最大28ピンのSOP ICを2.54mmピッチに変換できる基板 最大28ピンのSOP(Small Outline Package)ICを1.27mmピッチから2.54mmピッチへ変換するためのユニバーサル基板です。SOPパッケージのICをユニバーサル基板に載せたいときなどに使用すると、プロトタイピングや評価に非常に役立ちます。 最大28ピンに対応 1枚の基板に同じパターンが3つ並んでおり、Vカット処理済みで簡単に分割可能 SOP ICを標準的な2.54mmピッチのユニバーサル基板に実装可能 金フラッシュめっきと両面レジストで信頼性が高く、RoHSに対応

Paragon(R)の住宅用および軽商用霜取りタイマーは、内部SPDTスイッチを作動させて冷蔵庫の霜取りヒーターを作動させる同期モーター制御です。これらのヘビーデューティ15アンペアパラゴンタイマーは、OEMメーカーが古いクラシックデザインと住宅用および軽商用アプリケーション用にインストールされた新しいデザインの両方を置き換えるために使用されます。静音性同期設計により、非常に静かな動作を実現 位置の自由度タイマーはさまざまな場所に取り付けることができます 互換性標準マウントにより、あらゆるアプリケーションで使用できます 二重絶縁アース接地は不要 腐食保護を強化するための真鍮製接点 本製品はプロパンガスシステムでの使用が認可されています

DIP(Dual In-Line Package)28ピン(0.3インチ幅)用丸ピンICソケットです。挿しやすく抜けにくく、板バネと比較すると信頼性が高いです。

DIP(Dual In-Line Package)18ピン(0.3インチ幅)用丸ピンICソケットです。挿しやすく抜けにくく、板バネと比較すると信頼性が高いです。

MIL-C 17D Coaxial Cable RG 178 B/U An RG178B/U coaxial cable with a transparent sheath and SPC braid for signal protection Features and Benefits ・ 94% coverage silver plated copper braid shield ・ 70% propagation velocity

アクセサリタイプ = タイマーモジュールシリーズ = 86 SeriesFinder multi-function Timer RelayThe Finder multi-function timer relay is solid-state， compact equipment with 230VAC/DC coil. It is suitable for controlling the operation of equipment， machinery， systems or processes for a wide range of industrial applications. This timer relay can be installed into new and existing applications in an extremely hassle free-way. This timer relay performs delay functions like ON-delay， interval， symmetrical flasher (starting pulse ON)， OFF-delay with control signal， ON and OFF delay with control signal， interval with control signal ON， interval with control signal OFF， and interval with control signal ON and OFF in the range of 0.05 seconds up to 100 hours. Its affordability， optimum space management， and high-performance make it ideal for several applications in process control environments.Features and BenefitsMulti-scale timing ranges from 0.05 seconds to 100 hours like 0.05 seconds to 1 seconds， 0.5 seconds 10 seconds， 5 seconds to 100 seconds， 0.5minutes to 10 minutes， 5 minutes to 100 minutes， 0.5 hours to 10 hours， 5 hours to 100 hours Operating temperature ranges from -20℃ to 50℃ Atex versions available Screw type terminal connection Plug in type mounting LED indicatorApplicationsMachines for ceramics Machines for paper processing Printing machines Packaging machines Wood processing machines Milk processing plant Textile machines Industrial process control Motor control applications Electrical isolation Signal matching between electronic controlsCertificationsIP20 rated EAC certified cRUus certified CE certified EN 61000-4-2 EN 61000-4-3 EN 61000-4-4 EN 61000-4-5 EN 61000-4-6 EN55022

HOBUT Multi-Function MeterThe HOBUT Multi-Function meter is a multifunction， easy to use universal LCD power indicator that features 96mm x 96mm moulded cases and selectable 3-colour backlight LCD screens. It is easy to use and features user-programmable CT and VT ratios and can be used on any single or 3-phase system with any input voltage without reprogramming. This multifunction meter measures current， energy， frequency， power and voltage. Note: Both RS485 output 668-4070 (Modbus protocol) and pulsed output 668-4073 (for Wh or VArh) are plug-in optionsFeatures and Benefits1A or 5A CT AC or DC AUX Cost effective Current transformer ratio Cut-out height is 96mm Cut-out width is 96mm Depth is 82mm Input voltage ranges between 28V and 570V Number of digits are four Operating temperature ranges between 0℃ and 60℃ Security code access for programming Selectable screen colour Voltage transformer ratioApplicationsBuilding management systems Gensets Low， medium and high voltage control panels Power managementCertificationsANSI/ESD S20.20:2014 BS EN 61340-5-1:2007 CE certified

