot(Black)

リレーシールドはArduino/Seeeduinoボードへの大電流負荷を制御できる4つの高品質リレーを提供します。これは、Arduino のデジタルI/Oでは直接制御できないデバイスを制御するための優れたソリューションになります。標準化されたシールドフォームファクタによりArduino および互換機とのスムーズな接続が可能になります。シールドには各リレーのオン/オフ状態を示す4つのLEDインジケータもあります。

DescriptionSometimes referred to as "spade connectors，" these quick disconnects are really useful as power connectors in prototyping or in projects that are repeatedly assembled and disassembled. The shape of these connectors allows them to be used with a variety of retro game-cabinet buttons， as well as lights similar to the ones found in our Spectacle line.These Female Quick Disconnects are about 1/4" wide， come in packs of five， and can be affixed to a 16-14 AWG wire. Mating connectors can be found in the similar items section below.

DescriptionPoke Home Connectors have been featured on a number of our boards over the last few years by providing a simple screw-terminal-type connector for easy wire connection purposes. Similar to screw terminals， Poke Home Connectors grasp a wire entered into the receiving area of the pin-out by pressing down on the small plastic strip at the end of the housing. Doing so raises the internal clamp and， upon release of the button secures the wire in place without any soldering required.Poke Home Connectors work better in environments with a lot of vibrations(i.e. automotive applications)or when a wire is expanding or contracting due to temperature cycling. Additionally， the tension in the connector is automatically adjusted to the wire gauge(assuming it is within the accepted wire thickness)as opposed to variances in tension when a user tightens the screw terminal.

IXYS製のCPC1908Jを搭載したソリッドステートリレーです。GPIOピンによって制御されるスイッチを使用し、最大48Vをブロックし、最大6A(rms)の連続電流を切り替える定格です。

アナログ・デバイセズのAD5541Aを搭載した16ビットのD/Aコンバータモジュールです。AD5541Aは、シングルの16ビット、シリアル入力、バッファなし電圧出力のD/Aコンバータで、単電源の2.7V～5.5Vで動作します。

DescriptionThe PicoBuck LED Driver is an economical and easy to use driver that will allow you to control and blend three different LEDs on three different channels. By default， each channel is driven at 330mA； that current can be reduced by either presenting an analog voltage or a PWM signal to the board. Version 12 of the board adds a solderable jumper that can be closed to increase the maximum current to 660mA. The new voltage regulator also increased the voltage rating on the various components on the board， allowing it to be used up to the full 36V rating of the AL8805 part.Three signal inputs are provided for dimming control. You can use the PWM signal from an Arduino or your favorite microcontroller to dim each channel individually， or you can tie them all to the same PWM for simultaneous dimming. Dimming can be done by an analog voltage(20%-100% of max current by varying voltage from .5V-2.5V)or by PWM(so long as PWM minimum voltage is less than .4V and maximum voltage is more than 2.4V)for a full 0-100% range. A small jumper is provided for each channel to allow you to increase the drive strength from 330mA to 660mA. Two mounting holes for 4-40 or M3 screws are provided on either side of the board. They are perforated so they can be easily snapped off with a pair of pliers， if a smaller footprint is desired.Note：If you're going to use screw terminals， this board uses two different sizes. Check the related products for both sizes you'll need.Note：The PicoBuck LED Driver was made in collaboration with Ethan Zonca. A portion of each sale is given back to him.