ピーク感度波長 = 880nmパッケージタイプ = T-1 3/4実装タイプ = スルーホール実装ピン数 = 2ダイオード材質 = Si最小検出波長 = 700nm最大検出波長 = 1100nm標準降下時間 = 5ns長さ = 4.95mm高さ = 8.77mm直径 = 6.1mm標準上昇時間 = 5nsQSD2030F PINフォトダイオード. Fairchild SemiconductorのQSD2030Fは、プラスチックシリコンPINフォトダイオードです。 標準の5 mm(T-1 3/4)スルーホールパッケージに収められています。 QSD2030Fは、周囲の可視光を遮断する昼光フィルタを備えた黒色のエポキシ製パッケージに収納されています。. QSD2030Fフォトダイオードの特長: PINフォトダイオード 5 mm(T-1 3/4)パッケージ 広いレセプション角度: 40° 昼光フィルタ 高感度 波長: 880 nm 検出面積: 1.245 x 1.245 mm

DescriptionThis is a 220 Ohm， 1/4th Watt， +/- 5% tolerance PTH resistor. Commonly used in breadboards and perf boards. We've opted for a new and more breadboard-friendly lead thickness(they're a bit thicker than our last ones).Note：Sold as singles.FeaturesTolerance：±5%Power(Watts)：0.25W， 1/4WComposition：Carbon FilmFeatures：Flame Retardant Coating， SafetyTemperature Coefficient：0/ -400ppm/℃Operating Temperature：-55℃ ～ 155℃Package / Case：AxialSize / Dimension：0.091"" Dia x 0.236"" L(2.30mm x 6.00mm)Number of Terminations：2Resistance：220 Ohms

PIC16C505 8-Bit Microcontrollers. The PIC16C range of Microcontrollers from Microchip are 8-bit CMOS MCUs that incorporate Microchip ’s PICR architecture into a variety of pin and package options， from space efficient 14-pin devices to feature-rich 64-pin devices. Now supplanted by Flash based variants these CMOS devices are still popular in legacy designs. For new applications PIC16F variants should be considered. The PIC16C505 family of microcontrollers is based upon Microchip ’s baseline architecture with a 2 level hardware stack and 33 12-bit instructions. These MCUs provide up to 5 MIPS， 1.5 Kbytes program memory with data memory of 72 bytes RAM. On board is a RC oscillator with ±1% accuracy. Features. 33 Instructions 2 Level Hardware Stack 4 MHz Internal Oscillator 11 I/O Pins One 8-bit Timer Watchdog Timer (WDT) Power-on Reset (POR) Device Reset Timer (DRT) In-Circuit Serial Programming (ICSP)

電源電圧 = 24 V dcブロアタイプ = 遠心分離AC/DC動作 = DC風量 = 209m3/hシリーズ = RG 160 N高さ = 220mm幅 = 220mm奥行 = 56mm寸法 = 220 x 220 x 56mmファン回転速度 = 2850rpm騒音レベル = 66dB(A)ベアリングタイプ = ボール取り付け穴の間隔 = 203 x 203mm整流タイプ = エレクトロニック垂直取り付け穴の間隔 = 203mmebm-papst Centrifugal FanThe ebm-papst centrifugal fan has an airflow of 209m3/h and a supply voltage rating of 24VDC. It is designed for operation in the harshest of environments. These fans are constructed for high dust， high humidity and direct water exposure in indoors and outdoors. They are ideal for wash-down situations and cannot be damaged by continuous immersion in water making them suitable for a broad range of applications. It is 220mm long， 220mm wide and 56mm deep. With a construction based on the entire motor (winding and PCB) being completely coated in plastic， the integrated operating electronics of ebm-papst fans are completely encased and the cable connection is specially sealed. Note: To prevent overloading the motor， these blowers must be operated against the minimum static pressures.Features and BenefitsDC fans with electronic rotor switching and integrated electronic switching regulation Maintenance free Fibreglass-reinforced plastic， PBTP housing and PA vane Protected against polarity reversal and overload Electric connection with two 22AWG rated wiresApplicationsIndustrial use Central air conditioning units or building ventilation systems AutomobileCertificationsCE certified IP68 rated

PIC16F870 871 8ビットマイクロコントローラ. The PIC16F range of microcontrollers from Microchip are 8-bit MCUs that incorporate Microchip ’s PICR architecture into variety of pin and package options， from space efficient 14-pin devices to feature-rich 64-pin devices. Devices with Baseline， Mid-Range or Enhanced Mid-Range architecture are available with numerous different peripheral combinations， giving designers flexibility and choice for their applications. The PIC16F870/871 family of microcontrollers is based upon Microchip ’s Mid-Range core with an level deep hardware stack and 35 instructions. These MCUs provide up to MIPS， 3.5 Kbytes program memory， 128 bytes RAM and EEPROM of 64 bytes. マイクロコントローラの機能. 20 MHz Max. CPU Speed 35 Instructions Level Hardware Stack 22 I/O Pins PIC16F870 Model 33 I/O Pins PIC16F871 Model Power-On Reset (POR) Brown-Out Reset (BOR) Power-Up Timer (PWRT) Oscillator Start-Up Timer (OST) Watchdog Timer (WDT) In-Circuit Serial Programming (ICSP) In-Circuit Debug (ICD). 周辺機器. 10-bit Analogue-to-Digital Converter (ADC) PIC16F870 Channels， PIC16F871 Channels Capture， Compare， PWM (CCP) Module Two 8-bit Timers One 16-bit Timer Universal Synchronous Asynchronous Receiver Transmitter (USART) Parallel Slave Port (PSP) PIC16F871 Model Only

USB5734 USB 3.0 Hub Controllers. From Microchip the USB5734 is a 3.0 compliant (also known as USB 3.1 Gen 1) and supports all the defined USB speeds up to the 5 Gbps SuperSpeed (SS) data rate on all enabled downstream ports. The device integrates a USB 2.0 controller to decouple SuperSpeed data from slower USB 2.0 traffic to avoid bottlenecks slower USB 2.0 traffic can create. The USB5734 integrates functions that would typically be associated with a separate MCU or processor； as such Microchip classifies this device as a ’Smart Hub ’. For example the device can communicate to peripherals via I2C， SPI， GPIOs or UART in addition to USB. Also a downstream device can take control of the host system by swapping roles to become the host port， with the Smart Hub switching between two different hosts if required. 特長. Four downstream USB 3.0 (USB 3.1 Gen1)/2.0 ports Integrated Hub Feature Controller (HFC) enabling I/O bridging and FlexConnect I/O Bridging: Host communication to external peripherals - USB to I2C/UART/SPI/GPIO FlexConnect: Host port swapping and switching to downstream devices Battery Charging: USB-IF revision 1.2 support on downstream ports (DCP， CDP， SDP) Simultaneous data transfer for 2500 mA of high speed charging Port Configuration Straps: Predefined configuration of port settings Battery Charging， Non-Removable， Disable Application Straps: Predefined configuration of GPIOs for specific Use Cases including Mixed Mode， FlexConnect Mode， Port Speed mode， Port BC Mode and UART Mode. ProTouch2: Configuration tool to enable enhanced OEM configuration options through either One-Time Programmable (OTP) (8Kbit) or external SPI ROM Manufacturing line programming tool and field update capabilities USB Link Power Management (LPM) support IETF RFC 4122 compliant 128-bit UUID Compatible with MicrosoftR WindowsR 8/8.1 and other major OS ’s

RaspberryPiにTWELITEDIPを接続するための基板 TWELITEDIPをRaspberryPiに接続して使用することができます。TWELITESTAGEAPPと組み合わせると、TWELITEやTWELITEPALのデータの監視や子機のLEDを点灯させるといったコマンドを送ることができます。さらに、トワイライター2(TWELITER2)なしで、TWELITEの設定やアプリの書き換えができます。

FY Series Super capacitors， also known as Electric Double-Layer Capacitors (EDLCs)， are intended for high energy storage applications.Wide range of temperature from 25℃ to +70℃ Maintenance free Maximum operating voltage: 5.5 VDC Highly reliable against liquid leakage Lead-free Applications Super capacitors have characteristic