DescriptionThis is a two pack of #502 PCB engravers from Carbide 3D for your Shapeoko or Nomad CNC machine to supply you with even more fabrication and milling options. Each PCB engraver possesses a 0.005" ball tip with a 0.0025" radius， a 40 degree tip angle， and is made of solid carbide to ensure long lasting use.If you are wondering how best to utilize this kit， make sure to check out the free to use web app， Carbide Copper. Carbide Copper is CAM software to let you mill PCBs with your CNC machine and is the fastest way to make same-day circuit boards in your own office or shop.Note：It is recommended to use this PCB engraver with FR1 copper clad rather than FR4 to ensure you give your tool bit the longest life possible.Features0.005" Ball tip(0.0025" radius)40 Degree Tip Angle0.125" Shank2 FlutesSolid Carbide

DescriptionThis is a two pack of #501 PCB engravers from Carbide 3D for your Shapeoko or Nomad CNC machine to supply you with even more fabrication and milling options. Each PCB engraver possesses a 0.1" ball tip with a 0.005" radius， a 60 degree tip angle， and is made of solid carbide to ensure long lasting use.If you are wondering how best to utilize this kit， make sure to check out the free to use web app， Carbide Copper. Carbide Copper is CAM software to let you mill PCBs with your CNC machine and is the fastest way to make same-day circuit boards in your own office or shop.Note：It is recommended to use this PCB engraver with FR1 copper clad rather than FR4 to ensure you give your tool bit the longest life possible.Features0.00" Ball tip(0.005" radius)60 Degree Tip Angle0.125" Shank2 FlutesSolid Carbide

DescriptionJump-start your IoT development with the Omega2+ Starter Kit. This kit includes everything you need to create eight different circuits that will teach you how to control LEDs， read inputs， control and read external sensors and displays， learn Python， and more. Step-by-step instructions for building each circuit with the included parts can be found in the online Starter Kit Guide under the "Documents" tab.Each Starter Kit includes an Onion Omega2+ IoT Computer， an Expansion Dock and a variety of electronics components that belong in the collection of every student of Internet of Things. This collection includes resistors， LEDs， jumper wires， switches， a 7-segment display and an LCD screen， to name a few. All kit components are nicely packed up in a handy plastic carrying case.The Onion Omega parts we carry are separated into three different categories：Mainboard， Dock and Expansion Board. With the parts in this kit you will be able to plug the Omega2+ into the Expansion Dock and add any Expansion Board! For a kit that includes all of the parts in the Starter Kit plus the Expansion Boards， check out the Omega2+ Maker Kit.ExamplesBlinking an LED --- Learn the basics of programming the Omega by turning an LED on and off.Blinking Multiple LEDs --- Learn some more programming concepts by controlling multiple LEDs at once.Fading an LED --- Create a cool LED fading effect using the Pulse Width Modulation(PWM)technique.Reading a Switch --- Use a physical switch to control an LED through the Omega.Using a Shift Register --- Use a shift register chip to control eight LEDs using only a few GPIOs.Controlling a 7-Segment Display --- Add a 7-segment display to the previous circuit to display numbers.Reading a 1-Wire Temperature Sensor --- Use a 1-wire temperature sensor to read the ambient temperature.Controlling an LCD Screen --- Use the I2C protocol to control an LCD screen attached to the previous circuit.

Micon Racer2の車軸で使用しているパーツです。補修にお使い下さい。Micon Racer2補修部品リストMicon Racer2 駆動部 補修パーツDCモーターMMCR-FS5用車軸

小型モーター専用のESC(Electric Speed Controller)最大370サイズまでのブラシ付きモータに対応します。小型/軽量でロボットに搭載しやすいように、平らなデザインになっていますので市販の両面テープで簡単に固定することができます。MD-1には、一般的なラジコン用ESCと同じブレーキ&バック付きの(RCカーESC仕様)と、ロボットや工作セットの自作、改造に適した(ニュートラルブレーキ仕様)の2つのラインナップがあります。ニュートラルブレーキ仕様は、ロボットやキャタピラ工作セットなどにお勧めです。一般的なESCは前進操作の後のバック操作でブレーキになります。対して、ニュートラルブレーキ仕様では前進操作後のバック操作でそのまま後進することができます。ブレーキ操作は、ニュートラル位置(中心)に戻すことで効かせることができます。MD-1は、一般的なラジコン用サーボと同じようにPWM信号で制御することができるので、ArduinoなどRCサーボ用のライブラリをそのまま流用することができます。MD-1側で正転逆転、出力制御をするので、市販のモータドライバを使用するようなマイコン側で煩わしい電子制御部分を気にせず制御させることができます。マイコンボードへの配線も信号線、電源、GNDだけなのですっきりと収まります。最大電流は1.9A(FETスペック：5.3A)です。1.9Aを超えると電流リミットがかかります。電流リミット機能によりモータに負荷がかかりにくく、破損しにくい設計になっています。詳しい内容は、こちらのサポート情報をご覧ください。