Solid Tantalum Surface Mount Chip Capacitors， Molded Case， 0805 SizeSmall size， suitable for high-density packaging Terminations: 100 % matte tin APPLICATIONS Industrial Audio and visual equipment General purpose

fixing nut and washer. 6.4mm Mount Neon Indicators. 7mm coloured diffused polycarbonate lens Nickel plated brass bezel 125V type suitable for 110-125V a.c. 250V types suitable for 200-250V a.c. Opal lens illuminates orange Average life expectancy 10000 hours when ran at 115V ； 230V respectively

fixing nut and washer. 6.4mm Mount Neon Indicators. 7mm coloured diffused polycarbonate lens Nickel plated brass bezel 125V type suitable for 110-125V a.c. 250V types suitable for 200-250V a.c. Opal lens illuminates orange Average life expectancy 10000 hours when ran at 115V ； 230V respectively

fixing nut and washer. 6.4mm Mount Neon Indicators. 7mm coloured diffused polycarbonate lens Nickel plated brass bezel 125V type suitable for 110-125V a.c. 250V types suitable for 200-250V a.c. Opal lens illuminates orange Average life expectancy 10000 hours when ran at 115V ； 230V respectively

コイル電圧 = 24V ac/dc接点構成 = SPDT取り付けタイプ = DINレール極数 = 1ターミナルタイプ = ねじ奥行き = 75.6mm高さ = 87.9mm長さ = 6.2mmシリーズ = 38 Series接点材質 = 銀合金入力電流 = 12mA寸法 = 6.2 x 75.6 x 87.9mmFinder Interface Relay ModuleThe Finder interface relay module is an innovative， ultra-compact electromechanical device equipped with a 24AC/DC coil and an SPDT 1C/O contact configuration. This narrow design interface relay works as a coupling element used to send control signals to and from a PLC. The high number of approvals make it useful for many applications around the world. It offers a high-density solution for smaller electrical cabinets and other industrial applications thus optimising your panel installation. This electromechanical relay module has a small footprint that makes it ideal for applications where space-saving is essential.Features and BenefitsThe contact rated voltage is 250VAC and switching current of 6A The input and output circuits and the voltage supply are completely electrically isolated Instant ejection of relay by plastic retaining clip Integral coil indication and protection circuit Operating temperature ranges from -40℃ to 70℃ AgNi contact material Screw type terminal connection DIN rail type mountingApplicationsPackaging machines Traffic light controls Vending machines Programmable controllers Control panels for electrical distribution Labelling machine Bottling plants Industrial process control Motor control applications Electrical isolation Signal matching between electronic controlsCertificationsIP20 rated CE certified CSA certified EAC certified cRUus certified

Derating will limit the maximum load current at temperatures above 25 ℃. UL/cUL. Heat sink not included. For load current de-rating and heat sink details see manufacturers datasheet. Series PS Peak Switching Relay. AC switching to 280Vac AC load switching to 50A Peak voltage switching Panel mount Dimensions: H22.9 x W45.7 x D47.5

fixing nut and washer. 6.4mm Mount Neon Indicators. 7mm coloured diffused polycarbonate lens Nickel plated brass bezel 125V type suitable for 110-125V a.c. 250V types suitable for 200-250V a.c. Opal lens illuminates orange Average life expectancy 10000 hours when ran at 115V ； 230V respectively

コイル電圧 = 24V dc接点構成 = SPST取り付けタイプ = DINレールターミナルタイプ = ねじV dc奥行き = 75.6mm高さ = 87.9mm長さ = 6.2mmシリーズ = 38 Series入力電流 = 10.5mA動作時間 = 0.2msFinder Interface Relay ModuleThe Finder interface relay module is an innovative， ultra-compact electromechanical device equipped with a 24VDC coil and an SPNO contact configuration. This narrow design interface relay works as a coupling element used to send control signals to and from a PLC. The high number of approvals make it useful for many applications around the world. It offers a high-density solution for smaller electrical cabinets and other industrial applications thus optimising your panel installation. This electromechanical relay module has a small footprint that makes it ideal for applications where space-saving is essential.Features and BenefitsThe contact rated voltage is 24VDC and switching current of 6A The input and output circuits and the voltage supply are completely electrically isolated Instant ejection of relay by plastic retaining clip Integral coil indication and protection circuit Silent high speed switching Long electrical life Operating temperature ranges from -20℃ to 55℃ AgNi contact with optionally hard gold-plating available Screw type terminal connection DIN rail type mountingApplicationsPackaging machines Traffic light controls Vending machines Programmable controllers Control panels for electrical distribution Labelling machine Bottling plants Industrial process control Motor control applications Electrical isolation Signal matching between electronic controlsCertificationsIP20 rated CE certified CSA certified EAC certified cRUus certified

ThedomelensSMDLEDserieshasbeendesignedinasmalluntintedandclearmoldedpackagewithlensforsurfacemountingasgullwingorreversegullwingversionTheVLD.1232.seriesisusingrecentultrabrightInGaN/sapphirechiptechnologywithhighluminousflux.UtilizinglatestadvancedInGaNtechnologyPackagetype:surface-mountPackageform:gullwing，reversegullwingAPPLICATIONSTrafficsignalsandsignsInteriorandexteriorlightingSmokedetectors

検出スペクトル = 赤外線ピーク感度波長 = 940nmパッケージタイプ = T-1 3/4実装タイプ = スルーホール実装ピン数 = 2ダイオード材質 = Si最小検出波長 = 790nm最大検出波長 = 1050nm標準降下時間 = 2.5ns長さ = 5.75mm幅 = 5.75mm高さ = 8.6mmピークフォト感度 = 0.55A/W標準上昇時間 = 2.5nsBPV10NFシリーズフォトダイオード. Vishay SemiconductorsのBPV10NFシリーズのシリコンPINフォトダイオードファミリです。この製品は、黒色プラスチックレンズと昼光フィルタを備えた5 mm (T-1 3/4)標準パッケージに収容されています。BPV10NFフォトダイオードは、放射感度の高い高速デバイスです。BPV10NFシリーズに適した用途には、赤外線検出器、赤外線リモコン、空間データ伝送システムなどがあります。この製品は、TSFFシリーズの赤外線エミッタと併用できます。. BPV10NF PINフォトダイオードの特長: T-1 3/4 (5 mm)パッケージ スルーホール取り付け 昼光色フィルタの付いた黒色のプラスチックパッケージ 高い放射感度 高帯域幅 高速な応答時間 動作温度範囲: -40 → +100 ℃

PINフォトダイオード-T-13/4(5mm)パッケージSRAMOptoSemiconductorsのPINフォトダイオードファミリは、標準のT-13/4(5mm)スルーホールパッケージに収められています。1x1mm2の放射検出面積があります。T-13/4パッケージのフォトダイオードは、短いスイッチング時間を実現します。高速フォトインタラプタ、産業電子機器、制御及び駆動回路などに最適です。

The OSRAM Opto Semiconductors featuring 940 nm Multi-Mode VCSEL Power ArrayDesigned for Sensor Field of InterestANSI/ESDA/JEDEC JS-001 (HBM， Class 2) Very small SMT package VCSEL power array High optical power IR Laser with photodiode

1 m Ω Yageo 抵抗器、PA シリーズ電流センサ - 金属基板の鉛フリー終端に低 TCRAEC-Q200認定 ハロゲンフリーエポキシ RoHS対応(2022年10月現在) 環境的に危険な廃棄物を削減する コンポーネント及び機器の高い信頼性 製品/製造に使用される禁止物質 電流検出に適用される低抵抗 耐硫化性

The OHD Thermal Guard is developed for thermal problem countermeasuresIts unique proprietary design features a magnet and a temperature-sensing soft ferromagnetic substance called ThermoriteRThe material’s magnetic flux density decreases as the temperature increases turning it into a paramagnetic substance at the Curie temperature.High reliability for on/off operations High-speed response Long operational life Excellent environmental durability Compatibility with extremely low (0.1 mW or lower) signals to high power (6 W) levels Extremely simple circuit design Compact， light and easy to handle Dust， explosion and corrosion-proof Wide range of operating temperatures available in 5℃ increments from +30℃ to +130℃ Applications Typical applications include atmospheric temperature detection and overheating monitoring of power transistors， power modules， room heaters， hot gas heaters， PPCs， amplifiers， motors， HDDs， FDDs and other general appliances.

The OHD Thermal Guard is developed for thermal problem countermeasuresIts unique proprietary design features a magnet and a temperature-sensing soft ferromagnetic substance called ThermoriteRThe material’s magnetic flux density decreases as the temperature increases turning it into a paramagnetic substance at the Curie temperature.High reliability for on/off operations High-speed response Long operational life Excellent environmental durability Compatibility with extremely low (0.1 mW or lower) signals to high power (6 W) levels Extremely simple circuit design Compact， light and easy to handle Dust， explosion and corrosion-proof Wide range of operating temperatures available in 5℃ increments from +30℃ to +130℃ Applications Typical applications include atmospheric temperature detection and overheating monitoring of power transistors， power modules， room heaters， hot gas heaters， PPCs， amplifiers， motors， HDDs， FDDs and other general appliances.