DescriptionThis is a simple pack of five White LilyPad LEDs that are still attached to one another， letting you snap the LEDs apart at your leisure to sew into clothing or whatever else you can dream up.LilyPad is a wearable e-textile technology developed by Dr. Leah Buechley and cooperatively designed by Leah and SparkFun. Each LilyPad piece was creatively designed with large sew tabs to allow them to be sewn into fabric. Various input， output， power and sensor boards are available. They're even washable(with special care)!Note：A portion of this sale is given back to Dr. Buechley for continued development and education in e-textiles.Features5.5mm x 12.5mmThin 0.8mm PCB

LEDライトRDO-404をボックス型スタンドに固定したセットです。12cm角程度の水耕栽培プランターなどでそのまま実験などに利用することができます。※高輝度LEDを使用していますので、発光面を直視しないでください。

DescriptionThis is a two pin， compact surface mount JST connector. We really like the solid locking feeling and high current rating on these small connectors. We use these all the time as battery connectors.

DescriptionThe M1600HCT-P-SMA is unique antenna combining the ability to communicate with the Iridium satellite network while simultaneously receiving L1 GNSS signals(GPS and GLONASS). This makes the M1600HCT the perfect antenna for tracking devices that transmit their position over Iridium. In addition， weighing only 11 grams， the antenna can achieve IP67 when seated against an SMA bulkhead connection(there is a small o-ring built into the base).This product is designed for applications requiring high quality reception of the Iridium network and is ideal when：the orientation of the unit containing the antenna is random， the unit is used in harsh environments， and/or the antenna is mounted externally and in close proximity to other antennas.FeaturesFrequencyGPS(1575 MHz)GLONASS(1602 MHz)Iridium(1616 - 1626 MHz)Polarization：RHCPPeak Gain：GPS：-3 dBicGLONASS：0 dBicIridum：2.8 dBicImpedance：50 OhmRF Connector：SMADimensions：48mm×18.5mmWeight：11g

DescriptionThe Hologram eUICC SIM Card is a mix between legacy and new technology when cellular service is needed your project. This eUICC SIM Card enables profile switching capabilities so you can dynamically change the subscriber profile while your chosen devices are in the field， over-the-air. For those looking for IoT cellular service with no intentions on switching cellular carriers， this SIM card is for you.eUICC features are limited to certain modules at this point. This includes the u-blox SARA-R4 module used on our SparkFun LTE CAT M1/NB-IoT Shield - SARA-R4. For these situations， the functionality will be that of a normal SIM with cellular service through Hologram. You won't be able to change carriers.FeaturesTemperature Range：-25C to 85CNano SIM 8.8mm x 12.3mmMinimum 500，000 Read/write cyclesMinimum 25 yrs at 25℃ Data retention

DescriptionThis diode-transistor photocouplers consist of an LED， optically coupled to a high speed photodetector to transmit electrical signals between circuits while still isolating your system from higher voltages. The 6N137 optoisolator is presented in an 8-pin DIP package.The output features is an open collector and coupler parameters are guaranteed over the temperature range from -40℃～5℃. The internal shield provides a guaranteed Common Mode Transient Immunity(typical)10KV/μs.FeaturesHigh Speed：10MBdCommon Mode Rejection：10KV/μs
